6. The PA Region Analysis window is different depending on if the image is Multiplexed or not.
If you chose not to Multiplex your image, an additional Save Spectral Curves option is
o
available in the PA Regions section. The PA Region(s) will also be listed with the option to
enable/disable and the option to select what color the line of data will be displayed as on the
graph.
To save a spectral curve:
i. On a PA-Mode (Spectro) image with a PA Region, tap the graph button.
ii. Tap Save Spectral Curves. The Save Spectral Curves panel is displayed.
iii. Select w hich PA Region to save by tapping the check box for each PA Region you
want to save.
iv. (Optional) Change the PA Region default name by tapping the text box and typing a
new name.
Session Tasks
Note: Once the spectral curve is saved, you will see your curve on the
Photoacoustics page in System Settings. See Photoacoustics on
page 383 for more information.
