FujiFilm VisualSonics Vevo F2 User Manual page 72

Note: The volume estimate from an ellipse measurement is based on the
following:
Volume = 0.52 x width
The 'width' component of the formula is the lesser of the two axes of the ellipse
measurement, while the 'length' component is the greater.
To Add an Ellipse Measurement
1. Tap Measurements.
2. Tap Ellipse.
The ellipse measurement is placed on the image.
3. Tap and drag one of the line points to the desired location on the image. As you move the point, the
measured length is updated on the Measurements panel. Refer to Using the Measurements Panel
on page 62.
Session Tasks
2
x length
Vevo F2 Imaging System User Manual
72
