FujiFilm VisualSonics Vevo F2 User Manual page 378

Option (*.dcm)
Explicit VR Little Endian
JPEG Baseline
RLE Lossless
5. Select the export options for the RAW/RF Data. For more information, refer to Export RF Data on
page 234.
6. Tap Done to close the settings page.
General
Use the General tab to configure facility information and basic system settings.
To Select the General Tab
1. Tap More, and then tap System Settings.
2. Tap the General tab.
System Settings
Image pixel data are not compressed. The Tag type is explicitly
defined in the file.
An image created using the JPEG compression algorithm that starts
d isplaying the image as the data are made available, line by line.
Run Length Encoding. A lossless compression algorithm that
provides decent compression ratios in specific types of image file
types such as TIFF and PDF.
Vevo F2 Imaging System User Manual
Description
378
