Control Live/Review
Oxy-Hemo
Settings
PA Guide
Persistence
Presets
Priority
Modes
Opens a flyout menu that is used to set the display type,
threshold HbT, and sO
Both
For more information, refer to Oxy-Hemo on page 171.
Activates a series of screen overlays intended to help you
position the transducer to the animal's skin line for optimal image
Live
quality.
For more information, refer to PA Guide on page 183.
Applies a pixel-averaging algorithm to the most recently acquired
frames to produce a more uniform view of the image area. This
feature reduces shimmering and motion artifacts in faster moving
tissue, and is useful for imaging uniform tissues such as the liver,
kidney, or prostate.
Tap Persistence, then select a desired level of strength for the
Live
feature. Each level corresponds to the number of frames used in
the algorithm:
Off = 1 frame
l
Low = 4 frames
l
Medium = 8 frames
l
High = 12 frames
l
Opens the Presets menu.
Use this menu to select an appropriate preset.
Live
For more information, refer to Applications & Presets on
page 365.
Adjusts the opacity between the overlay data and the B-Mode
data.
To use this feature, tap Priority and use the up/down buttons to
Both
select a desired value.
Priority is only available in the Both display layout.
This feature is disabled if the image is multiplexed.
Vevo F2 Imaging System User Manual
Description
range for Oxy-Hemo images.
