All interlocks must be OK before the laser will fire. If any interlock is tripped, including the external interlock,
the amber INTERLOCK LED will turn on, and the laser will stop firing. The interlock must be reset before the
laser can be restarted.
You may also wire the laser so that opening a door to the laser imaging room (or opening any other switch)
will shut off the laser.
Laser Covers
The LAZR-X laser has a safety cover over the optics area. This cover must be in place during operation.
Shutters
An intracavity safety shutter interrupts the beam and prevents lasing when the laser is not in use.
There is also a shutter at each of the two fiber ports to block the laser when a fiber is not plugged in. Never
try to open the shutters if a fiber is not plugged in.
Beam Dumps
There is a beam dump at each side of the laser. They must be in place to block invisible and visible laser
radiation.
Safety Labels
The following table describes the safety symbols that appear on the laser.
Symbol
IEC 60417 - 5007
IEC 60417 - 5008
EN 61010-1:2010
EN 61000-4-5
EN 61000-4-6
EN 61000-4-11
IEC 60825-1
Reference
Publication
On (supply).
Off (supply).
Indicates the presence of high voltage which may pose a
danger to the user or equipment. disconnect the power supply
before servicing the system.
Class 4 lasers are hazardous under both intrabeam and
diffuse reflection viewing conditions. They may cause also
skin injuries and are potential fire hazards.
