Working with Images
Images are saved clips and image frames that are listed within a series.
To Open an Image
1. In the Study Browser, expand the study and series that contain the image you want to open.
2. Select the image you want to open, by either double tapping the image row or tapping the image
thumbnail.
The system opens the image in review mode in the mode window.
To Name an Image From the Study Browser
You can name a saved image from the Study Browser.
1. In the Study Browser, expand the study and series that contain the image you want to name.
2. Select the image you want to name and tap the More button.
3. Tap the Name Image button in the pop up menu.
Note:
is selected.
4. Enter the name for the selected image and tap Done to update the name.
Modifying a Stored Image
Image processing tools for modifying images that have already been acquired are available in the Controls
bar while reviewing the image.
The tools vary depending on the imaging mode. For information on the available i mage processing tools for
a mode, see the Acquisition and Display subsections i n the mode settings topic for each imaging mode.
Note: Changes made in the Image Processing panel do not change the outcome
for data quantification.
Storing an Image
You can store a clip or individual frame while you are acquiring image data or reviewing image data.
Study Browser
The Name Image button will not be available if more than one image
