1. Select a profile from the list.
2. Tap outside the flyout to close it.
Waveform
The waveform profile used by the transmit event. This drop-down list shows the currently selected
waveform, a Select Waveform option, and any waveform loop blocks that enclose the event.
To change the waveform profile used by this event, tap this drop-down list and tap Select Waveform to
open a flyout:
The top section of this flyout lists waveform profiles. This is identical to the list to the left of the Waveforms
panel.
The bottom section of this flyout is a preview that shows the selected waveform profile.
Note: The preview cannot be used to edit the waveform profile.
Modes
Select Waveform flyout panel
