Control
Live/Review
Orientation
Both
Presets
Live
Preview
Live
Pulse
Sequence
Review
Pulse
Sequences
Live
Review
Review
Modes
Sets the image orientation, allowing you to align the image with the
transducer. The blue dot
and image display corresponds to this setting.
Tap any of the buttons to select an orientation. There is an Up/Down
button and a Left/Right button. Each button shows the orientation
that is not currently selected.
Opens the Presets menu.
Use this menu to select an appropriate preset. Each preset contains
settings for the following:
For more information, refer to Applications & Presets on page 365.
Opens the Preview tab of the VADA configuration panel.
For more information, refer to Preview on page 308.
Opens the Pulse Sequences tab of the Review panel.
For more information, refer to Review on page 317.
Opens the P ulse Sequences tab of the VADA configuration panel.
For more information, refer to Pulse Sequences on page 272.
Opens the Review tab of the Review panel.
For more information, refer to Review on page 317.
Vevo F2 Imaging System User Manual
Description
shown at the corner of the control panel
242
