Any control listed here can be added to, or removed from, the right sidebar of the control panel during an
imaging session. For more information, refer to Customizing the Control Panel on page 91.
Control Live/Review
AM-Mode Angle
Annotations
Brightness
Clip Settings
Contrast
Modes
Adjusts the sample volume to an angle other than the vertical
position.
In M-Mode, this control adjusts the gate angle. If you set an angle
to any value other than 0°, the system begins acquiring data in
AM-Mode.
Live
In AM-Mode, this control adjusts the angle of the line of
acquisition.
To set the angle, tap the AM-Mode Angle button and use the Up
and Down buttons to adjust the angle, or use the slider. You can
also tap 0° to return to M-Mode.
Review Adds annotations to an image.
Adjusts the brightness of the image.
Review
The current brightness is displayed on the button.
Opens the Clip Settings menu.
Both
For more information, refer to Configuring Clip Settings on
page 101.
Adjusts the contrast level of the image.
Review
The current contrast is displayed on the button.
