PA Guides on the control panel, with both Guide Area and Guide Line enabled
PA Guides appear on the control panel as the following:
1. Guide Area
2. Optical fiber guides: These indicate which area of the sample will be illuminated by the different
fibers. The lines correspond to the yellow (wide), blue (medium), and green (narrow) fibers.
Note: The Guide Line does not appear on the control panel.
Vevo Spectral Unmixing
Vevo Spectral Unmixing takes a PA-Mode image and separates it into components.
Vevo Spectral Unmixing can be done in PA-Mode (Multi-wavelength).
When an image is unmixed, the Vevo F2 Imaging System automatically saves the original, mixed data,
before saving the unmixed data to a separate image marked as PA-Mode (Unmixing).
Note: PA-Mode (Unmixing) is not a PA-Mode imaging sub-mode.
