FUJIFILM DIGITAL RADIOGRAPHY
DR-ID 1300PU
Service Manual
Document No.
Version 06 -
2-26-30 Nishiazabu, Minato-ku, Tokyo
DR-ID 1300
018-234-06E
Mar. 31, 2020
Printed in Japan
The relationship between mR (milliroentgen), which
is the unit of radiation, and μC/kg (micro-coulomb/
kilogram), which is the SI derived unit of radiation, is
as follows.
1 mR = 0.258 μC/kg
FDR is a trademark or a registered trademark of FUJIFILM Corporation.
<No part of this manual may be reproduced or transmitted.>
©
2016-2020 FUJIFILM Corporation. All rights reserved.
Copyright
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by means, electronic,
mechanical, photocopying, recording or otherwise, without the prior
written permission of FUJIFILM Corporation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR-ID 1300 and is the answer not in the manual?

Questions and answers

Related Manuals for FujiFilm DR-ID 1300

Summary of Contents for FujiFilm DR-ID 1300

  • Page 1 SI derived unit of radiation, is as follows. 1 mR = 0.258 μC/kg FDR is a trademark or a registered trademark of FUJIFILM Corporation. <No part of this manual may be reproduced or transmitted.> © 2016-2020 FUJIFILM Corporation. All rights reserved.
  • Page 2 BLANK PAGE...
  • Page 3 The Service Manual is applicable to the digital radiography DR-ID 1300. 4. The following conducts are prohibited without prior written approval of FUJIFILM Corporation: - Copy or transcribe a whole or part of the contents of this manual.
  • Page 4 - 3B: Indicates that screw-locking bond needs to be applied to screw sections of installed parts/components. Recommended screw-locking bond: Three Bond 1401B 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 5 Calibration Dosimeter  Steel rule (150 mm)  Steel rule (300 mm)  Digital multimeter   ∗ Calipers  ( ∗ : A block gauge for use in inspection requires calibration. 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 6: Table Of Contents

    Safety Precaution DR-ID 1300 / DR-ID 1300PU Service Manual - Contents Safety Precaution Safety Precautions ..............1 Cautions on Electromagnetic Waves ........14 General Precautions ................1 DR-ID 1300PU ................14 4.1.1 Electromagnetic Compatibility (EMC) ............14 Precautions on Infection ..............2 4.1.2 Further Information for IEC 60601-1-2 (EN60601-1-2) ......15 Requirement ..................2...
  • Page 7 1.2.2 For both DR-ID 1200 and DR-ID 1300 ............2 1.2.3 For both DR-ID 600 , DR-ID 1200 and DR-ID 1300 ........3 10. Exposure Stand ..............16 Dimensions, Weight and Location of the Center of Gravity ... 6 11. Action in case of Failure ............17 DR-ID 1300PU ................6...
  • Page 8 Board-Related Information ..............MD-6 Block Diagram ..............MD-7 2.1 System Block Diagram .............MD-7 2.2 SE Block Diagram ..............MD-8 2.3 MP Block Diagram ..............MD-9 Effective Area and Center Position of Image ....MD-10 Effective Area .................MD-10 3.2 Center of the Image ..............MD-10 Calibration ..............MD-11 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 9 Changing the BIOS Setting ............ MT1-1 Updating MP OS Version ............MT1-4 1.3 Checking the Network Connection Configuration ....MT1-4 Action for the Case Where the F-Secure is Installed ..... MT1-5 Analysis with Log ..............MT1-6 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 10 SE (Flat Panel Sensor) ........... MC-19 SE (1305SE) ................MC-20 3.1.1 SE Rear Cover ................... MC-20 3.1.2 POW65A Board .................. MC-21 3.1.3 RMV65A Board .................. MC-23 3.1.4 LED65B Board ................... MC-26 3.1.5 LED65C Board ................... MC-26 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 11 Dual Panel Point Defect Specifications Excess Area Display ..MU1-52 1.10.3 DR-ID 1422SE Panel Correct Data Backup/Restore ....... MU1-92 1.10.4 Config Setting Backup/Restore ............MU1-93 NETWORK SETTING ............MU1-53 1.10.5 HISTORY Backup ................MU1-94 1.5.1 Local Network .................. MU1-54 1.10.6 LOG Backup ..................MU1-95 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 12 [3.2] MP Version >> .................. MU2-27 INSTALL ................MU2-51 [3.2.1] MP1 Version Check >> ..............MU2-28 VERSION UP ...............MU2-51 [3.2.2] MP2 Version Check >> ..............MU2-28 [3.3] SE Version >> .................. MU2-29 0.10 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 13 BACKUP ................MU2-68 1.14 RESTORE ................MU2-70 1.15 I/O TRACE EXPERT ............MU2-71 1.16 ERROR DB ................MU2-72 1.17 UNINSTALL (ALL RUs) ............MU2-73 1.18 VERSION UP (ALL RUs) ............MU2-73 1.19 Configuration ................MU2-74 1.19.1 CDPath ..................... MU2-74 0.11 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 14 CIRCUIT DIAGRAM (SE) (#******** - #********) ......SP-11 PARTS NOS. SEARCH TABLE ..........SP-13 List of Service Parts for Securing and Wiring ......SP-14 Table of Screws / Washers Indication Symbols ......SP-16 List of Quick Wearing Parts ............SP-17 0.12 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 15 Checking the Cables ............PM-8 Checking the Exposure ........... PM-9 Checking for Image Problems ........PM-10 10. Checking the Error Log ..........PM-11 11. Cleaning the Periphery of the Machine and the External Cover ..........PM-12 0.13 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 16 0.14 Installation (IN) Installation (IN) How to Read the Installation Manual ........IN-1 0.14 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 17 10.10 Setting the IP Address of the SE ..........IN1-65 Connecting the X-Ray Shot Cable .........IN1-14 10.11 Updating SE Application Software Version ......IN1-67 6.5.1 Connecting the X-Ray Shot Cable (Steady Grid Type) ...... IN1-14 0.15 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 18 16. Backing Up the Data ............IN1-89 17. Final Checks ..............IN1-91 17.1 Checking the SE ..............IN1-91 17.2 Checking the Status of Boards ..........IN1-91 18. Visual Inspection and Cleaning of the Machine ..IN1-93 0.16 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 19 Connecting the X-Ray Shot Cable .........IN2-14 10.9 Setting the Serial ID of the Long Panel ........IN2-65 6.5.1 Connecting the X-Ray Shot Cable (Steady Grid Type) ...... IN2-14 10.10 Updating SE Application Software Version ......IN2-66 0.17 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 20 Density Problems, White Blank Portion, and Sensitivity Problems in the Images .........IN2-86 14. Checking the Error Log ..........IN2-88 15. Clearing the EDIT HISTORY .......... IN2-89 16. Backing Up the Data ............IN2-90 0.18 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 21 Appendix 3.1 Local Network PreSetting >> .........Appx IN3-1 Appendix 3.2 MC ETH0 IP Setting >> .........Appx IN3-6 Appendix 4. Precaution before using the DR-ID 1300 ......Appx IN4-1 Appendix 5. Defect Calibration and Lag Calibration ........Appx IN5-1 Appendix 5.1 DR Maintenance Software ........Appx IN5-2 Appendix 5.1.1 Defect Calibration ..............Appx IN5-2...
  • Page 22 0.20 Performance Check (PC) Performance Check (PC) DR-ID 1300 Performance Check List ........PC-1 0.20 DR-ID 1300 / DR-ID 1300PU Service Manual 018-234-04E...
  • Page 23 0.21 Performance Check (PC) BLANK PAGE 0.21 DR-ID 1300 / DR-ID 1300PU Service Manual 018-234-04E...
  • Page 24 0.22 Performance Check (PC) BLANK PAGE 0.22 DR-ID 1300 / DR-ID 1300PU Service Manual 018-234-04E...
  • Page 25 03.31.2016 New release (FM9369) All pages 06.30.2017 Revision for MC V15 (FM9473) 03.31.2020 Revision for MC V17.2 (FM9623) 5, 7, 8, 11, 12 DR-ID 1300 / DR-ID 1300PU Service Manual Safety Precaution 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 26: Safety Precautions

    Service Manual to verify that the retaining screws are securely tightened to properly secure the parts. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 27: Precautions On Infection

    Comply with safety information on protection against infectious diseases when servicing the machine. Do not touch blood or other biological fluids. IEC60950-1 Approval If not observed, severe injury and even death may result. 1.3.2 Monitor IEC60950-1 Approval Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 28: Precautions On The Patient Environment

    It excludes the space traveled by the patient to reach the medically-used room. <For bed-type machine> 2.5 m 2.5 m 2.5 m 600_020001.ai <For stand-type machine> 2.5 m 2.5 m 2.5 m 600_020002.ai Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 29: Cautions On Connection

    If the voltage between cables differs from the coil voltage of the relay, commission the service personnel of the X-ray equipment to check the cable connection. If erroneous connection is made, the machine might get damaged. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 30: Safety And Other Symbols

    At the same time, your cooperation in the correct disposal of this product General mandatory action sign will contribute to the effective usage of natural resources. 600_020035.ai For more information about waste, please contact FUJIFILM dealers. Year of manufacture No stepping on surface 600_020044.ai 1200_020016.ai...

  • Page 31: Precautions On The Mp Installation

    The surface temperature of the MP will be raised only when the MP is malfunctioning. Install the MP in an area that is located away from the floor path into the exposure chamber. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 32: Labels

    2.1.1  1305SE 1300_020024.ai (C) Protective earth (ground) Label 600_020041.ai  Outside Japan (A) SE system label 1300_020007E.ai (B) Panel ID label 1300_020001.ai 1300_020024.ai (C) Protective earth (ground) Label 600_020041.ai Safety Precaution 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 33 (B) PU rating label 1300_020009E.ai (C) Stand bracket identification label 1200_020010.ai  Japan 1300_020015.ai (A) PU pharmaceutical certification label 1300_020003.ai (B) PU rating indication label 1300_020004.ai (C) Stand bracket identification label 1300_020015.ai Safety Precaution 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 34 Use supplied power cables. Do not use other power cables. <Outside Japan> Use specified power cables. Do not use other power cables. Refer to the following section for the cable specifications. {Spec:6._Electrical Specifications} Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 35 If erroneous connection is made, the machine might get damaged. (H) AC bucky relay unit rating identification label 100-110 V  2015 1300_020011.ai 110-120 V  AC bucky relay unit MPC54B board 1300_020006E.ai 2015 1300_020012.ai Safety Precaution 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 36 (L) SE cable 4 m identification label 2015 1300_020025.ai SE cable 10 m identification label 1300_020014.ai (I) Protective ground mark (engraved mark) 1300_020020.ai SE cable 20 m identification label 1300_020019.ai 600_020041.ai (J) Caution label 600_020080.ai Safety Precaution 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 37 2.1.3  PU Power Cable Caution Label (USA Only) Power Cable Caution Label (Only Hospital Grade Power Cable for U.S.A.)  MC system label 1200_020025.ai  MC application 600_020018.ai 1300_020021.ai Safety Precaution 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 38: Classification

    Equipment not suitable for use in the presence of a flammable anesthetics mixture with air or with oxygen or nitrous oxide. 5. According to the mode of operation Continuous use Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 39 WARNINGS - Do not place devices generating electromagnetic wave near this equipment. - If a device(s) other than those specified is connected, predetermined EMC performance cannot be guaranteed. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 40 Class A - The use of accessories, transducers and cables other than those specified, with the suitable for use in all exception of transducers and cables sold by FUJIFILM Corporation as replacement establishments other Harmonic emissions than domestic and those...
  • Page 41 Over the frequency range 150 kHz to 80 MHz, field strength should be less than 3 V/m. typical commercial or hospital environment. NOTE: U is the a.c. mains voltage prior to application of the test level. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 42 NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 43 Everybody who connects additional equipment to the signal input part or signal output part configures a medical system, and is therefore responsible that the system complies with the requirements of IEC 60601-1-1 or JIS T 0601-1-1. Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 44 Safety Precaution BLANK PAGE Safety Precaution 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 45 03.31.2016 New release (FM9369) All pages 06.30.2017 Revision for MC V15 (FM9473) 1, 11, 13 03.31.2020 Revision for MC V17.2 (FM9623) 2, 7 DR-ID 1300 / DR-ID 1300PU Service Manual Product Specifications 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 46: Commodity Composition And Optional Items

    Remarks Japan DR-ID 1200 MC SOFT # V2.0 or later Install the DR-ID 1200 MC MC Software Only application Outside Japan DR-ID 1200 MC SOFT E to the DX Console. Product Specification 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 47: Optional Items

    DR1300 SE-CBL 10M E MP - SE Japan DR1300 SE-CBL 20M # Outside Japan DR1300 SE-CBL 20M E 1.2.2 For both DR-ID 1200 and DR-ID 1300  Options for the Power Supply Unit (MP) Name of machine Type Destination Product abbreviation Remarks...

  • Page 48: For Both Dr-Id 600 , Dr-Id 1200 And Dr-Id 1300

    Product Specifications 1.2.3 For both DR-ID 600 , DR-ID 1200 and DR-ID 1300  X-Ray Shot Cable Name of machine Type Destination Product abbreviation Remarks Japan DR600 3S-CBL 5M # 3-core, 5m Outside Japan DR600 3S-CBL 5M E Connected between X-ray...
  • Page 49 DR600 I/F BOX # When the X-ray shot cable cannot be connected to the X-ray generator, the shot signal I/F box between the X-ray generator and DR-ID 1300 is used for cooperation. Outside Japan DR600 I/F BOX E Japan DR600 I/F BOX HAND SW #...
  • Page 50 Select larger time than the accumulation time above and the selectable minimum time of mode2. If the selected time is longer than 3.8 seconds, you cannot use the I/F box. Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 51: Dimensions, Weight And Location Of The Center Of Gravity

    Dimensions: W567.4 x D1339.8 x H50 (mm) Weight: Approx. 19.5 kg NOTE Unit: mm Specifications, dimensions and weight are subject to change without notice due to continual improvements. 1200_030004.ai 1339.8 Unit: mm 1300_030001.ai Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 52: Installation Space

    When installing the MP, be sure to use the bracket on the floor or the fixing bracket to prevent it from falling. Any one of these, approx. 4 m, approx.10 m, approx. 20 m 1300_030002.ai Product Specification 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 53: Dr-Id 1300Mp

    NOTE When installing the MP horizontally, install the MP to make the breaker switch and the indicator underside. If the MP is installed upside down, the power supply is deteriorated. Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 54: Means For Moving And Fixing The Machine

    For the DR-ID 1300MP, the bracket for anchoring is specified as an optional item. Refer to the following figure to anchor the DR-ID 1300MP. <DR-ID 1300MP> 169.5 or more 167.1 69.5 or more 167.1 or more Unit: mm 1200_030019E.ai Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 55: Environmental Conditions

    - Dusty places - Places where the machine is subject to constant or excessive vibration or shock - Places exposed to direct sunlight - Places where no ventilation equipment is provided Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 56: 6. Electrical Specifications

    Category 5e or more (UTP type) Between the DR-ID 1300MP 100 m 1000Base-T and the DR-ID 300CL <Connection> Straight cable  Network HUB A 1000Base-T compliant HUB should be used. Product Specification 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 57: Dr-Id 300Cl (Computer)

    Product Specifications DR-ID 300CL (Computer) See the DR-ID 300CL Service Manual. Monitor See the DR-ID 300CL Service Manual. Product Specification 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 58: 7. Other Specifications

    50 dB or less (except single noise) REFERENCE The values are measured at positions that are 1.2 to 1.5 m above the floor and a 1 m interval from the device surface. Product Specification 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 59: Grid

    The specification of recommended long-length grid for a long panel made by Mitaya Manufacturing Co., Ltd. is following. - Grid density: 40 lines/cm - Grid ratio: Any one of 10:1, 8:1, or 6:1 - Focusing distance: 100 to 300 cm Product Specification 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 60: Lattice

    - Lattice member diameter: 1 mm ± 0.2 mm - Oblique direction angle of X-ray: 15 degrees or less For the procedure for the quality of the lattice, refer to the following. {IN:Appendix 6._Lattice} Product Specification 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 61: 10. Exposure Stand

    - With a patient weighing at least 135 kg on it, the stand must be able to support SE. - Even with a patient weighing at least 135 kg on it, no load must be directly applied to the surface of the SE. Product Specification 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 62: 11. Action In Case Of Failure

    A period of one year after the installation of the machine is specified as the guarantee period, and components are provided free from FUJIFILM against the failure during u INSTRUCTION u that period. However, if the failure is not attributed to the design and production of the...

  • Page 63: Failure Attributed To The Manufacturer

    A defective point is identified. Cable connection is checked, or the board is replaced as needed. The manufacturer (FUJIFILM) bears the cost of the primary repair during the charge- free guarantee period. Request via the PRS (Parts Request System). u INSTRUCTION u Observe the following terms when the primary repair takes place by the sales company.

  • Page 64: 12. Disposal Of The Machine

    However, if the contamination of the SE surface is intense and can not be removed, do not return the SE to the Parts Center, and dispose of according to the local regulations. Product Specification 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 65 Control Sheet Issue date Revision number Reason Pages affected 03.31.2016 New release (FM9369) All pages 06.30.2017 Revision for MC V15 (FM9473) DR-ID 1300 / DR-ID 1300PU Service Manual Machine Description (MD) 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 66: Summary Of The Machine

    - 48.6 x 16.7 inch size flat panel sensor (DR-ID 1305SE) enables long-length (system) DR-ID 1200MC radiography of the entire lower limbs or the entire vertebrae with a single irradiation. (control software)*2 This enhances the work efficiency of long-length radiography and also shortens a DR-ID 300CL constrained time of a patient, reducing patient burden. (image processing unit) - The flat panel sensor (DR-ID 1305SE) is also available for standard radiography. 48.6 x 16.7 inch size flat panel sensor enhances the work efficiency of patient *1: For supplying the power to the SE (flat panel sensor). positioning. *2: For controlling the SE (flat panel sensor) - By utilizing FUJIFILM’s proprietary ISS (Irradiation Side Sampling) method and GOS scintillator with an optimal composition of large and small phosphor particles, images with high sensitivity and high sharpness are obtained. In addition, the noise reduction circuit enhances the sensitivity and sharpness in low-density areas. - After an X-ray irradiation process is completed, the image appears on the monitor of the image processing unit in 9 to 19 seconds. - The flat panel sensor (DR-ID 1305SE) has the X-ray automatic detection function (AUTO DETECT). With this function, the flat panel sensor detects even a small amount of X-ray precisely to start an exposure without connecting it to the X-ray device. - Up to two flat panel sensors (DR-ID 1305SE) can be used at the same time. MD-1 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 67 [DR-ID 1200MC] X-ray operator DR-ID 1201SE/1202SE/ Generator console 1211SE/1212SE X-ray operator Generator console Remote control Remote control : DR-ID 1300 1300_100001.ai DR-ID 1305SE DR-ID 1300MP DR-ID 1305SE : DR-ID 1300 1300_100012.ai MD-2 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 68: General Configuration Of The Dr-Id 1300Pu And Names

    - Status lamp B (for each panel) - Transmits/receives the X-ray shot signal and exposure Lighting state Description conditions/exposure performance data, and transmits the DR-ID 1300MP Exposure possible information to the MC. READY LED (power supply unit) Flashing at 1.0-sec intervals During exposure sequence - Supplies power (24 V) to the SE. (Green) - The power cable is shipped together with the machine from Unlit Standby the factory to destinations inside Japan. The cable needs to be locally prepared in other countries. MD-3 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 69: Electric Parts

    - Control of each board in the panel, based on requests from the MC (battery monitoring, LED control, shock sensor control, SE application update, log output to the Center FTP server, etc.). - Perform command communications between the RMV boards for each panel unit. (D) LED Lighting of the panel LED (status lamp) (E) POW Supply of the DC power for the boards in the panel. 1300_100004.ai - Convert the SE input power 24 V DC into the power supply for the panel system 12 V, into the power supply for the (F) POD PDV, and into the power supply for the HUB 5 V. - Relay the LED control signal from the RMV board to the LED board. (G) HUB Connect each board in the panel with LAN cables. (H) LED Lighting for each panel selection READY LED. Separate control signals for each panel selection READY (I) COC LED from the RMV65A board. MD-4 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 70: I/O Parts Information

    1.3.3 I/O Parts Information Name Symbol Type Description Power supply circuit breaker switch n MP DETAIL A (A) Power circuit breaker 200 VAC - Handle mark: 600_100009.ai Cools the interior of the MP and (B) MP cooling fan FAN1 24 VDC exhausts the air inside the MP. (C) Circuit protector 1200_100013.ai MD-5 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 71: Board-Related Information

    MPX54A board Transmits X-ray exposure conditions and the shot signal to the X-ray equipment. Contact signal output relay. Relay Part No.: AHN22005 (Panasonic Electric Works) Board-type power supply unit. Power supply unit Supplies power of 12 VDC to the inside of the MP and the SE. Part No.: CME240P-24 (TDK Lambda) LED board for indicating power supply status. LED60C board Indicates the power supply status. For LAN connection. MPC54B board MP control board with the CPU mounted. The remote switch (optional) can be connected. NFB51A board Noise filter Relay the system power DC24V for SE and the LAN signal to MPL65A board the SE. *: The AC relay and the DC relay incorporated in the AC bucky relay unit need to be replaced periodically. The relay incorporated in the MPX54A board need not be replaced unless a failure occurs. 1300_100010.ai MD-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 72: 2. Block Diagram

    10ｍ/20ｍ （LAN+24V power) Power supply Power cable (3m) AC100V-240V with protective earth conductor X-ray room Outside the X-ray room 外 (IEC 60601 environment) (IEC 60950 environment) （ 環境） （IE 環境） 1300_100005E.ai MD-7 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 73: Se Block Diagram

    POW65A POW1 RMV28 RMV27 RMV4 RMV28 RMV27 RMV11 RMV12 RMV4 RMV65A RMV65A Control GTD65A(rear) GTD65A(rear) GTD65A(rear) GTD65A(rear) /Control LED65C LED65B D-sub 9pin Can also be connected to the diagonal position 1300_100005E.ai MD-8 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 74: Mp Block Diagram

    Relay Board Ver Selector For Checking Board Ver Board Ver Panel 2_12V output control Panel 1_12V output control +5V D output control ERC54A AC bucky relay uint Remote SW (Option) 1300_100007E.ai MD-9 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 75: Effective Area And Center Position Of Image

    MD-10 3. Effective Area and Center Position 3.2 Center of the Image of Image The center of the image is as shown below: 1339.8 669.9 3.1 Effective Area An effective area of an image extends over 1234.2 mm x 424.8 mm (8,228 x 2,832 Center of the image area pixels). 1234.2mm (8228Pixel) Center of the image area Unit: mm 1300_100009E.ai 1300_100008E.ai MD-10 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 76: Calibration

    - For defect calibration - For defect calibration to be generated calibration calibration (at termination - For lag only) calibration (*2) Required time About 30 seconds About 30 seconds About 40 minutes About 5 minutes (per one panel) *1: If starting the machine after the short time interruption (up to about 5 minutes) of the power supply, battery replacement, etc., the background calibration is not performed. After starting up, it is immediately usable. *2: The full calibration does not generate the lag calibration data itself but calculates the lag calibration factor only. The lag calibration data is calculated by multiplying the offset image captured automatically when the exposure menu is registered at a normal exposure by the lag calibration factor. MD-11 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 77 4, 5, 11, 14, 17, 18, AppxMT1-1 to 1-8 DR-ID 1300 / DR-ID 1300PU 03.31.2020 Changes in pagination (FM9623) 6 to 10, 12, 13, 15, 16, 19 to 27 Service Manual Troubleshooting (MT) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 78: Overview Of Troubleshooting

    When an error occurs, it may incur two or more additional errors. The error code displayed on the CL represents the last-encountered error. You must therefore view the error log to locate the error code related to the encountered trouble before proceeding to perform troubleshooting. MT-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 79: Determining The Error Code Of The Encountered Trouble

    Level where an accidental retry error causing no problem in performance, and routine processing can be continued. An error is logged, but the user is not notified when the error occurs. It is necessary to check the error log in periodic servicing and take remedial action. The logged errors may be used for design analysis. 600_200002.ai MT-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 80: How To Use The Detail Error Log

    [12610] 2009/07/27 18:19:52 023913 @xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx Indicates a serial number for each error category. [12210] 2009/07/27 18:23:50 0244C0 @xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx [12103] 2009/07/27 19:10:43 023FE9 @xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx [12103] 2009/07/27 19:12:40 023FE9 @xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx [12111] 2009/07/27 19:10:43 023913 @xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx 600_200004.ai MT-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 81: 11112 Error

    If it does not improve, replace the RMV board and the GLG board. 16 0x00010000 Sleep mode recovery error Replace the RMV board. 17 0x00020000 Image FLASH error Replace the RMV board. MT-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 82 Replace the RMV board. 31 0x80000000 Exposure sequence error Replace the RMV board. Replace the GLG board, POW board and RMV board. 32 0x10080000 Gate IC/Panel cracking judgment If it does not improve, replace the SE. MT-5 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 83 11112 error Connector (BB2_CNCHK_1) RMV23 11112 error Gate IC error RMV24 11112 error Gate IC error RMV25 11112 error Thermistor error RMV27 11112 error Long panel RMV28 11112 error Long panel MT-6 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 84: Error Code Table

    SSD and load onto the CPU board memory and the SODIMM mounted on the SPC board, but read from the SSD fails. 10601 System file load error - Check the SSD. <Reference> You can know the file name where a failure in loading occurs on the error log. MT-7 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 85 Blowout of a fuse of the POW board is detected by the RMV board during the check of fuses. <Reference> You can know which device (fuse, connector or fan) is defective on the error log. MT-8 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 86 Battery high temperature [During bootup/routine processing] - Check the ambient temperature. 11215 The battery temperature rises to the warning level. - Space exposures to lower the temperature in the FPD. warning MT-9 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 87 [During menu registration] 11228 Panel cracking judgment error - Panel breakage (9 mm x 9 mm or more) is detected. The SE has detected a panel cracking and informs the MC. MT-10 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 88 An error occurs in a control command to the panel. - Check the connection with the AP (for wireless type). (warning level) - Check the connection of the SE cables (for wired type). MT-11 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 89 Parameter error An error is detected in an item set by service personnel (wrong value setting, inconsistency of combination, or the like) Memory map reconfiguration [During bootup/routine processing] 12150 A retry of memory map reconfiguration fails. retry MT-12 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 90 You can know the FPD No. of interest on the error log. Initialization error during SE [During bootup] - Check the board condition in the FPD. 12222 An error occurs in bootup in connecting the SE. connection {MU2:[5.2]_SE Board State >>} MT-13 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 91 - Continue exposures until the necessary exposure count 12234 for the defect calibration is reached, and click [Create a exposures for defect calibration <Reference> Gain Data]. Five exposures are necessary to carry out the defect calibration. MT-14 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 92 [During full calibration] After marker calibration is to take place, the number of exposures - Check whether the exposure count has turned to the 12281 exposures for marker necessary for the marker calibration is recognized to be insufficient. fourth exposure. calibration MT-15 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 93 [During bootup/routine processing] 12504 CL response error Response other than normal is received from the CL. [During bootup/routine processing] 12599 CL system error An error is detected in the CL system. MT-16 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 94 - Check the selector menu of the CL. 12901 The exposure menu cannot be accepted because the operative method is - Check the settings in EDIT CONFIG. method not specified) not specified. MT-17 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 95 - Click [OK] and check that the ready lamp turns on again. 13043 Electrical noise detection error <NOTE> When a 13043 error occurs, 11112 (detail code: 0x00800000) is recorded in the error log. MT-18 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 96: Troubleshooting Based On Led Indication

    Is the ERROR lamp lit/flashing? Flashing 1300_100003.ai A communication error occurs. A hardware error occurs. Check the appearing error code, Check the appearing error code, and take countermeasures. and take countermeasures. 600_200008.ai MT-19 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 97: Analysis Of Abnormal Images

    - Image data files for 3 images each for before and after the abnormal image occurred that have been saved in the "C:\Program Files \Fujifilm\IIP\Data\Image" of the CL, apart from the individual information file (*.inf)
  • Page 98 If the moiré occurs after the timing is adjusted by means of the exposure stand trimmer, the cause might lie in some failure in the drive unit mechanism of the grid mounted on the exposure stand. MT-21 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 99: Writing Out The Image Data

    Writing out the image data → The DOS prompt screen appears, and the image files are copied in the folder. After the files have been copied, the following screen appears. DR-ID 1300 always keeps 50 latest images stored. The following describes the procedure for writing these images when a malfunction occurs. (1) Start up the RU PC-TOOL. (2) Select "LOG ALL" from the BACKUP menu and click [EXECUTE].

  • Page 100: Backup File

    - ROI coordinates of the exposure part per ROI numbers (IROI/x1/y1/x2/y2) - ROI coordinates of the Pb part per ROI numbers (PbROI/x1/y1/x2/y2) - Acquisition timing for each frame, average QL of ROI for each exposure part, and average QL of ROI for each Pb part (Frame/Time/QLave_X/QLave_Pb) - Judgment results for lag correction ON/OFF (JudgementCorrect) - Decay constant per ROI numbers (IROI/A(iROI)) MT-23 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 101: Seregistinfo.txt

    MT-24 SERegistInfo.txt How to read the SERegistInfo.txt file is as follows. Lxxxxxx Lxxxxxx Lxxxxxx Wxxxxxx Nxxxxxx reg No. serial (1-100） MT-24 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 102 MT-25 BLANK PAGE MT-25 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 103 MT-26 BLANK PAGE MT-26 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 104 MT-27 BLANK PAGE MT-27 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 105: Appendix 1. Troubleshooting For 10753 Error

    - V02.15 or earlier: Perform step (6) only. Step (7) or later is unnecessary. (2) Turn ON the power of the PC while pressing the <ESC> key. → Startup Menu is displayed. (3) Press the <F10> key. 600_700336.ai 600_700334.ai → BIOS setup window is displayed. AppxMT1-1 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 106 (7) Select [Power] > [Hardware Power Management]. 600_700339.ai 600_700337.ai → Save Changes and Exit window is displayed. → Hardware Power Management window is displayed. (11) Select [Yes]. (8) Select [PCI Express Power Management] and change [Enabled] to [Disabled] by pressing the right arrow key. 600_700340.ai → BIOS setup is completed. 600_700338.ai AppxMT1-2 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 107 → Hardware Power Management window is displayed. (5) Check that the [PCI Express Power Management] is “Disabled”. 600_700334.ai → BIOS setup window is displayed. 600_700338.ai (6) Press the <ESC> key and select [Ignore Changes and Exit] to complete BIOS setup window. → BIOS setup window is completed. AppxMT1-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 108: Updating Mp Os Version

    (Console, MC) 600_203001.ai l Example 2: MPs including a HUB are connected in line. (Console, MC) 600_203002.ai n Modified Network Configuration Each device directly connects to the HUB. (Console, MC) 600_203003.ai AppxMT1-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 109: Action For The Case Where The F-Secure Is Installed

    For a countermeasure for this case, refer to the ECN shown below. - "ECNxxx, 10753 due to incomplete setting of F-Secure: Sporadic disconnections of the MC-to-MP line" AppxMT1-5 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 110: Analysis With Log

    MC and the SE starts, and then the CONNECT 2013/12/13 09:48:18 00000F04 192.168.0.20 NEW SE is recorded. 0005000710010200 LifeCkRq 2013/12/13 09:48:18 00000F04 192.168.0.20 0007000510010300 LifeCkRs 0000 * LifeCkRq: Life check requirement from the MC LifeCkRs: Life check response from the MP AppxMT1-6 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 111 Possibly abnormal parts are the ERC54A board and the HUB of this MP. Replace the parts, identify the location of the failure, and then repair it. If the failure is not solved after the parts are replaced, check the MPC54A board. AppxMT1-7 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 112 AppxMT1-8 BLANK PAGE AppxMT1-8 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 113 Revision for MC V17.2 (FM9623) AppxMC1-1 to 1-8, AppxMC2-1 to 2-4 03.31.2020 Changes in pagination (FM9623) 26 to 32 DR-ID 1300 / DR-ID 1300PU Service Manual Checks, Replacement and Adjustment of Parts (MC) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 114: Precautions For Check, Replacement, And Adjustment

    - When servicing a board, do not touch connector pins mounted on the board Orange with bare hands. White Gray - Never remove the red-painted screws. Black Yellow Green Blue Brown Purple Spiral of yellow and green MC-1 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 115: Mp (Power Supply Unit

    If the power is turned ON with the screw or the like dropping in the power 1200_700026E.ai supply unit, short-circuiting will result. (2) Remove the front cover. #1 Remove: TP3x6 (x6) Front cover 1200_700027E.ai MC-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 116 - When replacing the front cover, be sure to order the following two types of labels (A) and (B), and apply them on the new cover. Refer to the following for the application locations. 15±1mm 20±1mm 2±1mm 1200_300220.ai MC-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 117: Mpx54A Board

    600_300009.ai REFERENCE The MPX54A board is equipped with exchangeable relays (K1 to K6). n Board Location DETAIL A MPX54A board 1200_300010.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. 1200_300009.ai MC-4 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 118: Mpc54B Board

    LAN connector. 1200_300008.ai Older board (J version or earlier) Newer board (L version or later) Older board bracket Newer board bracket 1200_300221E.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-5 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 119 Micro fuse Daito Communication Apparatus Co. Ltd. LM20(D)CDL Micro fuse Daito Communication Apparatus Co. Ltd. LM03(D) Micro fuse Daito Communication Apparatus Co. Ltd. LM20(D)CDL Micro fuse Daito Communication Apparatus Co. Ltd. 1200_300002.ai MC-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 120: Setting The Jumper Pin

    ETHERNET SWITCH 5V_Hub CONTROLLER BLOCK 12V_1 DCDC 12V_2 DCDC 600_300168.ai 1200_300216.ai n Jumper Pin Information n Handling Fuse Failures No jumper pin is used in the machine. Change the target fuse. MC-7 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 121: Led60C Board

    DETAIL A (2) Remove the LED60C board. LED60C board #1 Remove: M3x6 (x1) #2 Disconnect: Cable connector (LED1) LED60C board 1200_300012E.ai 1300_300006.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-8 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 122: Mpl65A Board

    If two SE cables are connected, remove also the cable connectors of MPL 6 and 8. 1300_300007.ai MPL5 MPL7 MPL3 MPL4 MPL1 1300_300008.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-9 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 123 Rated voltage Rated amperage Type Model indications LM40(D)CDL Micro fuse Daito Communication Apparatus Co. Ltd. LM40(D)CDL Micro fuse Daito Communication Apparatus Co. Ltd. n Handling Fuse Failures Change the target fuse. MC-10 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 124: Nfb51A Board

    (2) Remove the NFB51A board. #1 Unclamp: Clamp (x1) NFB51A board #2 Disconnect: Cable connectors (NFB1, NFB2) #3 Remove: M3x6 (x4) 1200_300019.ai 1200_300018.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-11 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 125: Cooling Fan (Fan1

    The cooling fan (FAN1) is for exhaustion. Check the arrow indicating the direction of the air engraved on the fan before putting the fan on the fan cover. DETAIL A 1200_300014.ai 1200_300016.ai MC-12 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 126: Power Supply Unit

    #1 Disconnect: Cable connectors (CN1, CN51) Power supply unit #2 Remove: M3x6 (x5) #3 Draw out: Power supply unit VR51 600_300177.ai 1200_300017.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-13 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 127: Switch Cover

    Reinstallation Procedures Reverse the removal procedures for reinstallation. u NOTE u Align the tabs on the switch cover with the notches on the front cover. Switch cover Front cover 1200_300079E.ai MC-14 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 128: Outlet

    Outlet 1200_300080E.ai REFERENCE The outlet is installed in the MP with the tabs (two places on the right side and one place on the left side) directed toward the outlet's opening. MC-15 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 129: Ac Bucky Relay Unit (Optional

    Identify the model before replacing the relay. Hook {MD:1.3.4_Board-Related Information} 600_300039.ai n Removal Procedures n Reinstallation Procedures (1) Remove the AC bucky relay unit. #1 Disconnect: Relays Reverse the removal procedures for reinstallation. 1300_300023.ai MC-16 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 130: Replacing The Mp Whose Local Ip Address Is Changed

    (5) Click [Setting for MP1]. The confirmation dialogue box of “Are you sure?” appears. (6) Click [OK]. (7) Click [MP Network Setting >>] on the Network Setting window. The MP Network Setting >> window appears. MC-17 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 131 It is not necessary to change the IP address of the SE. (2) Restore the respective data which has been backed up. - CONFIGURATION - HISTORY LOG - CORRECT ALL DATA {MU2:1.14_RESTORE} MC-18 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 132: Se (Flat Panel Sensor

    - Remove the SE cover where there is no dirt or dust around the machine. - Follow the same procedures as those for installation when the SE is to be replaced with a new one. MC-19 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 133: Se (1305Se

    SE rear cover, and place a shock absorbing member for protecting the exposure plane. LED65C board LED65B board POW65A board RMV65A board POD65A board COC65A board 1300_300004.ai Shock absorber 1300_300007.ai MC-20 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 134: Pow65A Board

    You can remove any of the TOP, CENTER and BOTTOM covers as needed. n Reinstallation Procedures Reverse the removal procedures for reinstallation. POW4 POW65A board POW6 POW5 POW2 POW3 POW1 POW9 POW7 1300_300009.ai MC-21 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 135 KMC05 Chip fuse Daito Communication Apparatus Co. Ltd. 6-12V 1200_300004.ai Charging ON/OFF Charge/Select BQ24171 BAT: 6-8A ADAS 2.5V GLG: 9V 3.3V RMV: 3.3V 1200_300214.ai n Handling Fuse Failures Change the board. MC-22 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 136: Rmv65A Board

    - The cable connectors of RMV4 on the RMV65A boards for the TOP and BOTTOM panel units are hidden under the harness, so remove the boards before removing the cable connectors. MC-23 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 137 (8) Restore the calibration data. {MU2:1.14_RESTORE} (9) Perform the forced transfer of the SE correct data and check the SE correct data save status. {IN2:10.13_Forced Transfer of the SE Correct Data} (10) Restart the MP. MC-24 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 138 Chip fuse Daito Communication Apparatus Co. Ltd. ADAS KMC20 Chip fuse Daito Communication 2.5V Apparatus Co. Ltd. FPGA CPU, UART 3.3V CLK, Ether 1200_300218.ai n Handling Fuse Failures Change the board. MC-25 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 139: Led65B Board

    #1 Remove: M2.6x3 (x2) #2 Disconnect: Cable connectors (LED1) #2 Disconnect: Cable connectors (LED1) 1300_300011.ai 1300_300024.ai n Reinstallation Procedures n Reinstallation Procedures Reverse the removal procedures for reinstallation. Reverse the removal procedures for reinstallation. MC-26 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 140: Coc65A Board

    Apparatus Co. Ltd. COC1 COC7 n Handling Fuse Failures COC3 F1: Change the board. F2: Change the fuse. COC4 COC9 COC65A COC8 board 1300_300025.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. MC-27 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 141: Pod65A Board

    {MC:3.1.1_SE Rear Cover} (2) Remove the POD65A board. #1 Disconnect: Cable connectors (POD1 to POD10) #2 Remove: M2.6x3 (x4) POD8 POD1 POD2 POD3 POD7 POD6 POD10 POD9 1300_300003.ai POD5 POD4 1300_300012.ai MC-28 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 142: Hub

    F2 to F8, F12: Change the board. F11: Change the fuse. 1300_300013.ai u NOTE u Do not remove the attached black shading tape because the LED light source of HUB may affect images. MC-29 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 143: D-Sub Connector

    Fix the HUB using the screws for the BOTTOM cover at the two locations at the top. Align the HUB to the upper right bracket shown in the figure below. {MC:3.1.1_SE Rear Cover} (2) Disconnect the cable connector for the HUB. For the TOP side: Cable connector (HUB1) For the BOTTOM side: Cable connector (HUB5) 1300_300014.ai HUB5 HUB1 1300_300015.ai MC-30 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 144 For the TOP side: Cable connector (POD1) #1 Unclump: Clumps For the BOTTOM side: Cable connector (POD8) #2 Remove : Hexagon-headed bolt (x2) POD8 POD1 1300_300017.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. 1300_300016.ai MC-31 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 145: Led Connector

    (2) Disconnect the cable connector for the POD65A. For the TOP side: Cable connector (POD10) For the BOTTOM side: Cable connector (POD9) 1300_300019.ai n Reinstallation Procedures Reverse the removal procedures for reinstallation. POD10 POD9 1300_300018.ai MC-32 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 146: Replacing The Se Whose Local Ip Address Is Changed

    Changing the Local IP Address (1) Return the local IP address of the SE/MP/MC to the original value (value before changed to the default value). {IN:Appendix 3._Replacement Procedure of the Local Network} MC-33 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 147: List Of Tools

    Qty.: 1 Combination box-open-end wrench (7 mm) Combination box-open-end wrench (8 mm) Remarks: Remarks: Reference type: M41-7 Reference type: M41-8 Reference manufacturer: Reference manufacturer: 600_300090.ai Qty.: 1 Qty.: 1 Remarks: Remarks: 600_300091.ai MC-34 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 148 Reference type: P-95 Reference manufacturer: Reference manufacturer: Reference manufacturer: Reference manufacturer: Any commercially available one HAKKO MATSUSHITA ELECTRIC HOZAN Qty.: 1 Qty.: 1 Qty.: 1 Qty.: 1 Remarks: Remarks: Remarks: Remarks: 600_300092.ai 600_300093.ai MC-35 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 149: Special Tools And Measuring Instruments

    Reference manufacturer: - Reference manufacturer: - Reference type: Kimwipe Reference manufacturer: Qty.: 1 Qty.: 1 CRECIA Remarks: For 1kg. Remarks: Calibration required Qty.: 1 Inspection and calibration required Remarks: 600_300094.ai 600_300095.ai MC-36 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 150: Special Consumables

    Qty.: 1 Qty.: 2 Qty.: 1 Remarks: Remarks: Remarks: Remarks: 600_300097.ai Polyimide tape Reference type: No.5412 Reference manufacturer: 3M Qty.: 1 Remarks: For retaining the cables in the SE. 308S0086 1300_300021E.ai MC-37 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 151 MC-38 BLANK PAGE MC-38 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 152 MC-39 BLANK PAGE MC-39 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 153: Appendix 1. Updating/Downgrading Mp Os Version

    The appropriate version of the MP OS is indicated in Readme.txt in the MP OS media. Readme.txt <Display example> New MP Kernel ver MP1 Version Check>>window Old MP Kernel ver 1200_300179.ai 1200_700092E.ai AppxMC1-1 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 154: Appendix 1.2 Updating Mp Os Version

    <Shift> key to terminate the DX Console application and the MC application. 1200_300166.ai The Command Prompt window appears. (3) Press the <Enter> key. 1200_300167.ai (4) Enter the MP IP address (192.168.0.20) and press the <Enter> key. 1200_300168.ai AppxMC1-2 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 155 OFF, the data on the HDD gets damaged, and the MP cannot boot up as a result. DX Console and restart the system. (9) Check the MP OS version. {MC: Appendix 1.1_Checking the MP OS Version} AppxMC1-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 156: Appendix 1.3 Downgrading Mp Os Version

    While write into the HDD is in progress, never turn OFF the MP power. If turned OFF, the data on the HDD gets damaged, and the MP cannot boot up as a result. AppxMC1-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 157 (8) Remove the MP OS Installer Ver. 1.0 media from the DVD drive for the DX Console and restart the system. (9) Check the MP OS version. {MC: Appendix 1.1_Checking the MP OS Version} AppxMC1-5 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 158 When there are multiple “cdrom*”, even if the “mount” command is successful, the “cd” command may fail. 1200_300176.ai 1200_300173.ai In this case, specify the other “cdrom*” after restarting the MC, then execute the “mount” command. AppxMC1-6 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 159 AppxMC1-7 BLANK PAGE AppxMC1-7 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 160 AppxMC1-8 BLANK PAGE AppxMC1-8 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 161: Appendix 2. Installing The New Hub Replacement Kit

    HUB (AT-FS710/5E): 1, HUB power cable: 1 power cable. HUB mounting positioning spacer Mounting screw 22 For mounting the rear cover Rear cover HUB mounting part spacer Used to connect the rear cover and the HUB AppxMC2-1 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 162 For the HUB mounting part, use the rear cover HUB mounting part spacer the same way as for the old HUB. (8) After the installation is completed, confirm that it operates normally. AppxMC2-2 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 163 AppxMC2-3 BLANK PAGE AppxMC2-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 164 AppxMC2-4 BLANK PAGE AppxMC2-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 165 3, 16, 43 to 52, 72, 78 to 80, 83, 84 17 to 42, 53 to 71, 73 to 77, 81, 82, 03.31.2020 Changes in pagination (FM9623) 85 to 99 Service Manual Maintenance Utility (MU1) (DR Maintenance Software) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 166: Dr Maintenance Software

    Before starting up the DR Maintenance Software, check that the network cable connections and the network settings are completed. The DR Maintenance Software is a tool for exclusive use of the service engineer to For mobile configurations, check that the FUJIFILM AP is connected. set and check the RU functional conditions by the operation from the CL. The “OPERATION” and “INSTALLATION” exist for the DR Maintenance Software. In this manual each of the functions in the “OPERATION” are explained.
  • Page 167 [Internet options]. 1200_700565E.ai (2) Change the address in the “Home page” field to the following address, click [Use current], and then click [OK]. 1200_700566E.ai DR Maintenance Software address is registered to homepage. MU1-2 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 168 {1.10.1_SE Correct Data Backup/Restore} {1.5_NETWORK SETTING} {1.10.2_CALNEO GL Panel Correct Data Backup/Restore} {1.5.1_Local Network} {1.10.3_DR-ID 1422SE Correct Data Back up/Restore} {1.6_CHECK DEVICE STATE} {1.10.4_Config Setting Backup/Restore} {1.6.1_Check Version} {1.10.5_HISTORY Backup} {1.6.2_Check Board Status} {1.10.6_LOG Backup} MU1-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 169: Update Software

    Select the target SE from the drop-down list box. (3) Click [GET]. Update SE appears. (4) Confirm the “Current Version” and the “Updated Version”. If “Updated Version” is newer, click [INSTALL]. All of the target SE software is updated with the updated version. MU1-4 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 170: Panel Setting

    (1) Click “PANEL SETTING” - “SE Registration/Deletion”. The SE Registration/Deletion window opens. (2) Click [Add]. The Panel Registration window opens. (3) Input the serial ID and click [OK]. 1200_400055E.ai The serial ID of the SE is registered. MU1-5 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 171: Se Wireless Setting

    (2) Select the target SE from the drop-down list box. (3) Click [OK]. (3) Click [GET] in the “SE Country Code Display”. The SE Registration is deleted. The SE Country Code will be displayed. MU1-6 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 172: Led Color Setting

    - DR-ID 613SE: 4000msec or less. The selector color is registered. u NOTE u Restart the SE when the selector color is registered. The selector color registration will be reflected in the SE after restart. MU1-7 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 173: Memory Mode Setting

    In the Read Mode (read mode setting), set the Read Mode for memory exposure in addition to the routine exposure.Any of “0”, “1” or “2” can be inputted into [Read Mode]. 1300_410014E.ai MU1-8 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 174 (1) Click “PANEL SETTING” - “CALENO GL Panel Registration/Deletion”. The CALENO GL Panel Registration/Deletion window opens. (2) Click [Del] for the corresponding SE. The Panel Deletion window opens. (3) Click [OK]. The CALENO GL Panel Registration is deleted. MU1-9 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 175: Config Setting

    MU1-10 CONFIG SETTING u NOTE u If the current values are not displayed, click [Refresh]. In accordance with the device usage configuration, the registered RU system configuration information can be checked and changed. The information whose settings have been changed is written on the HDD. 1200_400061E.ai MU1-10 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 176: Mc Setting

    (3) Left-click the MC Manager from the task tray and execute “EXIT”. Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. REFERENCE The settings become effective after restart of the MC. 1200_400062E.ai MU1-11 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 177 Specifies to which MP the X-ray shot cable corresponding to the operative method  MC ID CODE [Stand] of the X-ray equipment is to be connected. <Options> Check just the SEs shared via multiple MCs when connected to FUJIFILM APs. - None: Not connected The “MC_ID_MODE” checks that other MCs are not redundant, and makes changes if - MP1 [default]: Connected to MP1 they are redundant.
  • Page 178 Three SEs connected - 4: Four SEs connected - 5 [default]: Five SEs connected u NOTE u - For connecting one long panel, select “1”. - For connecting two long panels, select “2”. MU1-13 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 179 1: FIXED MODE 500 msec 500 msec Usually select this mode. (500 ms) [default] or less 2: FIXED MODE 1200 to 3800 1200 to 3800 Image quality might degrade for low dose (1200 ms) msec (*) msec exposures. *: Charge accumulation time is set in “MODE2 EXPOSURE TIME”. MU1-14 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 180 If setting to “OFF”, does not activate monitoring of the battery. which AcSelarete or CALNEO U/T is connected. If setting to “ON”, activates monitoring the battery. Usually, use the setting of NOT CONNECTED [default]. <Options> - NOT CONNECTED [default] - CONNECTED MU1-15 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 181 The X-ray irradiation time is often stopped by a signal from the MP due to communication delays, which shortens the exposure time. To ensure the irradiation time, set the SHOTGO OFF DELAY TIME value to around “the shortage of time + 10” MU1-16 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 182 - If [FPD-C] is registered in any selector, always carry out the following operations. - Connect the free X-ray shot cable to the MP. - Specify the destination of connection via the Maintenance Software in [OPE SETTING (FREE)] and [PORT SETTING (FREE)]. MU1-17 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 183: Ru Image Flag

    1213SE / 1214SE).  IMAGE READING MODE u NOTE u 1200_400064E.ai For the DR-ID 1300 series SE, this setting is disabled. (1) Click “CONFIG SETTING” - “RU Image Flag”. The RU Image Flag window opens. Selects the image compensation processing mode.
  • Page 184 Select whether or not the blemish/unevenness correction is to be performed. <Options> - OFF: Not performed - ON [default]: Performed  T2 TIMER(sec) Set the start time (sec) of the calibration executed in the background. When the exposure has been completed, the calibration begins after the time elapsed that was set. - Character string: [default: 120] MU1-19 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 185: Wireless Setting

    (3) Left-click the MC Manager from the task tray and execute “EXIT”. Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. REFERENCE The settings become effective after restart of the MC. 1200_400065E.ai MU1-20 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 186 Select the same settings for the AP. GHz. All of the channels can be used indoors. {IN1:10._Installing the RU Software} - When selecting 2.4 GHz on the FUJIFILM-made AP, select 20 MHz on the “Channel {IN2:10._Installing the RU Software} Width”. Do not select 40 MHz.
  • Page 187 • OFF [default]: Not used <Settable range> • ON: Used - 12-character string [default: 000000000000] REFERENCE - Image transfer is to be encrypted only for wireless communications. - This setting does not cover the 601SE/602SE/611SE/612SE/613SE. MU1-22 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 188: Se Sleep Mode Setting

    (3) Left-click the MC Manager from the task tray and execute “EXIT”. Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. 1200_400066E.ai REFERENCE The settings become effective after restart of the MC. MU1-23 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 189 - After all the SEs shift to the sleep mode and past the set time by this setting, shift to the extra sleep mode. - When set to “999”, do not shift to the extra sleep mode. MU1-24 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 190: Calibration

    MU1-25 CALIBRATION 1.4.1 SE Calibration u NOTE u For the DR-ID 1300, perform the following calibration. {MU1:1.4.2._Long Panel Calibration} Used to make the following calibration on the SE. Refer to the Installation manual for the detailed procedures. {IN1:11._Image Calibration} {IN2:11._Image Calibration}...
  • Page 191 Whether the diagnosis is successfully completed appears on the result display area. An error code is displayed in some cases. Refer to the Troubleshooting manual and take appropriate countermeasures. (2) Click [OK]. 1200_400069E.ai MU1-26 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 192 INSTRUCTION u Set the exposure time to 200 msec or less. Exposure for longer than 200 msec cannot be made, since the maximum exposure time is inherently specified as 200 msec. MU1-27 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 193 Carries out defect calibration. u NOTE u - Exposure count: 5 If “NG” appeared, check the following. - Exposure condition - Exposure field is the entire SE. u NOTE u If the calibration failed, restart the MC. (4) Click [OK]. 1200_400071E.ai MU1-28 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 194 As a result, because the number of the defects becomes an erroneous value and the defect size is increased more than expected, a calibration error may occur. When the defect correction data is automatically generated and stored in the HDD, “Succeeded” appears after completion. MU1-29 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 195 INSTRUCTION u Set the exposure time to 200 msec or less. Exposure for longer than 200 msec cannot be made, since the maximum exposure time is inherently specified as 1200_400072E.ai 200 msec. MU1-30 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 196: Long Panel Calibration

    SETTING , a warning message is displayed to indicate that the data transfer rate is slow. Set the FIPS MODE to “OFF” or perform the calibration after wire-line connecting the SE. MU1-31 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 197 The offset calibration takes place for all of connected SE’s. 1300_410001E.ai (1) Click “CALIBRATION” - “Long Panel Calibration”. The Long Panel Calibration window opens. (2) Select the target SE from the drop-down list box. (3) Implement each calibration. 1300_410069E.ai MU1-32 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 198 Whether the diagnosis is successfully completed appears on the result display area. An error code is displayed in some cases. Refer to the Troubleshooting manual and take appropriate countermeasures. (2) Click [OK]. 1300_410070E.ai MU1-33 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 199 INSTRUCTION u Set the exposure time to 200 msec or less. Exposure for longer than 200 msec cannot be made, since the maximum exposure time is inherently specified as 200 msec. MU1-34 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 200 As a result, because the number of the defects becomes an erroneous value and the defect size is increased more than expected, a calibration error may occur. When the defect correction data is automatically generated and stored in the HDD, “Succeeded” appears after completion. MU1-35 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 201 NOTE u  Lag Calibration If “NG” appeared, check the following. Carries out lag calibration. - Exposure condition - Exposure count: 1 - Exposure field is the entire SE. (4) Click [OK]. 1300_410072E.ai MU1-36 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 202 INSTRUCTION u Set the exposure time to 200 msec or less. Exposure for longer than 200 msec cannot be made, since the maximum exposure time is inherently specified as 200 msec. MU1-37 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 203 - Installing the Calibration Phantom - Exposing Calibration - Creating Calibration Data and Checking Result - Changing the Calibration Position and Exposing Calibration - Checking the Image Composition Accuracy {IN1:12._Marker Calibration} 1300_410006E.ai MU1-38 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 204: Sensitivity Correction Coefficient

    The SE software will be updated with the updated version. After execution of calibration, the actually measured value min us the offset value is stored in the log as the measured value. MU1-39 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 205: Se Correct Data Transfer

    (1) Click “CALIBRATION” - “SE Correct Data Transfer”. The SE Correct Data Transfer window opens. (2) Select the target SE from the drop-down list box. (3) Implement the correction data processing. MU1-40 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 206 Depending upon the saving status, the following will be displayed. Verify that transferring has completed. “PROCESSING” “COMPLETED” “TRANSFER FAILED” If the transferring failed, then re-implement a forced transfer of the correction data. (2) Confirm the correct data save status. MU1-41 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 207 - If the initialization calibration has not been completed, “false” is displayed. 1200_400079E.ai (1) Click [GET]. The list of FLASH correct data is displayed . (2) Confirm the correction data’s (FLASH) saving conditions. list of MU1-42 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 208: Line Defects Data Registration

    The images can also be collected by also implementing the DX image pickup tools which are distributed by the ECN. If the DX image pickup tools are usable, then use the DX image pickup tools. III. 1200_400062E-1.ai MU1-43 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 209 - Click “File” - “Import” - “Raw”, select the image data (std file) (# 1), and click White is zero: Check ON [Open] (# 2). Little-endian byte order: Check ON POCX01020D007.ai POCX01020D008.ai Pixel values for each SE size when reading raw data SE size Width Height 17 x 17 2832 2836 14 x 17 2336 2836 10 x 12 1648 1980 24 x 30 1536 1920 MU1-44 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 210 No good example) No good example) If the Image Type is incorrect If the SE size pixel values are incorrectly input Read at 8 bits 17x17 is read at 14x17 1200_400171.ai POCX01020D010E.ai MU1-45 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 211 (9) Start the DR Maintenance Software. (10) Select the “OPERATION” - “CALIBRATION” - “SE Correct Data Transfer”. (11) Select the target FPD and execute “SE Correct Data Forced Transfer”. {MU1:1.4.5_SE Correct Data Transfer} 1200_700567.ai MU1-46 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 212 If the line defects with 3 or more lines continue in both the vertical and horizontal directions, or if the intervals between the line defects are 3 lines or less, a 12231 error will occur. MU1-47 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 213: Long Panel Line Defect Data Registration

    {MU1:1.4.6_Line Defects Data Registration}_“ Identify the line defect locations” coordinates which were confirmed via ImageJ. REFERENCE Up to five vertical line defects, and up to five horizontal line defects can be simultaneously registered. (4) Click [Set]. 1300_410016E.ai MU1-48 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 214: Dual Panel Line Defect Data Registration

    (10) Select the “OPERATION” - “CALIBRATION” - “SE Correct Data Transfer”. (11) Select the target FPD and execute “SE Correct Data Forced Transfer”. {MU1:1.4.5_SE Correct Data Transfer}  Operation check {MU1:1.4.6_Line Defects Data Registration}_“ Operation check” MU1-49 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 215: Point Defect Specifications Excess Area Display

    The FPD that can be selected here is the FPD whose logs are registered in the MC, not the FPD which is currently connected. (2) Click [Acquire]. 1200_700569.ai The registered point defects are displayed. The point defects which exceed the point defect agglutination specifications are displayed via “□”. The point defects which exceed the point defect size specifications are displayed via “X”. MU1-50 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 216: Long Panel Point Defect Specifications Excess Area Display

    The FPD that can be selected here is the FPD whose logs are registered in the MC, not the FPD which is currently connected. (3) Click [Acquire]. 1300_410017E.ai The registered point defects are displayed. The point defects which exceed the point defect agglutination specifications are displayed via “□”. The point defects which exceed the point defect size specifications are displayed via “X”. MU1-51 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 217: Dual Panel Point Defect Specifications Excess Area Display

    MU1-52 1.4.11 Dual Panel Point Defect Specifications Excess Area Display u NOTE u Not used in the DR-ID 1300. MU1-52 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 218: Network Setting

    The default value of the subnet mask of the machine is 255.255.255.0, and locations assigned by 255 (mask value areas) indicate the network address. ETH0 Segment No. 172.16.1.20 DRID600_G0142.ai 192.168.0.0 Network address Host address DRID600_G0070.ai MU1-53 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 219: Local Network

    If the segment No. of the network address is changed, the network address of the access point (AP) must be changed to include the same segment No. If the network address of the access point differs, wireless connection of the SE cannot be made. 1200_400111E.ai MU1-54 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 220 SE. (8) Reinstall the SE cable and battery pack on the SE whose setting has been completed. 1200_400112E.ai MU1-55 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 221 (4) Left-click the MC Manager from the task tray and execute “EXIT”. need of initializing the machine. Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. 1200_400113E.ai MU1-56 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 222 The MP2 IP address which was input via “Changing the MP’s IP addresses (presets)” will be enabled, and at the same time MP1 will be set as MP2. (6) Turn OFF the power of the MP, and then turn it ON again. MU1-57 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 223 MP and the MC normally ends. This is because connection of The IP Address of the MC will be updated. the SE can be confirmed only when connection between the MC and the MP is normal. MU1-58 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 224: Check Device State

    (1) Click “CHECK DEVICE STATE” - “Check Version”. (3) Click [GET]. The Check Version window opens. The MP Version are displayed . (2) Check the version in “Check MC Version”. (4) Confirm the “Current Version”. MU1-59 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 225 (1) Click “CHECK DEVICE STATE” - “Check Version”. The Check Version window opens. (2) Select the target SE in “Check SE Version” from the drop-down list box. (3) Click [GET]. The SE Version are displayed. (4) Confirm the “Current Version”. MU1-60 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 226: Check Board Status

    (when connected with the MPC board’s MPC7 connector cable) Defective: Other than above. - Fan Status: The status of the fan connected with the MP board appears. Normal: Fan Status: true Defective: Other than above. MU1-61 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 227 The Check Board Status window opens. (2) Select the target SE in “Check SE Board Status” - “Board Status” from (4) Check the board states, and click [Cancel]. the drop-down list box. MU1-62 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 228 Battery Status : true (when there is a battery) MCU Status : true SDCard Status : true Defective: Other than above. - Temperature Displays the temperature of the stand SE. Display example: Temperature = 29.4 deg C MU1-63 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 229 If the battery usage start day has been set, and it is successful, a pop up window displaying “Succeeded” will pop up. (4) Click [OK]. 1200_400087E.ai (1) Click “CHECK DEVICE STATE” - “Check Board Status”. The Check Board Status window opens. MU1-64 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 230 (3) Click [START]. If the GLG board self-diagnostic has been started, and it is successful, a pop up window displaying “Succeeded” will pop up. (4) Click [OK]. MU1-65 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 231: Se Wireless Setting

    - DR-ID 613SE: 4000msec or less. 1200_400090E.ai (1) Click “CHECK DEVICE STATE” - “SE Wireless Setting”. The SE Wireless Setting window opens. (2) Select the target SE from the drop-down list box. MU1-66 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 232: Battery Information

    Serial No. of the batteries are displayed. (3) To delete the battery serial no., click [–], and click the [OK] in the pop up window. Serial No. of the batteries are deleted. MU1-67 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 233: History

    To fix the “Start Date” input values, click [SET] at the bottom of the screen, and the MC Manager needs to be restarted (if configured whereas the MC application is installed on the MC computer, then turn OFF the MC’s main power breaker). MU1-68 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 234: Upright

    <20, 20-23, 23-26, 26-28, 28-30, 30< The information will be changed. (3) If the history is to be deleted, click [DELETE], and click [OK] in the pop up window. The history is deleted. 1200_400096E.ai MU1-69 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 235: Table

    <20, 20-23, 23-26, 26-28, 28-30, 30< The information will be changed. (3) If the history is to be deleted, click [DELETE], and click [OK] in the pop up window. The history is deleted. 1200_400097E.ai MU1-70 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 236 (3) If the log history is to be deleted, click [DELETE] at the bottom of the window, and click [OK] in the pop up window. The log history will be deleted. MU1-71 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 237: Utility

    The Terminate MC window opens. (2) Click [START]. If the MC computers are shut down, and it is successful, a pop up window displaying “Succeeded” will pop up. (3) Click [OK]. MU1-72 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 238: Reboot Mc

    Reboot the MC Manager, and if it succeeds, “Succeeded” will be displayed in the 1200_400099E.ai (1) Click “UTILITY” - “Terminate MC”. pop up window. The Terminate MC window opens. (3) Click [OK]. (2) Click [START] in the “Reboot MC” Reboot the PC. MU1-73 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 239: Web Maintenance Status

    PING is implemented, and the confirmation results are displayed in the pop up window. 1200_400103E.ai u NOTE u If the communications verification is normal, “Succeeded” will be displayed. When it fails, since “Failed” will be displayed, check the network connections. (3) Click [OK]. MU1-74 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 240: Check Ftp

    (2) To change the setting values, input the “Updated Value”, and click [SET] 1200_400104E.ai (1) Click “UTILITY” - “Check FTP”. at the bottom of the window. The Check FTP window opens. (2) Click [START]. The confirmation results are displayed in the pop up window. 1200_400105E.ai (3) Click [OK]. MU1-75 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 241: Force Serial Id Writing

    (2) Input the new SE serial ID, and click [SET]. The force serial ID writing will be implemented, and the implemented results are displayed in the pop up window. (3) Click [OK]. (4) Reboot the SE. MU1-76 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 242: Replace Long Panel Rmv Board

    (1) Click “UTILITY” - “Replace Long Panel RMV Board”. The Replace Long Panel RMV Board window opens. (2) Select the target SE (Panel units) from the drop-down list box. (3) Click [START] in the “Install Communication File” The communication setting file will be installed on the RMV board. MU1-77 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 243: Update Se Cpu (0X0220)

    The SE’s CPU version is upgraded, and the implementation results are displayed on the pop-up screen. (4) Click [OK]. u INSTRUCTION u After the above is completed, manually upgrade the SE software version via the following procedures. {MU1:1.1.2_Update SE} MU1-78 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 244: Update Se Fpga

    0x00B8 {MU1:1.1.2_Update SE} DR-ID 1214SE 0x00C8 If the FPGA version of the SE is earlier than these, use “Upgrading the SE FPGA” to install an in-between version of FPGA software. 1200_400134.ai MU1-79 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 245: Replace Mp

    (2) If the address is to be changed, input “Updated Value” in the MC ETH1 (2) To change the Network Address Field and the MC Subnet Mask, Network Setting window, and click [SET]. change the input values. The address of the MC will be updated. MU1-80 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 246 Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. (4) Left-click the MC Manager from the task tray and execute “EXIT”. Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu” → “Start-up”. MU1-81 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 247 The MP2 IP address which was input via “Changing the MP’s IP addresses (presets)” will be enabled, and at the same time MP1 will be set as MP2. (6) Turn OFF the power of the MP, and then turn it ON again. MU1-82 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 248: Led Color Rgb Setting

    The battery reserve threshold values will be changed. u NOTE u Restart the SE when the selector color is registered. The selector color registration will be reflected in the SE after restart. MU1-83 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 249: Force Charge The Battery

    MU1-84 1.9.15 Force Charge the Battery u NOTE u Not used in the DR-ID 1300. MU1-84 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 250: Backup/Restore

    If it is a system which includes the DR-ID 1200, execute these procedures for the - SE Correct Data Correct Data Backup/Restore. For 1 image: YYYYMMDDhhmmss- (Panel ID).ZIP For the DR-ID 1300, execute the Correct Data Backup/Restore as per the following. For an SE batch: YYYYMMDDhhmmss-PANELS.ZIP {MU1:1.10.2._CALNEO GL Panel Correct Data Backup/Restore} - MC Configuration Data YYYYMMDDhhmmss-MC-CONFIG.ZIP...
  • Page 251 The backing up is implemented, and when it is completed the pop up window opens. (4) Click [SAVE]. The backup file saving is completed. u NOTE u The backup files will be saved in the “Downloads” folder by default. File name: YYYYMMDDhhmmss-PANELS.ZIP (5) Click [Open folder]. The backup file will be displayed. MU1-86 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 252 (5) Click [OK]. 1200_400122E.ai (1) Click “BACKUP/RESTORE” - “SE Correct Data Backup/Restore”. The SE Correct Data Backup/Restore window opens. (2) Click [Restore] the target SE. The correction data restore window is displayed. 1200_400123E.ai MU1-87 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 253 (1) Click “BACKUP/RESTORE” - “SE Correct Data Backup/Restore”. The SE Correct Data Backup/Restore window opens. (2) Turn ON the target SE checkbox. (3) Click [Restore Package]. The correction data restore window opens. 1200_400126E.ai MU1-88 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 254: Calneo Gl Panel Correct Data Backup/Restore

    The CALNEO GL Panel Correct Data Backup/Restore window opens. (2) Click [Backup] of the target Panel unit. The backing up is implemented, and when it is completed the pop up window will be displayed. MU1-89 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 255 The correction data restore window is displayed. (3) Click [SAVE]. The backup file saving is completed. u NOTE u The backup files will be saved in the “Downloads” folder by default. File name: YYYYMMDDhhmmss-PANELS.ZIP 1200_400123E.ai (4) Click [Open folder]. The backup file will be displayed. MU1-90 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 256 (1) Click “BACKUP/RESTORE” - “CALNEO GL Panel Correct Data Backup/ Restore”. The CALNEO GL Panel Correct Data Backup/Restore window opens. (2) Click [Restore Package]. The correction data restore window opens. 1200_400126E.ai MU1-91 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 257: Dr-Id 1422Se Panel Correct Data Backup/Restore

    The restoring is implemented, and if it completed, “Succeeded” will be displayed in the pop up window. (4) Click [OK]. u NOTE u To implement the SE correction data forced transferring, implement each SE. MU1-92 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 258: 1.10.4 Config Setting Backup/Restore

    (2) Click [Backup]. (3) Click [SAVE]. The backup file saving is completed. u NOTE u 1200_400129E.ai The backup files will be saved in the “Downloads” folder by default. File name: YYYYMMDDhhmmss-MC-CONFIG.ZIP (4) Click [Open folder]. The backup file is displayed. MU1-93 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 259: History Backup

    (2) Click [Backup]. (3) Click [SAVE]. The backup file saving is completed. u NOTE u The backup files will be saved in the “Downloads” folder by default. File name: YYYYMMDDhhmmss-MC-STATISTIC.ZIP (4) Click [Open folder]. The backup file is displayed. MU1-94 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 260: Log Backup

    Folder name: CONFIG Communication log between the CL and the Folder name: CONSOLE File name: CONSOLE.LOG 1200_400132E.ai Panel drop/impact log Folder name: GLG When the following execution file is copied into the folder where the log file is saved and is double-clicked, a file converted to a viewable format is generated in the same folder (file name after conversion: GLG_[file name before conversion]). C:¥ProgramFiles¥FujiFilm¥FCR¥DR- ID1200¥SYSTEM¥COMMON¥GLG.exe MU1-95 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 261 Folder name: LP_IMAGE Not used in the machine. Folder name: ES_IMAGE u NOTE u Refer to the following for further details on the CALIBRATION LOG files, and GLG log files. {MT:5._BACKUP FILE} MU1-96 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 262 The operative method for exposure and the panel to be used are determined based on the CSL setting (not depending on the connector (MPC6 or 7) to which the panel is connected). DRID600_G0139E.ai MU1-97 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 263 MU1-98 BLANK PAGE MU1-98 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 264 MU1-99 BLANK PAGE MU1-99 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 265: Maintenance Utility (Mu)

    Pages affected 03.31.2016 New release (FM9369) All pages 06.30.2017 Revison for MC V15 (FM9473) 4, 33, 42, 57, 68, 69 DR-ID 1300 / DR-ID 1300PU Service Manual Maintenance Utility (MU2) (RU PC-TOOL) 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 266: Pc-Tool

    I/O TRACE EXPERT ERROR DB {1.12_EDIT CL NAME} ALL RUs SETTING {1.13_BACKUP} UNINSTALL VERSION UP {1.14_RESTORE} DRID600_G0001.ai {1.15_I/O TRACE EXPERT} {1.16_ERROR DB} {1.17_UNINSTALL (All RUs)} {1.18_VERSION UP (All RUs)} {1.19_Configuration} {1.19.1_CDPath} MU2-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 267 - Updating SE Application Software Version Install >> Install SE Software >> Install SE FPGA Software, Install SE LAN Software and Install SE MCU Software DRID800_G0143.ai DX Console (FTP Server) folder Flash Flash Memory Memory DRID600_G0062.ai MU2-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 268 ... #1 [Click] ... Configuration C EACH RU SETTING CONNECTION TEST LIST OF EXISTING RU RU NAME RU IP ADDR BACKUP RESTORE ALL RUs SETTING DRID600_G0002.ai l Exiting the PC-TOOL (1) Click located in the upper right corner of the Main Screen of the PC- TOOL. MU2-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 269: New

    1300_400001.ai LIST OF EXISTING RU RU NAME RU IP ADDR CONNECTION TEST (2) Exit the RU PC-TOOL. (3) #1 BACKUP RESTORE RU NAME (3) #2 RU IP ADDR ALL RUs SETTING DRID600_G0003.ai (4) Exit the RU PC-TOOL. MU2-4 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 270: Delete

    Configuration C EACH RU SETTING CONNECTION TEST LIST OF EXISTING RU RU NAME RU IP ADDR DELETE BACKUP RESTORE ALL RUs SETTING 1300_400002.ai (4) Exit the RU PC-TOOL. 1300_400003.ai l Exiting the MUTL (1) Click in the upper right corner of the MUTL window. (2) Exit the RU PC-TOOL. MU2-5 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 271 - BOARD STATE CHECK - Board version indication type - CALIBRATION Displays the version of the selected board. - SYSTEM - Exposure count indication type Displays the number of exposures in progress (exposure count). MU2-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 272 {[1.7]_Wireless Speed Measurement>>} NEXT>> SE1-10>> SE51-55>> Measurement for using SE1 SE51 WIRED SE51 WIRELESS Measurement for using SE10 SE55 WIRED SE91-100>> SE55 WIRELESS {[2]_SE SETTING} {[2.1]_SE Registration>>} SE96-100>> SE1-10>> {[1.2]_SE Network Setting>>} SE1 Serial ID Connected SE Serial ID Connected SE Number MU2-7 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 273 Center SE Serial ID Offset2 Bottom SE Serial ID Image Reading Mode {[2.4]_LongPanel DELETE>>} Read Mode LongPanel 1>> {[2.8]_SE LED Color Setting>>} Top SE DELRTE Create LED Color>> Center SE DELRTE PINK>> Bottom SE DELRTE LongPanel 2>> Top SE DELRTE Center SE DELRTE BLUE>> Bottom SE DELRTE {[2.5]_BATTERY INFORMATIOIN>>} MU2-8 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 274 Insatall SE FPGA Software Display MC ALPS Version Insatall SE GLG Software {[3.2]_MP Version>>} Insatall SE LAN Software {[3.2.1]_MP1 Version Check>>} Insatall SE MCU Software Display MP1 Software Version {[5]_BOARD STATE CHECK} Display MP1 Kernel Version {[5.1]_MP Board State>>} Display MP1 ALPS Version {[5.1.1]_MP1 Board State>>} Display MP1 Driver Version Connector Status {[3.2.2]_MP2 Version Check>>} Fan Status MU2-9 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 275 Progress Indicator GLG Check Display ShotRdy GLG Calibration>> Create a Defect Data Get X axial Offset {[6.4]_Lag Calibration>>} Get Y axial Offset Input SE No. [1-100] Get Z axial Offset SE Serial ID Save Offset Data Operation Setting {[5.3]_SE Write SerialID>>} Start {[5.4]_LongPanel RMV Board Change>>} Display Progress Status Input SE No. [1-100] Display ShotRdy Install SE NetSel File Create a Lag Data Extra Sleep MU2-10 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 276 Center SE Serial ID Bottom SE Serial ID Operation Setting Calib Position Start Display Image Count Display ShotRdy Create a Marker Data {[6.6]_SE Correct Data Save Status>>} Input SE No. [1-100] {[6.7]_SE Correct Data Transfer>>} Input SE No. [1-100] {[6.8]_SE Correct Data Status>>} Input SE No. [1-100] {[6.9]_SE FLASH Correct Data Status>>} Input SE No. [1-100] {[7]_SYSTEM} {[7.1]_Termination>>} Terminate Forced Terminate Forced Reboot Auto Shutdown Setting MU2-11 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 277: Network Setting

    The default value of the subnet mask of the machine is 255.255.255.0, and locations assigned by 255 (mask value areas) indicate the network address. Segment No. 192.168.0.0 Network address Host address DRID600_G0070.ai MU2-12 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 278 Input the set value when the IP address of the local network is to be changed. To make the changed set value effective, the set value needs to be enabled (setting executed) respectively for the SE, MP and MC. MU2-13 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 279 By clicking [SE Network Address Setting] on the “Local Network PreSetting>>” window, the SE Network Address Batch Setting window opens and the SE network addresses can be set collectively. (4) Clicking [BACK], return to the Local Network PreSetting window. (5) If there is any item that you wish to input, click the corresponding button and repeat procedures (3) to (4). (6) Clicking [BACK], return to the NETWORK SETTING window. MU2-14 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 280 Check that the MC Manager icon has disappeared from the task tray, and then start 1200_700167E.ai the MC Manager from "Start menu" → "Start-up". (5) Clicking [BACK], return to the NETWORK SETTING window. (6) Disconnect the SE cable from the SE. (7) If an unspecified SE exists, repeat procedures (1) to (6). (8) Reinstall the SE cable and battery pack on the SE whose setting has been completed. MU2-15 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 281 SE can be confirmed only when connection between the MC and the MP is normal. 1200_700169E.ai (4) Left-click the MC Manager from the task tray and excute "EXIT". Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from "Start menu" → "Start-up". MU2-16 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 282 The IP address of the SE input in the Local Network Presetting is made effective. The IP address which is effective appears in the result display area. 1300_400012E.ai #1 Input: Target SE No. #2 Click: [SET] MU2-17 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 283: Local Network Presetting

    When two MP’s are connected, the second MP needs to be set as MP2. [Setting for MP2] {MU2: [1.3.1]_MP1 Network Setting >>} Change the IP address of the MP2. Set the IP address of the MP2 to the MP2 value input in [Local Network PreSetting]. 1200_700172E.ai MU2-18 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 284 Used to change the setting of MP1 to MP2. The IP address of the MP2 input in [Local Network PreSetting] is effective, and at the same time the MP1 is set as the MP2. MU2-19 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 285: Mc Eth0 Ip Setting

    >> window gets effective. effective. - MC IP Address (Default value: 172.16.150.135) - MC SubNet Mask (Default value: 255.255.0.0) - MC Default GW (Default value: 0.0.0.0) - FTP IP Address (Default value: 127.0.0.1) MU2-20 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 286: Wireless Speed Measurement

    - SE Memory Exposure Setting rate of the SE corresponding to the pressed button appears in the result display area. - SE LED Color Setting Clicking one of the buttons, the confirmation window of “Are You Sure?” appears. Clicking [OK] on the confirmation window, measurement of radio wave conditions starts. The measurement ends approx. in one minute. MU2-21 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 287: Se Registration

    TOP, CENTER and BOTTOM are specified functions as one long upon deregistration. panel. Deregistration is reflected after the machine is rebooted. REFERENCE The serial ID of an SE is mentioned on the surface of the machine-specific data CDROM. MU2-22 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 288: Longpanel Registration

    The serial ID of an SE is mentioned on the surface of the machine-specific data upon deregistration. CDROM. Deregistration is reflected after the machine is rebooted. MU2-23 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 289 No., and clicking [SET], the battery information is deleted. Register the battery threshold. Clicking [Regist Threshold >>], inputting the SE No. and clicking [Regist], the battery threshold set by [Input Threshold >>] is registered to the target SE. MU2-24 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 290 In the Read Mode (read mode setting), set the Read Mode for memory exposure in addition to the routine exposure. Input [Read Mode] and click [SET]. u NOTE u Any of "0", "1" or "2" can be inputted into [Read Mode]. MU2-25 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 291: Version Check

    SE after restart. 1200_400015E.ai  Function Description Selects the unit whose software version is to be checked. - MC Version >> - MP Version >> - SE Version >> MU2-26 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 292: [3.1] Mc Version

    - MP1 Version Check >> - [Display MC Software Version] button - MP2 Version Check >> - [Display MC Kernel Version] button - [Display MC ALPS Version] button MU2-27 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 293: [3.2.2] Mp2 Version Check

    - [Display MP1 Software Version] button - [Display MP1 Kernel Version] button - [Display MP1 ALPS Version] button - [Display MP1 Driver Version] button MU2-28 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 294: [3.3] Se Version

    The software versions of the SE boards are displayed. - Install MP Software >> - mcu - Install SE Software >> - aplWlan - wifiWlan - ethWlan - fpgaDrv - rmv - fpgaRmv - adc MU2-29 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 295: Install Mp Software

    Selects the MP on which the MP application is to be installed. MP1 Software VerUp Install: - MP1 Install >> The MP application is version-updated. The result appears in the result display area. - MP2 Install >> MU2-30 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 296: Install Se Software

    - Install SE GLG Software: Installation of the GLG board application. - Install SE LAN Software: Installation of the LAN application - Install SE MCU Software: Installation of the MCU application. MU2-31 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 297: Board State Check

    Selects the MP whose board conditions are to be checked. - MP board State - MP1 Board State - SE board State - MP2 Board State - SE Write Serial ID - LongPanel RMV Board Change MU2-32 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 298 ShotSW1 is OFF: [OFF]/ON - ShotSW Port2 Status The ON/OFF status of the shot switch port 2 appears in the result display area. ShotSW2 is ON: OFF/[ON] ShotSW2 is OFF: [OFF]/ON MU2-33 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 299: Se Board State

    Status: OK, RMV H/W Status: OK, RMV Power Status: OK Defective: Other than the above l Temperature Displays the temperature of the stand SE panel in the result display area. Display example: Temperature = 29.4 deg C MU2-34 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 300 Cycle Count: 27 Time to Empty: 65535 (min) Temperature: 2956 (0.1 K) l Battery Date Setting u NOTE u Not used in the DR-ID 1300. Set the start date for battery use. Accurate display of the battery capacity becomes possible by performing “Battery Date Setting”. MU2-35 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 301: Se Serialid Write

    The serial ID of an SE is mentioned on the surface of the machine-specific data CD- order of clicking does not matter.) ROM. → The 0 G output of the high G sensor is acquired. (4) Click [Save Offset Data]. → The offset value is stored in the FRAM of the GLG board (restart is not required). REFERENCE After execution of calibration, the actually measured value minus the offset value is stored in the log as the measured value. MU2-36 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 302: Longpanel Rmv Board Change

    The first letter of the serial ID must be entered as a capital letter. REFERENCE The serial ID of an SE is mentioned on the surface of the machine-specific data CD- ROM. MU2-37 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 303: Calibration

    - Defect calibration - Lag calibration - Marker calibration Also, it is used to confirm or set the SE correct data. - SE Correct Data Save Status - SE Correct Data Transfer - SE Correct Data Status - SE Flash Correct Data Status MU2-38 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 304: Offset Calibration

    - Clicking [Start] during automatic offset update (always taking place approx. at 10-minute intervals when no exposure menu is selected), “Error 12700 currently unavailable” is displayed. Again click [Start] approx. 30 seconds later in this case. MU2-39 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 305: Gain Calibration

    #2 Click: [SET] REFERENCE Whether the check is successfully completed appears on the result display area. An error code is displayed in some cases. Refer to the Troubleshooting manual and take appropriate countermeasures. MU2-40 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 306: Defect Calibration

    Completion of the shooting preparation by the panel is checked. <Result indication> - SHOT_READY: Completed - NOT_READY: Not completed - Create a Gain Data: Gain data is generated. DRID600_G0096E.ai #1 Input: Target SE No. #2 Click: [SET] MU2-41 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 307 - Clicking [Start] during automatic offset update (always taking place approx. at 10-minute intervals when no exposure menu is selected), “Error 12700 currently unavailable” is displayed. Again click [Start] approx. 30 seconds later in this case. MU2-42 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 308: Lag Calibration

    Lag correction calibration takes place under the following conditions: - Exposure conditions: Tube voltage of 80 kV, dose of 100 mR or more, irradiation time of 200 msec or shorter - Exposure count: 1 MU2-43 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 309: Marker Calibration

    Completion of the shooting preparation by the panel is checked. <Result indication> - SHOT_READY: Completed - NOT_READY: Not completed - Create a Marker Data: Marker correction data is generated. 1300_400009E.ai #1 Input: Target SE No. #2 Click: [SET] MU2-44 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 310: Se Correct Data Save Status

    #2 Click: [SET]  Function Description After finishing the full calibration or the SE correct data transfer, check whether the correction data storage has been completed or not. Inputting the SE No. and clicking [SET], the correct data save status after the calibration is displayed. MU2-45 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 311: Se Correct Data Status

    #1 Input: Target SE No #2 Click: [SET]  Function Description Check the list of correct data stored in the SE. Inputting the SE No. and clicking [SET], the correct data status is displayed. MU2-46 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 312: Se Flash Correct Data Status

    Used to select a way to shut down the system. REFERENCE Each time you click [Auto Shutdown Setting], ON/OFF setting is changed over. If the initialization calibration has not been completed, “Not Yet” is displayed. MU2-47 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 313: Termination

    - Terminate: The system is normally shut down including termination calibration. - Forced Terminate: The system is shut down without termination calibration. - Forced Reboot: The system is restarted without termination calibration. MU2-48 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 314: Ping

    Minimum = 0 ms, Maximum = 0 ms, Average = 0 ms (2) Select the machine to be checked. <NO GOOD indication> (3) Click [PING]. Other than above. The “PING” result is displayed on the CL window. PC-TOOL window (4) Exit the RU PC-TOOL. {MU2:1._PC-TOOL} Check that the display reads “0% loss”. 1200_700171E.ai MU2-49 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 315: Mon

    PC-TOOL. PC-TOOL window DRID600_G0055.ai Result window <GOOD indication> OK value = 0 = 0x0 <NO GOOD indication> Other than above. 1200_400034E.ai (4) Exit the RU PC-TOOL. {MU2:1._PC-TOOL} MU2-50 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 316: Install

    {IN2:10.1_Installing and Setting the NIC Board to the DX Console} (4) Select “.\install\remote\MCSetupWizard.bat” from “FILE EXECUTION” - When the MC application is installed, the MC Manager restarts automatically after area, and click [EXECUTE]. the completion of the installation. MU2-51 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 317 If the RU registration has been already completed, steps 6 and 7 are not (9) Click [Yes]. necessary. Proceed to step 8. #1 Click: [Yes] (6) If the RU registration has not been completed, the following window appears. Click [OK]. #1 Click: [OK] 800_700205.ai 800_700202.ai MU2-52 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 318 MU2-53 The following window opens during the version-update. (11) Click [START] in the “Set Up PC-TOOL” window to start the RU PC- TOOL window. #1 Click: [START] Set Up PC-TOOL window 800_700206.ai (10) Check that the installation is completed, and click [OK]. #1 Click: [OK] RU PC-TOOL window 800_700207.ai 600_700056.ai MU2-53 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 319 - When the MC application is upgraded, the MC Manager restarts automatically after the completion of the upgrading. - The settings become effective after the RU is restarted. (14) Update SE Application Software Version. {IN2:10.10_Updating SE Application Software Version} (15) Update MP Application Software Version. {IN2:10.5_Updating MP Application Software Version} MU2-54 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 320: Edit History

    Stores the changes, and exit from the [EDIT HISTORY] window. u INSTRUCTION u To make the input value in the “INSTALLATION DATE” effective, you need to click [SET] and turn OFF the main power circuit breaker of the MC. MU2-55 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 321: Edit Configuration

    HDD data gets damaged, and the MC cannot boot up. (6) Left-click the MC Manager from the task tray and execute "EXIT". Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from "Start menu" → "Start-up". REFERENCE The settings become effective after restart of the MC. 1200_400035.ai MU2-56 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 322 [Bed] of the X-ray equipment is to be connected. - MP1 [default]: Connected to MP1 <Options> - MP2: Connected to MP2 - MPX1 [default]: Connected to MPX1 {MU:1.11_EDIT CONFIGURATION_ OPE SETTING (UPRIGHT/TABLE/FREE)} - MPX2: Connected to MPX2 MU2-57 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 323 UPRIGHT 180 REVERSE Selects whether the exposure image of the stand SE (FPD) is to be rotated 180 degrees. <Options> - none [default]: Not rotated - 180: Rotated 180 degrees MU2-58 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 324 190 msec with the exposure menu of the DX Console. Also, the charge accumulation time becomes 500 msec when the irradiation time has been set to 300 msec with the exposure menu. MU2-59 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 325 "READ MODE". - When setting "ON" to "LONG TIME ACCUM MODE", set 7 minutes or more to "SLEEP START TIME" in "SE SLEEP MODE SETTING" window. MU2-60 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 326 - In case of the FUJIFILM-made AP, the “WSTAT” LED flashes red during the Make the same setting of the identifier on the AP. DFS search operation. <Options> - When selecting 2.4 GHz on the FUJIFILM-made AP, select 20 MHz on the “Channel - FUJIAP01 to FUJIAP10, MANUAL [default: FUJIAP01] Width”. Do not select 40 MHz. l ESSID MANUAL (arbitrary ID setting for wireless LAN) Sets an arbitrary ID in case that “MANUAL” has been selected at “ESSID”.
  • Page 327 AP’s are to be used. The MAC address is mentioned on the label or in the instruction manual of the AP. <Settable range> - 12-character string [default: 000000000000] MU2-62 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 328 As this setting causes a large change of the image quality, select according to the desire of the user. u NOTE u When set to “ON”, the PC capacity is compressed and the throughput is degraded. MU2-63 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 329 Select whether or not the blemish/unevenness correction is to be performed. - After completing the periodical defect calibration <Options> - After completing the automatic log update - OFF: Not performed - ON [default]: Performed MU2-64 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 330 - If [FPD-C] is registered in any selector, always carry out the following operations. - Connect the free X-ray shot cable to the MP. - Specify the destination of connection via the PC-TOOL in [OPE SETTING (FREE)] and [PORT SETTING (FREE)]. MU2-65 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 331 The operative method for exposure and the panel to be used are determined based on the CSL setting (not depending on the connector (MPC6 or 7) to which the panel is connected). 1300_400004E.ai MU2-66 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 332: Edit Cl Name

    (2) Select the CL to be edited and click [MODIFY] when the CL is to be edited, or click [NEW] when the CL is to be added. → The window for prompting the input of “CL IP ADDRESS” and “CL NAME” appears. (3) Input “CL IP ADDRESS” and “CL NAME” and click [SET]. (4) Click [SET]. → The RU PC-TOOL window restores.  Procedures for Setting the Master CL (1) Select the CL to be the master CL among those appearing on the “CL NAME” window. (2) Click [>>], and click [SET]. → The RU PC-TOOL window restores. MU2-67 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 333: Backup

    Collectively acquire the data of the registered panels (maximum 3 CORRECT ALL DATA of 100 pieces). CORRECT PANEL Acquire the data of an individual panel by specifying the panel DATA number. MU2-68 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 334 To change the backup location, click Only the drives and directories recognized by the CL are displayed as the locations available for backup. Choose a backup location (by double-clicking it). The selected location appears. DRID600_G0066.ai MU2-69 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 335: Restore

    Select (double-click) the region to restore. The selected ex.: When restoring the location configuration, do not specify appears. the folder CONFIG, but the folder one level higher. DRID600_G0067.ai MU2-70 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 336: I/O Trace Expert

    MU2-71 1.15 I/O TRACE EXPERT Not used in the machine. MU2-71 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 337: Error Db

    The name of the person (author) who entered “Author” text box (2) Click [ERROR DB]. text in the “Memo.” text box is entered. → The “ERROR DB” window appears. The contents of “Memo.” and “Author” are saved. “SAVE” button To delete them, erase them by use of the Delete (3) Click [UPDATE], and update the error log. key and press the [SAVE] button again. MU2-72 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 338: Uninstall (All Rus)

    RU’s disappear from "LIST OF EXISTING RU". In addition, the contents of "C: \ ProgramFiles \ FujiFilm \ FCR" directory on the CL are - Never turn OFF the power of the MC during version-update. Otherwise, the deleted.

  • Page 339: 1.19 Configuration

    The procedures for copying the complete CD contents to the "Copy CD-R" of the C drive are described as an example. (1) Select “CDPath” from the [Configuration (C)] menu. → The “CD PATH SETTING” window appears. (2) Input or select the path of the folder in which the CD-ROM (RU software) data is completely copied. (3) Click [SET]. DRID600_G0069.ai → “CDPath” is set. MU2-74 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 340 MU2-75 BLANK PAGE MU2-75 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 341 5, 6, 8 to 12, 14 to 19 12.28.2017 Revison for MC V16.2 (FM9490) 2, 4, 6, 13 DR-ID 1300 / DR-ID 1300PU 03.31.2020 Revison for MC V17.2 (FM9623) 4, 6, 13 Service Manual Service Parts List (SP) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 342: How To Use Service Parts List

    The use of different packing materials or all the relevant units. The shipment control packing methods may incur damage to number is represented by lower five digits packed component during transit. of eight-digit number indicated on the rating indication label. SP-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 343 MPL65A 48V / 4A for MPL65A 13.1 137S1422 ヒューズ Fuse F1, F2 型式／ Model： LM40(D)CDL (*1) MP の背面カバー用 345Y130006 ガスケット Gasket For MP Rear Cover 405Y200096 銘板アセンブリ Label Assembly (*4) 1300_500001.ai SP-2 018-234-05C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 344 Manufacturer / Daito Communication Apparatus Co. *2: メーカ／パナソニック電工株式会社 Manufacturer / Panasonic Electric Works Co. *3: メーカ／ TDK ラムダ株式会社 Manufacturer / TDK-Lambda Co. *4: REF.4 購入時に合わせて、シリアル番号を連絡の上、発注すること。 Order REF.15 with sending the MP serial number when purchasing REF.4. SP-3 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 345 113Y200005A LED65C LED65C 405Y200092 銘板アセンブリ Label Assembly GL 用 キ ャ リ ブ 治 具 Calibration Jig for 310N120042 ピン D-EVO GL *1: メーカ／大東通信機株式会社 Manufacturer / Daito Communication Apparatus Co. 1300_500002.ai SP-4 018-234-06C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 346: Options (Circuit Parts

    ボ ー ド ア セ ン ブ リ Board Assembly Hand Sw IF BOX 用 113Y100550E HSC54A HSC54A For Hand Sw IF BOX メーカ／パナソニック電工株式会社 Manufacturer / Panasonic Electric Works Co. 1200_500009.ai SP-5 018-234-01C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 347: Cable

    ケーブル MPC5-MPL3 cable 136Y120393A ケーブル Cable MPC-FAN MP 医用電源コード 136Y102483A ケーブル Cable （国内 /For Japan） 海外 / 国内 Ed3.1 Electric LP cable 20m 898Y200030 ケーブル cable For Overseas For Japan, Ed3.1 SP-6 018-234-06C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 348: Tools

    SP-7 治工具 Tools RANK REF. PART NO. PART NAME QTY. REMARKS SERIAL NO. REFER TO DR-ID 600/800/900/ DR-ID 600/800/900/ 1200/1300MP 136Y102973 1200/1300MP IP アドレスリセット IP Address reset jig 治具 SP-7 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 349: Circuit Diagram (Mp

    LAN1_RXN 国内 海外 B4B-ZR(LF)(SN) 5569-04A1-210 136Y120364 136Y121296 MPL6 MPL2 24V_OUT1 136Y121072 136Y121297 VOUT_EN GND_OUT1 DF1E-2P-2.5DS(05) 5566-02A-210 機種 ユニット 名称 回路図 補助名称 LongPanel （国内／海外） Z22N0007A コ ー ド 頁 頁 頁 富士フイルム株式会社 SP-8 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 350: Circuit Diagram (Se

    -TF(LF)(SN) <NC> SECN_TXRXN_C SM02B-SFHRS-TF(LF)(SN) <NC> SECN_TXRXP_D SECN_TXRXN_D 機種 ユニット 100BASE 5_Port MD_CRD_BUFRST 名称 回路図 補助名称 LongPanel （国内／海外） Centre COM FM_CRD_CONNECT_INT Z22N0007A FS705EX V2 コ ー ド DF13A-15P-1.25H(51) 頁 頁 頁 富士フイルム株式会社 SP-9 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 351 RMV25 FH52-28S-0.5SH(99) ｻｰﾐｽﾀ ●136N120072 GTD基板_L(制御系) RMV24 GTD2 103AP-2 GND 1 GTD65A_L 機種 ユニット GTD_CNCHK2 28 113Y120025 SM04B-SRSS-TB(LF)(SN) FH52-28S-0.5SH(99) 名称 回路図 補助名称 LongPanel （国内／海外） Z22N0007A コ ー ド 頁 頁 頁 富士フイルム株式会社 SP-10 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 352 -TF(LF)(SN) <NC> SECN_TXRXN_C SM02B-SFHRS-TF(LF)(SN) <NC> SECN_TXRXP_D SECN_TXRXN_D 機種 ユニット 100BASE 5_Port 回路図 MD_CRD_BUFRST 名称 補助名称 LongPanel （海外） Centre COM FM_CRD_CONNECT_INT Z22N100003 FS705EX V2 コ ー ド DF13A-15P-1.25H(51) 頁 頁 頁 富士フイルム株式会社 SP-11 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 353 LED制御出力 ●136Y200027 ↓ RMV_+5V VCC_+5V GTD_CNCHK2 28 113Y120025 RMV_GND FH52E-24S SM02B-SFHRS FH52-28S-0.5SH(99) SM02B-SFHRS-TF(LF)(SN) -0.5SH(99) -TF(LF)(SN) ③側 機種 ユニット 回路図 名称 補助名称 LongPanel （海外） コ ー ド Z22N100003 頁 頁 頁 富士フイルム株式会社 SP-12 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 354: Parts Nos. Search Table

    04-24 898Y120393B 02-2.2 136Y120363A 04-25 898Y200030 04-29 136Y120374 04-26 898Y200031 04-30 136Y120375B 04-4 898Y201161 04-31 136Y120376A 04-5 136Y120377A 04-6 136Y120378 04-7 136Y120380 04-9 136Y120381 04-10 136Y120382 04-11 136Y120383A 04-12 136Y120386A 04-13 SP-13 018-234-06C DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 355: List Of Service Parts For Securing And Wiring

    The following is an example of how screws in the service parts table are described. スマニュアル内の記載方法と同じである。 This description method is the same as that in this Service Manual. 長さ ね じの 呼 び ねじの 種 類 を あら わ す文字 SP-14 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 356 締結用および配線用のサービス部品一覧表 List of Service Parts for Securing and Wiring ネジ 参考情報 Reference information 記号 部品コード Symbol Parts code 形状 部品名称 Parts name Shape Cross-recessed hexagonheaded TP3x6 308S0414 六角頭 TP ネジ TPscrew SP-15 018-234-04C DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 357 Hexagon nut Plain washer Plain washer Spring washer Nominal diameter 4 E ring Nominal Spring washer E ring diameter 6 K-CL ring K-CL ring 1200_500022.ai Self-tapping screw with a noncircular end Stainless-made SP-16 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 358: List Of Quick Wearing Parts

    List Of Quick Wearing Parts Part name Shape 1 Fixing plug 2 Binding band Fixing plug Binding band N.K. clamp 3 N.K. clamp 4 Edging Edging Edge saddle 600_500003.ai 5 Edge saddle SP-17 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 359 SP-18 BLANK PAGE SP-18 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 360 SP-19 BLANK PAGE SP-19 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 361 Revision number Reason Pages affected 03.31.2016 New release (FM9369) All pages 06.30.2017 Revison for MC V15 (FM9473) 3, 4, 9 to 11 DR-ID 1300 / DR-ID 1300PU Service Manual Preventive Maintenance (PM) 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 362: Preventive Maintenance Program

    Procedure performed at an age of 5 years. 3, 4 and 5 years. As the tasks to be performed depend on the age of service, follow the list in carrying out the preventive maintenance program. PM-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 363: Preventive Maintenance Program List

    The model of the relay depends on a type of the AC bucky relay unit. Identify the type of the AC bucky relay unit, and select the relay for replacement. {MD:1.3.4_Board-Related Information} PM-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 364: Checking The Error Log

    PM-3 Checking the Error Log (1) Check the error log. {IN1:14._Checking the Error Log} {IN2:14._Checking the Error Log} PM-3 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 365: Checking For Image Problems

    PM-4 Checking for Image Problems (1) Check the images. {IN1:13._Checking for Image Problems} {IN2:13._Checking for Image Problems} PM-4 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 366: Inspecting The Fan (Mp

    PM-5 Inspecting the Fan (MP) (1) Check to make sure that the MP fan is working. #1 Check: Exhaust air 1200_600001.ai PM-5 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 367: Inspecting The Filter (Mp

    Inspecting the Filter (MP) (1) Remove the filter from the MP. #1 Remove: Filter DETAIL A 1200_600002.ai (2) Clean the filter with a vacuum cleaner. u NOTE u Replace the filter if the filter cannot be cleaned by the vacuum cleaner. (3) Reinstall the filter. PM-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 368: Replacing The Relay (Mp

    Take the following procedures only when the AC bucky relay unit (optional) is mounted. WARNING Be sure to turn OFF the circuit breaker on the distribution switchboard to avoid electric shock hazards. (1) Replace the relay. {MC:2.11.1_Relay} PM-7 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 369: Checking The Cables

    PM-8 Checking the Cables (1) Check that the SE cable has no twist or breakage of the jacket. #1 Check: Cable 1300_600001.ai PM-8 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 370: Checking The Exposure

    (3) Visually check the connection of the calibration phantom for misalignment. u NOTE u If a misalignment is found, perform the full calibration and marker calibration for the CENTER panel unit again. PM-9 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 371: Checking For Image Problems

    PM-10 Checking for Image Problems (1) Check the images. {IN1:13._Checking for Image Problems} {IN2:13._Checking for Image Problems} PM-10 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 372: 10. Checking The Error Log

    PM-11 10. Checking the Error Log (1) Check the error log. {IN1:14._Checking the Error Log} {IN2:14._Checking the Error Log} PM-11 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 373: Cleaning The Periphery Of The Machine And The External Cover

    Machine and the External Cover (1) Make sure that no dirt or dust remains around the machine. If dirty, clean around the machine. (2) Clean the SE with a cloth moistened with ethanol etc. PM-12 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 374 PM-13 BLANK PAGE PM-13 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 375 PM-14 BLANK PAGE PM-14 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 376 PM-15 BLANK PAGE PM-15 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 377: Installation (In)

    Control Sheet Issue date Revision number Reason Pages affected 06.30.2017 New release (FM9473) All pages 12.28.2017 Revision for MC V16.2 (FM9490) DR-ID 1300 / DR-ID 1300PU Service Manual Installation (IN) 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 378 Since Internet Explorer 11 is already installed if Windows 10 is being used as the OS, then the aforementioned procedures are unnecessary. n MC application V15.0 or earlier The procedures for using the RU PC-TOOL. {Installation (IN2) (RU PC-TOOL)} IN-1 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 379 IN-2 BLANK PAGE IN-2 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 380 IN-3 BLANK PAGE IN-3 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 381: Installation (In1) (Dr Maintenance Software)

    DR-ID 1300 / DR-ID 1300PU 03.31.2020 Revision for MC V17.2 (FM9623) 8, 51, 52, 55, 68, 89, 90 03.31.2020 Changes in pagination (FM9623) 69 to 75, 91 to 95 Service Manual Installation (IN1) (DR Maintenance Software) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 382: Installation Work Flowchart

    10.12 Installing the Machine-Specific Data 6.5 Connecting the X-Ray shot cable 10.13 Changing the IP Address of the SE/MP/MC and the FTP Server 6.6 Binding and Checking the Cables 6.7 Reinstalling the Covers IN1-1 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 383 15. Clearing the EDIT HISTORY 16. Backing Up the Data 17. Final Checks 17.1 Checking the SE 17.2 Checking the Status of Boards 18. Visual Inspection and Cleaning of the Machine IN1-2 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 384: Installation Preparations

    NOTE The SE cable is always needed to install the machine. Prepare the SE cable for use of the jig if the SE cable (optional) is not purchased by the customer. IN1-3 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 385: Precautions In Installation

    - If the exposure stand is equipped without the external cover, the display of the panel effective area and overlapping part must be able to be checked. IN1-4 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 386: Transfer And Unpacking

    If the machine is to be transferred over differing floor levels, slowly move the machine not to shock it. Note that the carrier can come over a differing level up to approx. 10 mm. Transporting box 1300_700056E.ai IN1-5 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 387: Unpacking The Se

    (1) Take out the DX Console from transporting box. #1 Take out: SE Unpacking the Monitor Transporting box (1) Take out the monitor from transporting box. CD-R Fuse Letter of guarantee Vinyl sheet Transporting 1300_700006E.ai IN1-6 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 388: Checking The Items Supplied

    Letter of guarantee/Report of completion of installation/Notes on the X-ray Only inside Japan exposure/Performance check list n DR-ID 300CL For details on the DR-ID 300CL, refer to the DR-ID 300CL Service Manual. IN1-7 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 389 I/F box cable_Philips I/F box cable_110-3 wire I/F box cable_110-4 wire l SE cable-related Name Qty. Remarks SE cable 4m (Only for overseas) SE cable SE cable l Fixture Name Qty. Remarks Anchor fixing bracket of MP IN1-8 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 390: Installing The Mp

    Removing the Covers (1) Remove the MP top cover. #1 Loosen: T3x6 (x2) Rear cover Top cover 1200_700028E.ai 1200_700026E.ai (2) Remove the MP front cover. #1 Remove: T3x6 (x6) Front cover 1200_700027E.ai IN1-9 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 391: Checking The Power Cable

    (4) Set the main power switch to the OFF position after completion of the #1 Remove: T3x6 (x3) measurement. #2 Turn over: height retaining brackets (x3) #3 Tighten: T3x6 (x3) Bottom cover 1200_700150.ai IN1-10 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 392: Installing The Anchor Mounting Bracket (Optional)

    (2) Install the anchor mounting bracket to the MP. #1 Tighten: T3x6 (x4) 1200_700159.ai (3) Install the bottom cover. 1200_700151.ai #1 Tighten: T3x6 (x2) (4) Reinstall the bottom cover. #1 Tighten: T3x6 (x2) Bottom cover 1200_700154.ai 1200_700152.ai IN1-11 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 393: Connecting The Cables

    SE cable to the MPL6 and MPL8 cable connectors. 97 mm or more - Firmly secure the #4 clamps. If they are not secured, there might be noise effects. Cable tie (inside) 105 mm or more 1200_700175E.ai IN1-12 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 394 (3) Route the LAN cables between the MP and DX Console from the lower opening on the MP rear cover and connect them. #1 Route: LAN cable #2 Connect: LAN cable connector (MPC4) MPC4 1300_700009.ai IN1-13 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 395 The AC bucky relay unit (optional) is required when the bucky AC type is to be connected. GND_iso SHOT1 {IN1:6.5.3_Connecting the X-Ray Shot Cable (Bucky AC Type)} GO A AHN22005 SHOT1 GO B 600_700010.ai IN1-14 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 396 Contact Capacity SHOT GO The specifications of relays (K4, K5 and K6) are as follows. X-ray exposure l Relay model AHN22005 (Panasonic Electric Works) Charge accumulation of SE (FPD) l Rated control capacity Standard contact: 30 VDC 600_700011.ai l Maximum switching current IN1-15 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 397 (1) Insert the X-Ray shot cable (optional) from the upper opening on the MP rear cover. 11 BKY2 RDY2B 11 BKY1 RDY2B #1 Insert: X-Ray shot cable (optional) 12 NC2 12 NC1 600_700013.ai 1200_700029.ai IN1-16 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 398 11 BKY1 RDY2B If the second cable is not present, the procedure is not necessary. Proceed to the 12 NC2 12 NC1 procedure (7). 600_700016.ai #1 Insert: X-Ray shot cable (optional) 1200_700030.ai IN1-17 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 399 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape 1200_700031.ai <When two X-Ray shot cables are used> 600_700014.ai 1200_700032.ai IN1-18 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 400 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape #2 Tie: Cables #3 Retain: Reusable band (supplied accessory) 1200_700033.ai IN1-19 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 401: Connecting The X-Ray Shot Cable (Bucky Contact Type)

    Shot AHN22005 +5V_iso Switch 1 BKY1 SHOT1 Prep RDY2B RDY1 TLP421F GND_iso SHOT1 RDY2 820Ω Shot Switch 2 SHOT1 RDY2 GND_iso SHOT1 GO A AHN22005 SHOT1 GO B BKY1 EXP 600_700022.ai IN1-20 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 402 The specifications of relays (K4, K5 and K6) are as follows. Bucky l Relay model BKY1 EXP AHN22005 (Panasonic Electric Works) l Rated control capacity X-ray exposure Standard contact: 30 VDC Charge accumulation of SE (FPD) l Maximum switching current 600_700023.ai IN1-21 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 403 Reusable band Bucky cable Part No.: LWS-3S V0 1200_700034.ai u NOTE u Abut the cable terminals as shown below when fastening them together. GOOD Cable Screw Terminal Terminal block NO GOOD 600_700132.ai IN1-22 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 404 If the second cable and the bucky cable are not present, the procedure is not necessary. Proceed to the procedure (7). Bucky cable 600_700026.ai #1 Insert: X-Ray shot cable (optional) and the bucky cable 1200_700035.ai IN1-23 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 405 8 BKY2 RDY1A 8 BKY1 RDY1A 9 BKY2 RDY1B 9 BKY1 RDY1B 10 BKY2 RDY2A 10 BKY1 RDY2A 600_700014.ai 11 BKY2 RDY2B 11 BKY1 RDY2B 12 NC2 12 NC1 Bucky cable 600_700028.ai IN1-24 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 406 <When two X-Ray shot cables and two bucky cables are used> 1200_700145.ai <When two X-Ray shot cables and two bucky cables are used> X-Ray shot cables Bucky cables X-Ray shot cables Bucky cables 1200_700146.ai 1200_700037.ai IN1-25 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 407 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape #2 Tie: Cables #3 Retain: Reusable band (supplied accessory) 1200_700033.ai IN1-26 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 408: Connecting The X-Ray Shot Cable (Bucky Ac Type)

    SHOT GO A BKY EXP A SHOT GO B BKY EXP B FGND FGND Relay AC100/110V : AHN210X0 AC110/120V : AHN210X1 AC200/220V : AHN210Y0 AC220/240V : AHN210Y2 AC Bucky Relay Unit 600_700033.ai IN1-27 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 409 200/220 VAC 4.5/6.5 mA Charge accumulation AHN210Y2: 220/240 VAC 4.1/5.9 mA of SE (FPD) - AHN12205 (Panasonic Electric Works) Standard contact: 250 VAC and 30 VDC 600_700034.ai l Maximum switching current IN1-28 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 410 600_700132.ai (1) Mount the AC bucky relay unit (optional) on the MP. #1 Tighten: TP3x6 (x4) MPX2-10 MPX1-10 AC bucky relay unit MPX2-11 MPX1-11 600_700036.ai *: Short cable (supplied accessory) 1200_700147.ai IN1-29 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 411 If the following specifications of the cable and the NO GOOD terminal are not observed, the machine might get damaged. - Cable: AWG18 to 22 thick - Terminal: FV1.25-M4 (J.S.T. Connector) - Crimp nippers: Manufactured by IZUMI; A125 600_700132.ai IN1-30 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 412 MP rear cover. #1 Remove: B3x6 (x4) AC bucky relay unit #1 Insert: X-Ray shot cable (optional) and the bucky cable Covers X-Ray shot cable Bucky cable 1200_700148.ai 1200_700038.ai IN1-31 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 413 X-Con BKY Stand Exp A X-Con SHOT2 RDY2 (L) X-Con BKY Stand Exp B X-Con BKY SHOT2 RDY2 (N) X-Con BKY Bed Exp A SHOT2 RDY2 (L) X-Con BKY Bed Exp B IN1-32 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 414 X-Con SHOT2 RDY2 (L) X-Con BKY Stand Exp B X-Ray shot cable 600_700051.ai X-Con BKY SHOT2 RDY2 (N) X-Con BKY Bed Exp A SHOT2 RDY2 (L) X-Con BKY Bed Exp B IN1-33 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 415: Binding And Checking The Cables

    <When two X-Ray shot cables and two bucky cables are used> X-Ray shot cables LAN cable (between MP and MC) X-Ray shot cable(s) LAN cable (between MP and AP) and the bucky cable(s) 1200_700039.ai Bucky cables 1200_700037.ai IN1-34 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 416: Reinstalling The Covers

    #1 Embed: Anchors (x2) u INSTRUCTION u Remove the cuttings that are stuck in the holes. u NOTE u The anchors corresponding to the anchor nut size should be prepared. 1200_700155.ai 1200_700007.ai IN1-35 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 417: Installing The Se

    The SE power is configured to be automatically turned OFF if an unregistered SE is (2) Turn ON the power of the MP. connected. A new SE needs to be registered before connecting it. IN1-36 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 418: Mounting The Nic Board To The Dx Console

    (4) Mount the network interface board. (5) Lower the latch, and fix the network interface board. Cover 600_700104.ai (6) Put on the cover removed in the procedure (2). Reverse the removal procedures for reinstallation. 600_700102.ai IN1-37 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 419: Connecting The Network Cables

    LAN cable DR-ID1300 SE cable 1300_700059E.ai NOTE In case of one DR-ID 1305SE configuration, connect the SE cable to MPL5 connector and MPL7 connector of the MPL65A board into the MP. IN1-38 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 420 [DR-ID 1200MC] 192.168.0.10 192.168.0.93 (TOP) (Eth1) 192.168.0.94 (CENTER) 192.168.0.95 (BOTTOM) 192.168.0.20 DR-ID 1305SE DR-ID 1300MP DR-ID 1305SE 192.168.0.90 (TOP) LAN cable 192.168.0.91 (CENTER) DR-ID1300 SE cable 192.168.0.92 (BOTTOM) DR-ID1200 SE cable 1300_700058E.ai IN1-39 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 421: Installing The Dx Console

    Refer to the DR-ID 300CL Service Manual. REFERENCE The MAC address of the MC is required during the setting operation on the CL. The MAC address of the MC appears by selecting “Network Address” in the “MUTL”. IN1-40 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 422: 10. Installing The Ru Software

    10.10 Setting the IP Address of the SE 10.11 Updating SE Application Software Version 10.12 Installing the Machine-Specific Data 10.13 Changing the IP Address of the SE/MP/MC and the FTP Server IN1-41 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 423: Network Settings

    #1 Right-click: menu #2 Select: [Control Panel] 1200_700399E.ai (3) Click [Change adapter settings]. The Network Connections window opens. 1200_700398E.ai #1 Click: [Change adapter settings] The All Control Panel Items window opens. 1200_700400E.ai IN1-42 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 424 (5) Select “Eth1”, and then select [Properties] from the right-click menu. - Subnet mask: 255.255.255.0 The Network Properties dialog opens. #1 Select: Use the following IP address #2 Input: IP address, Subnet mask 1200_700403E.ai IN1-43 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 425 ← Return to the All Control Panel Items window. #1 Verify: Eth0 and Eth1 #2 Click: [←] 1200_700404E.ai (9) Click [Close]. Return to the Network Connections window. #1 Click: [Close] 1200_700407E.ai 1200_700405E.ai IN1-44 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 426 (2) Click [Turn Windows features on or off]. 1200_700410E.ai The Windows Features window opens. REFERENCE #1 Click: [Turn Windows features on or off] For Windows 7, place a checkmark to the check-box of “Telnet Server”. 1200_700409E.ai IN1-45 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 427 (2) Click [Windows Firewall]. #2 Click: Enable Rule The Windows Firewall window opens. (3) Select [Advanced settings]. The Windows Firewall with Advanced Security window opens. #1 Select: Advanced settings 1200_700475E.ai 1200_700473E.ai IN1-46 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 428 (6) Select [Exit] from [File] menu. The system returns to the Windows Firewall window. #1 Click: [File] menu #2 Click: Exit 1200_700476E.ai (7) Close the Windows Firewall window. The system returns to the desktop screen. IN1-47 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 429: Installing The Mc Application/Dr Maintenance Software

    (wizard window) DXL04010001.ai (3) Insert the install disk into the DVD drive of the CSL-PC. Upon inserting the install disk into the DVD drive, the “Set Up PC-TOOL” window automatically starts. 1200_700413E.ai IN1-48 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 430 (7) Click [Install] and start installation. The Command Prompt window opens three times. #1 Click: [Install] 1200_700415.ai Upon completion of the installation, the RU PC-TOOL Set Up window (wizard window) opens. IN1-49 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 431 The following window opens. #1 Select: .\install\local\Install.bat #2 Click: [EXECUTE] Set Up PC-TOOL window 1200_700420.ai (6) Press <Y> key. The “Maintenance mode” window opens. 1200_700417.ai The following window opens. 1200_700418.ai (4) Press <Y> key. IN1-50 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 432 (8) Click [Yes]. (11) Click [I Agree]. (9) Click [Finish]. #1 Click: [Finish] 1200_700424.ai The “Installation options” window opens. 1200_700422.ai When the Installation is completed, the “WinPcap 4.1.3 Setup Wizard” window opens. IN1-51 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 433 Registering to the MC Manager start menu (1) Right-click I:/MC/MCManager.exe, and select “Pin to Start”. 1400_700020E.ai The MC Manager is pinned to the start menu. 1200_700426.ai After the Installation is completed, the following window opens. 1200_700427.ai IN1-52 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 434 #2 Click: [Connect] (5) Input the RU NAMEand click [Register]. #1 Input: RU NAME #2 Click: [Register] 1200_700432.ai The version and the media version that are installed on the device appear. 1200_700429.ai IN1-53 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 435 (8) Check that the installation is completed, and click [OK]. #1 Click: [OK] 1200_700436.ai The system returns to the desktop screen. (9) Remove the disk from the DVD drive. (10) Restart the PC. IN1-54 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 436 #1 Select: .\install\DRWM\Setup.bat mode here. Normally, select “1. Standard” (standard mode). #2 Click: [EXECUTE] Set Up PC-TOOL window POCX010713001J.ai (4) Press <Y> key. (5) Press <Enter> key. 1200_700482.ai The following window opens. 1200_700483.ai IN1-55 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 437 INSTRUCTION Check that connecting the Network Cables and Network Settings before starting DR Maintenance Software. When the mobile configuration, Check the FUJIFILM-made AP will be connected. {IN1:10.1_Network Settings} 1200_700565E.ai (3) Change the address in the “Home page” field to the following address, (1) Open Internet Explorer, enter the following address into the address click [Use current], and then click [OK].

  • Page 438: Starting Up The Dr Maintenance Software

    Perform the subsequent proceduese according to the DR Maintenance Software. REFERENCES When the DR Maintenance Software is restarted, open the Internet Explorer again. 1200_700488E.ai Security Lock is canceled. (6) Click [OK]. 1200_700489E.ai IN1-57 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 439: Preparation Before Setting Dr Device

    IN1-58 10.4 Preparation before Setting DR Device ■ Checking the Network Settings (1) Check that there is no problem in MC application and Network Settings. 1200_700491E.ai (2) Click [Next]. IN1-58 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 440: Updating Mp Application Software Version

    If the MP application failed in upgrading the version, restart the MP and retry from connection check. (3) Check that the installation is completed, and restart the MP. (4) Check the MP application software version. {n Checking the MP Application Software Version} IN1-59 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 441: Changing The Ip Address For Using Two Mps

    (4) Select “MP1” from the drop-down list box, and click [Re-acquire connected MP]. (5) Select “Setting for MP2”, and click [SET]. 1200_700545E.ai 1200_700543E.ai (9) Click [Next] twice. The following window opens. 1200_700006E.ai IN1-60 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 442: 10.7 Configuration Settings

    Click the upper left corner and then the upper right corner. DXL04010001.ai (3) Click [Device Setting] and click [Modify]. #1 Click: [Device Setting] #2 Click: [Modify] IIP Service Utility window 1200_700495E.ai (2) Click [Next]. Device Setting window 1200_700136.ai IN1-61 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 443 The system returns to the IIP Service Utility window. #1 Set: Reader Type #2 Click: [OK] Selector Setting window 1200_700137.ai 1200_700139.ai NOTE Correspond with the Edit Configuration settings. (7) Click [Setup Configuration Item]. IN1-62 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 444 New Node window 1200_700144.ai 1200_700497E.ai NOTE With the DR-ID 1300, set the SE serial ID via the “Setting the Serial ID of the GL Panel”. Therefore, do not enter anything in the “Setting the Serial ID of the SE”. IN1-63 018-234-05E...

  • Page 445: Setting The Serial Id Of The Gl Panel

    Setting the Serial ID of the GL Panel (2) After entering the SE (3 panel units) serial ID which are to be registered, click [OK]. With the DR-ID 1300, set the SE serial ID via the “Setting the Serial ID of the GL Panel”. INSTRUCTION - Take the procedures from “10.9 Setting the Serial ID of the GL Panel”...

  • Page 446: 10.10 Setting The Ip Address Of The Se

    Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from “Start menu”. NOTE With the DR-ID 1300, do not perform “Changing the SE Country Code”. 1200_700501E.ai The IP Address of the SE (wired/wireless) appears.
  • Page 447 (3) Click [OK], and restart the SE. 1200_700503E.ai (4) Click [GET], confirm that the IP address has been changed, and click [Next]. 1200_700502E.ai The IP Address of the SE will be updated. 1200_700505E.ai IN1-66 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 448: 10.11 Updating Se Application Software Version

    INSTRUCTION while until a completion message appears. If “Current Version” and “Updated Version” are identical with each other, click the [Next] to go to the following procedure. {IN1:10.12_Installing the Machine-Specific Data} IN1-67 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 449 {n Checking the SE Application Software Version} Upgrade the SE application version again after updating the FPGA software NOTE from “OPERATION>UTILITY> Update SE FPGA”. With the DR-ID 1300, do not perform “Setting the SE LED Color”. {MU1:1.9.11_Update SE FPGA} IN1-68 018-234-06E...

  • Page 450: 10.12 Installing The Machine-Specific Data

    (1) Insert the machine-specific data CD into the DVD drive of the CL. (2) Click [Install] of the panel unit where you want to install the machine- specific data. 1200_700544E.ai 1200_700514E.ai IMAGE READING MODE High-Speed Mode Standard Mode CORRECTH CORRECTS 1300_700062E.ai IN1-69 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 451 “CORRECTS” folder. For the procedure for changing the folder selection, refer to connection confirmation again. “l IMAGE READING MODE” of “MU1:1.3.2_RU Image Flag”. {MU1:1.3.2_RU Image Flag} (6) Click [OK]. 1200_700517E.ai (7) Repeat (2) to (6) for the remaining two panel units. IN1-70 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 452 If the number is other than 150,8000: Restoration of the serial number is successful. If the number is 150,8000: Compare with machine-specific CD and confirm that time stamp and contents are the same. If they are the same, the machine- specific has been successfully restored. If it is different, restoring the machine- specific has failed, so install the machine-specific again. (9) Click [Next]. IN1-71 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 453 Defect correction data is generated according to the background calibration during the CL termination. NOTE In case of the background calibration failed, restart the SE and execute from SE connection confirmation again. IN1-72 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 454 255.255.255.0, and locations assigned by 255 (mask value areas) indicate the network address. The default value of the network address is “192.168.0”. Segment No. 192.168.0.0 1200_700520E.ai Network address Host address 600_700206.ai IN1-73 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 455 Do not restart the MP and MC Manager for this step, but perform in the next step. 1200_700522E.ai REFERENCE Do not restart the SE for this step, but perform in the next step. IN1-74 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 456 (2) Restart all of the SE/MP/MC. (3) Open the Internet Explorer, input “http://(Changed the IP address of MC):19101/index.html” in the address bar and press the [Enter] key. DR Maintenance Software starts. IN1-75 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 457: 11. Image Calibration

    Messages of “Calibrating” and “Urgent use is possible” alternately appear on the DX Number of exposures: 4 BOTTOM panel Console status indication area. units #1 Check: Status indication *: Set the exposure time to 200 msec or less. 1200_700172E.ai IN1-76 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 458: Offset Calibration

    Images for offset correction data generation (4 frames) are read from the SE (FPD). If the offset correction data which was generated is stored on a HDD, a pop up window displaying “Succeeded” pops up. 1200_700489E.ai IN1-77 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 459: Gain Calibration

    Perform the full calibration for the target panel unit. - For CENTER panel unit Perform the full calibration and marker calibration. REFERENCE The focal size of the X-ray high voltage generator may be either large or small. IN1-78 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 460 INSTRUCTION u Set the exposure time to 200 msec or less. Exposure for longer than 200 msec cannot be made, since the maximum exposure time is inherently specified as 1200_700546E.ai 200 msec. IN1-79 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 461: Checking The Calibration Results

    Perform the procedures from “11.1_Offset Calibration” to “11.3_Checking the NOTE Calibration Results” at an installation site where two or more SEs are connected. {IN1:11.1_Offset Calibration} Do not perform defect calibration and lag calibration when installing. IN1-80 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 462: 12. Marker Calibration

    1300_700068E.ai REFERENCE will fail and create an abnormal image. Select an operative method from STAND / TABLE / FREE. (2) Select “CENTER_TOP” in “Position” and then click “Start” in “Marker Calibration”. IN1-81 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 463 (C) Installation positions for the calibration phantom (D) Align two calibration phantoms on the specific installation position for each boundary. REFERENCE The calibration phantom is the metal stick that is included with the MP. 1300_700057.ai IN1-82 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 464 (7) After checking that the green “Ready” button is lit, expose the 4th shot with the following conditions. Check that the exposure count turned to “4/4” . - Tube voltage of 80 kV, Amperage: 100 mA, Time: 20 msec, SID: 120 cm IN1-83 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 465 - LogAll (IMO.log / Calib.log) (2) Check that the calibration data have been generated. REFERENCE The data are stored in the following location. Check the time stamp of the file generated. - C:\Program Files\FujiFilm\MC\opt\config\machine\correct\PANEL2\ LPMarkerData.txt IN1-84 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 466 - Tube voltage of 80 kV, Amperage: 50 mA, Time: 13 msec, SID: 180 cm 1st shot 2nd shot 1300_700036E.ai u NOTE u If a misalignment is found, perform the full calibration and marker calibration for the CENTER panel unit again. IN1-85 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 467: 13. Checking For Image Problems

    1.5 mR are shown below. Distance: 180 cm {MT:4.1_Analyzing Moiré} Voltage: 55 kV Amperage and time: 1.6 mAs (When the amperage and the time can be specified, minimize the amperage.) IN1-86 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 468 - Routine files (a total of four images each for TOP, CENTER, BOTTOM and Synthesis) Obtain complete set of the Routine files having extensions other than “inf” that includes personal information. IN1-87 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 469: 14. Checking The Error Log

    (2) Click [ERROR DB] and check the error log. (2) Click [HISTORY]. (3) Click [DELETE]. (3) Click [DELETE]. 1200_700536E.ai (4) Click [OK] to clear the error log. 1200_700538E.ai (4) Click [OK] to clear the HISTORY. 1200_700537E.ai IN1-88 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 470: 16. Backing Up The Data

    SE correction data is saved. REFERENCE The correction data are saved in the backup folder of the Window with a file name “YYYYMMDDhhmmss-PANELS.ZIP”. “YYYYMMDDhhmmss” is a time stamp at saving. {MU1:1.10.1_SE Correct Data Backup/Restore} IN1-89 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 471 The error log are saved in the backup folder of the Window with a file name “YYYYMMDDhhmmss-MC-ALLLOG.ZIP”. “YYYYMMDDhhmmss” is a time stamp at saving. {MU1:1.10.6_LOG Backup} (5) Exit the DR Maintenance Software. 1200_700540.ai #2 Click: [All Log] #3 Click: [OK] 1200_700559E.ai The log file is saved. IN1-90 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 472: 17. Final Checks

    RemoteSwitchStatus “false”. There is no problem with MPX1ShotSwitch1stStepStatus “false”. There is no problem with SwitchStatus MPX1ShotSwitch2ndStepStatus “false”. There is no problem with MPX2ShotSwitch1stStepStatus “false”. There is no problem with MPX2ShotSwitch2ndStepStatus “false”. IN1-91 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 473 Withdraw Count Battery Temperature Temperature Battery Status Status Battery Cycle Count Cycle Count Any one of “0” to “65535” Battery First Use First Use Battery First Use First Use Date Date IN1-92 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 474: Visual Inspection And Cleaning Of The Machine

    IN1-93 18. Visual Inspection and Cleaning of the Machine Visually check the units for damage. If contaminated, wipe off with a dry cloth. IN1-93 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 475 IN1-94 BLANK PAGE IN1-94 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 476 IN1-95 BLANK PAGE IN1-95 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 477 Changes in pagination (FM9473) 40, 42 to50, 52, 53, 55 to 57, 59 to 95 03.31.2020 Revision for MC V17.2 (FM9623) DR-ID 1300 / DR-ID 1300PU Service Manual Installation (IN2) (RU PC-TOOL) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 478: Installation Work Flowchart

    6.5 Connecting the X-Ray shot cable 10.13 Forced Transfer of the SE Correct Data 6.6 Binding and Checking the Cables 10.14 Changing the IP Address of the SE/MP/MC 6.7 Reinstalling the Covers IN2-1 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 479 15. Clearing the EDIT HISTORY 16. Backing Up the Data 17. Final Checks 17.1 Checking the SE 17.2 Checking the Status of Boards 18. Visual Inspection and Cleaning of the Machine IN2-2 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 480: Installation Preparations

    NOTE The SE cable is always needed to install the machine. Prepare the SE cable for use of the jig if the SE cable (optional) is not purchased by the customer. IN2-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 481: Precautions In Installation

    - If the exposure stand is equipped without the external cover, the display of the panel effective area and overlapping part must be able to be checked. IN2-4 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 482: Transfer And Unpacking

    If the machine is to be transferred over differing floor levels, slowly move the machine not to shock it. Note that the carrier can come over a differing level up to approx. 10 mm. Transporting box 1300_700056E.ai IN2-5 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 483: Unpacking The Se

    (1) Take out the DX Console from transporting box. #1 Take out: SE Unpacking the Monitor Transporting box (1) Take out the monitor from transporting box. CD-R Fuse Letter of guarantee Vinyl sheet Transporting 1300_700006E.ai IN2-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 484 Letter of guarantee/Report of completion of installation/Notes on the X-ray Only inside Japan exposure/Performance check list n DR-ID 300CL For details on the DR-ID 300CL, refer to the DR-ID 300CL Service Manual. IN2-7 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 485 I/F box cable_Philips I/F box cable_110-3 wire I/F box cable_110-4 wire l SE cable-related Name Qty. Remarks SE cable 4m (Only for overseas) SE cable SE cable l Fixture Name Qty. Remarks Anchor fixing bracket of MP IN2-8 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 486: Installing The Mp

    Removing the Covers (1) Remove the MP top cover. #1 Loosen: T3x6 (x2) Rear cover Top cover 1200_700028E.ai 1200_700026E.ai (2) Remove the MP front cover. #1 Remove: T3x6 (x6) Front cover 1200_700027E.ai IN2-9 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 487: Checking The Power Cable

    (4) Set the main power switch to the OFF position after completion of the #1 Remove: T3x6 (x3) measurement. #2 Turn over: height retaining brackets (x3) #3 Tighten: T3x6 (x3) Bottom cover 1200_700150.ai IN2-10 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 488: Installing The Anchor Mounting Bracket (Optional)

    (2) Install the anchor mounting bracket to the MP. #1 Tighten: T3x6 (x4) 1200_700159.ai (3) Install the bottom cover. 1200_700151.ai #1 Tighten: T3x6 (x2) (4) Reinstall the bottom cover. #1 Tighten: T3x6 (x2) Bottom cover 1200_700154.ai 1200_700152.ai IN2-11 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 489: Connecting The Cables

    Connect the stand SE cable to the MPL5 and MPL7 cable connectors, and Cable tie (outside) connect the bed SE cable to the MPL6 and MPL8 cable connectors. 97 mm or more Cable tie (inside) 105 mm or more 1200_700175E.ai IN2-12 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 490 (3) Route the LAN cables between the MP and DX Console from the lower opening on the MP rear cover and connect them. #1 Route: LAN cable #2 Connect: LAN cable connector (MPC4) MPC4 1300_700009.ai IN2-13 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 491 The AC bucky relay unit (optional) is required when the bucky AC type is to be connected. GND_iso SHOT1 {IN2:6.5.3_Connecting the X-Ray Shot Cable (Bucky AC Type)} GO A AHN22005 SHOT1 GO B 600_700010.ai IN2-14 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 492 Contact Capacity SHOT GO The specifications of relays (K4, K5 and K6) are as follows. X-ray exposure l Relay model AHN22005 (Panasonic Electric Works) Charge accumulation of SE (FPD) l Rated control capacity Standard contact: 30 VDC 600_700011.ai l Maximum switching current IN2-15 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 493 (1) Insert the X-Ray shot cable (optional) from the upper opening on the MP rear cover. 11 BKY2 RDY2B 11 BKY1 RDY2B #1 Insert: X-Ray shot cable (optional) 12 NC2 12 NC1 600_700013.ai 1200_700029.ai IN2-16 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 494 11 BKY1 RDY2B If the second cable is not present, the procedure is not necessary. Proceed to the 12 NC2 12 NC1 procedure (7). 600_700016.ai #1 Insert: X-Ray shot cable (optional) 1200_700030.ai IN2-17 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 495 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape 1200_700031.ai <When two X-Ray shot cables are used> 600_700014.ai 1200_700032.ai IN2-18 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 496 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape #2 Tie: Cables #3 Retain: Reusable band (supplied accessory) 1200_700033.ai IN2-19 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 497 Shot AHN22005 +5V_iso Switch 1 BKY1 SHOT1 Prep RDY2B RDY1 TLP421F GND_iso SHOT1 RDY2 820Ω Shot Switch 2 SHOT1 RDY2 GND_iso SHOT1 GO A AHN22005 SHOT1 GO B BKY1 EXP 600_700022.ai IN2-20 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 498 The specifications of relays (K4, K5 and K6) are as follows. Bucky l Relay model BKY1 EXP AHN22005 (Panasonic Electric Works) l Rated control capacity X-ray exposure Standard contact: 30 VDC Charge accumulation of SE (FPD) l Maximum switching current 600_700023.ai IN2-21 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 499 Reusable band Bucky cable Part No.: LWS-3S V0 1200_700034.ai u NOTE u Abut the cable terminals as shown below when fastening them together. GOOD Cable Screw Terminal Terminal block NO GOOD 600_700132.ai IN2-22 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 500 If the second cable and the bucky cable are not present, the procedure is not necessary. Proceed to the procedure (7). Bucky cable 600_700026.ai #1 Insert: X-Ray shot cable (optional) and the bucky cable 1200_700035.ai IN2-23 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 501 8 BKY2 RDY1A 8 BKY1 RDY1A 9 BKY2 RDY1B 9 BKY1 RDY1B 10 BKY2 RDY2A 10 BKY1 RDY2A 600_700014.ai 11 BKY2 RDY2B 11 BKY1 RDY2B 12 NC2 12 NC1 Bucky cable 600_700028.ai IN2-24 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 502 <When two X-Ray shot cables and two bucky cables are used> 1200_700145.ai <When two X-Ray shot cables and two bucky cables are used> X-Ray shot cables Bucky cables X-Ray shot cables Bucky cables 1200_700146.ai 1200_700037.ai IN2-25 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 503 No cable terminal may remain depending on the X-ray high voltage generator to be connected in some cases. If no cable terminal remains, the procedure is not necessary. #1 Wrap: Plastic tape #2 Tie: Cables #3 Retain: Reusable band (supplied accessory) 1200_700033.ai IN2-26 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 504: Connecting The X-Ray Shot Cable (Bucky Ac Type)

    SHOT GO A BKY EXP A SHOT GO B BKY EXP B FGND FGND Relay AC100/110V : AHN210X0 AC110/120V : AHN210X1 AC200/220V : AHN210Y0 AC220/240V : AHN210Y2 AC Bucky Relay Unit 600_700033.ai IN2-27 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 505 200/220 VAC 4.5/6.5 mA Charge accumulation AHN210Y2: 220/240 VAC 4.1/5.9 mA of SE (FPD) - AHN12205 (Panasonic Electric Works) Standard contact: 250 VAC and 30 VDC 600_700034.ai l Maximum switching current IN2-28 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 506 600_700132.ai (1) Mount the AC bucky relay unit (optional) on the MP. #1 Tighten: TP3x6 (x4) MPX2-10 MPX1-10 AC bucky relay unit MPX2-11 MPX1-11 600_700036.ai *: Short cable (supplied accessory) 1200_700147.ai IN2-29 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 507 If the following specifications of the cable and the NO GOOD terminal are not observed, the machine might get damaged. - Cable: AWG18 to 22 thick - Terminal: FV1.25-M4 (J.S.T. Connector) - Crimp nippers: Manufactured by IZUMI; A125 600_700132.ai IN2-30 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 508 MP rear cover. #1 Remove: B3x6 (x4) AC bucky relay unit #1 Insert: X-Ray shot cable (optional) and the bucky cable Covers X-Ray shot cable Bucky cable 1200_700148.ai 1200_700038.ai IN2-31 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 509 X-Con BKY Stand Exp A X-Con SHOT2 RDY2 (L) X-Con BKY Stand Exp B X-Con BKY SHOT2 RDY2 (N) X-Con BKY Bed Exp A SHOT2 RDY2 (L) X-Con BKY Bed Exp B IN2-32 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 510 X-Con SHOT2 RDY2 (L) X-Con BKY Stand Exp B X-Ray shot cable 600_700051.ai X-Con BKY SHOT2 RDY2 (N) X-Con BKY Bed Exp A SHOT2 RDY2 (L) X-Con BKY Bed Exp B IN2-33 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 511: Binding And Checking The Cables

    <When two X-Ray shot cables and two bucky cables are used> X-Ray shot cables LAN cable (between MP and MC) X-Ray shot cable(s) LAN cable (between MP and AP) and the bucky cable(s) 1200_700039.ai Bucky cables 1200_700037.ai IN2-34 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 512: Reinstalling The Covers

    #1 Embed: Anchors (x2) u INSTRUCTION u Remove the cuttings that are stuck in the holes. u NOTE u The anchors corresponding to the anchor nut size should be prepared. 1200_700155.ai 1200_700007.ai IN2-35 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 513: Installing The Se

    The SE power is configured to be automatically turned OFF if an unregistered SE is (2) Turn ON the power of the MP. connected. A new SE needs to be registered before connecting it. IN2-36 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 514: Mounting The Nic Board To The Dx Console

    (4) Mount the network interface board. (5) Lower the latch, and fix the network interface board. Cover 600_700104.ai (6) Put on the cover removed in the procedure (2). Reverse the removal procedures for reinstallation. 600_700102.ai IN2-37 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 515: Connecting The Network Cables

    LAN cable DR-ID1300 SE cable 1300_700059E.ai NOTE In case of one DR-ID 1305SE configuration, connect the SE cable to MPL5 connector and MPL7 connector of the MPL65A board into the MP. IN2-38 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 516 [DR-ID 1200MC] 192.168.0.10 192.168.0.93 (TOP) (Eth1) 192.168.0.94 (CENTER) 192.168.0.95 (BOTTOM) 192.168.0.20 DR-ID 1305SE DR-ID 1300MP DR-ID 1305SE 192.168.0.90 (TOP) LAN cable 192.168.0.91 (CENTER) DR-ID1300 SE cable 192.168.0.92 (BOTTOM) DR-ID1200 SE cable 1300_700058E.ai IN2-39 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 517: Installing The Dx Console

    Refer to the DR-ID 300CL Service Manual. REFERENCE The MAC address of the MC is required during the setting operation on the CL. The MAC address of the MC appears by selecting “Network Address” in the “MUTL”. IN2-40 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 518: 10. Installing The Ru Software

    10.10 Updating SE Application Software Version 10.11 Setting the IP Address of the SE 10.12 Installing the Machine-Specific Data 10.13 Forced Transfer of the SE Correct Data 10.14 Changing the IP Address of the SE/MP/MC IN2-41 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 519: Installing And Setting The Nic Board To The Dx Console

    #1 Click: [Start] menu #2 Click: [Control Panel] 600_700238.ai (3) Click [Change adapter settings]. The Network Connections window opens. 600_700237.ai #1 Click: [Change adapter settings] The All Control Panel Items window opens. 600_700239.ai IN2-42 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 520 #1 Select: Use the following IP address #2 Input: IP address, Subnet mask (5) Select “Eth1”, and then select [Properties] from the right-click menu. The Network Properties dialog opens. #1 Right-click: Eth1 #2 Click: [Properties] 600_700241.ai 600_700243.ai IN2-43 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 521 The setting procedure up to here is for NIC, and from here is for Telnet. (12) Click [Programs and Features]. The Programs and Features window opens. #1 Click: [Programs and Features] 600_700245.ai 600_700248.ai IN2-44 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 522 #1 Check ON: “Telnet Client” and “Telnet Server” The Services window opens. #2 Click: [OK] #1 Double-click: Services 600_700250.ai (15) Click [←]. 600_700253.ai Return to the All Control Panel Items window. #1 Click: [←] 600_700251.ai IN2-45 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 523 #1 Click: [Start] menu [OK]. #2 Click: [Control Panel] Return to the Services window. #1 Select: Automatic #2 Click: [OK] 600_700237.ai (23) Click [Windows Firewall]. The Windows Firewall window opens. 600_700255.ai IN2-46 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 524 The system returns to the desktop screen. (25) Select [Inbound Rules]. #1 Select: Inbound Rules 600_700265.ai (26) Right-click [FTP Server Passive (FTP Passive Traffic-In)] and select "Enable Rule". The "Enabled" of [FTP Server Passive (FTP Passive Traffic-In)] changes to "Yes". #1 Right-click: FTP Server Passive (FTP Passive Traffic-In) #2 Click: Enable Rule 600_700266.ai IN2-47 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 525: Installing The Ru Pc-Tool

    [EXECUTE]. #1 Select: .\install\local\Install.bat #2 Click: [EXECUTE] Set Up PC-TOOL window 800_700211.ai (6) Press the <Y> key on the keyboard. The setup wizard window opens. 800_700208.ai The following window opens. 800_700209.ai IN2-48 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 526 (8) Click [Finish]. 800_700216.ai The License Agreement window opens. (11) Click [I Agree]. 800_700212.ai Upon completion of the installation, the WinPcap 4.1.3 Setup window opens. 800_700217.ai The Installation options window opens. IN2-49 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 527 (17) Check that the MC Manager icon has appeared on the task tray. 800_700218.ai The Completing the WinPcap 4.1.3 Setup Wizard window opens. (13) Click [Finish]. 800_700219.ai Upon completion of the installation, the following window opens. 800_700214.ai IN2-50 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 528 If the RU registration has been already completed, steps 4 and 5 are not necessary. Proceed to step 6. 800_700198.ai (3) Press the <Y> key on the keyboard. Upon completion of the configuration setting, the “Version Up Completed” opens. (4) Press the <Enter> key. IN2-51 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 529 #1 Check: the version and the media version that are installed on the device #2 Click: [Upgrade] 800_700207.ai The system returns to the desktop screen. (9) Remove the disk from the DVD drive. (10) Restart the PC. 800_700204.ai IN2-52 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 530: Installing The Ru Software

    The “Set Up PC-TOOL” window starts. 2. Select “.\Initial\apl_initial\install.bat” from the “FILE EXECUTION” pull-down menu, and then click [EXECUTE]. The “Are you sure you want to uninstall MC application?” dialog appears. 3. Click [OK]. 1200_700135.ai IN2-53 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 531 - MC application V3.4 or earlier: 16 one-byte characters - MC application V11.0 or later: 15 one-byte characters RU PC-TOOL window (input example) RU PC-TOOL window CONNECTION TEST RU NAME RU IP ADDR 127 1200_700084E.ai 1200_700083.ai IN2-54 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 532 #2 Verify: Lost = 0 (0% loss) RU PC-TOO window RU INSTALL window 1200_700086.ai (5) Select the software version “INSTALL VERSION” to be installed. #1 Select: INSTALL VERSION RU INSTALL window 1200_700085.ai INSTALL VERSION 1200_700087.ai IN2-55 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 533 The CL NAME window opens. REFERENCE You may make configuration settings. (10) Click [MODIFY] and change the IP address to “127.0.0.1”. #1 Select: CL0 #2 Click: [MODIFY] CL NAME window 1200_700088.ai 1200_700179E.ai IN2-56 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 534 (12) Make sure that the write into the HDD has completed, and press any key on the keyboard. #1 Check: “Install is complete”appears on the Command Prompt window #2 Press: Any key on the keyboard Command Prompt window 600_700066.ai IN2-57 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 535: Unlocking The Ru Pc-Tool's Security Lock

    Follow the procedure below to install the RU software. {IN2:10.2_Installing the RU PC-TOOL} 1200_700482.ai (2) Select “PCToolSecKeykey” inside the application disk drive, and click [Open]. ID900_J0215.ai The security lock is unlocked. IN2-58 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 536: Updating Mp Application Software Version

    Follow the procedures below when the version coincides with the version indicated in Readme.txt. {IN2:10.6_Configuration Settings} MP1 Version Check>>window REFERENCE The appropriate version of the MP application software is indicated in Readme.txt in the DR-ID 1300 MC APL software DVD. Readme.txt <Display example> MP Software ver 1200_700092E.ai 1200_700119.ai IN2-59...

  • Page 537: Updating Mp Application Software Version

    (5) Check that the installation is completed, and again start up the MP. MP Install>>window #1 Check: OK MP1 Install>>window MP1 Install>>window 1200_700096E.ai (6) Check the MP application software version. {IN2:10.5.1_Checking the MP Application Software Version} 1200_700094E.ai IN2-60 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 538: 10.6 Configuration Settings

    Click the upper left corner and then the upper right corner. DXL04010001.ai (3) Click [Device Setting] and click [Modify]. #1 Click: [Device Setting] #2 Click: [Modify] IIP Service Utility window Device Setting window 1200_700136.ai IN2-61 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 539 The system returns to the IIP Service Utility window. #1 Set: Reader Type #2 Click: [OK] Selector Setting window 1300_700011.ai 1200_700139.ai NOTE Correspond with the Edit Configuration settings. (7) Click [Setup Configuration Item]. IN2-62 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 540: Setting The Serial Id Of The Se

    The IP address to be entered in “IP Address” depends on the installation destination of the MC application. - To install in the DX Console: 127.0.0.1 #1 Input: HostName and IP Address (127.0.0.1) #2 Select: CU/MC #3 Click: [OK] New Node window 1200_700144.ai IN2-63 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 541 #1 Input: Serial ID #2 Click: [SET] SE1-10>> window SE1-10>> window 1300_700012E.ai (4) Check that the serial ID appears in the registration frame. #1 Check: Serial ID SE1-10>> window <Display example> 1200_700098E.ai 1300_700013E.ai IN2-64 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 542: Setting The Serial Id Of The Long Panel

    #2 Click: [SET] LongPanel Registration>> window LongPanel1 window LongPanel1 window 1300_700015E.ai (4) Check that the serial ID appears in the registration frame. #1 Check: Serial ID LongPanel1 window <Display example> 1300_700014E.ai 1300_700016E.ai IN2-65 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 543: 10.10 Updating Se Application Software Version

    (2) Click [VERSION CHECK] command, and then click [SE Version >>] and [SE1-10 >>]. #1 Click: [VERSION CHECK] #2 Click: [SE Version >>] #3 Click: [SE1-10 >>] VERSION CHECK window SE Version>>window SE1-10>>window 1200_700100E.ai IN2-66 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 544 The appropriate version of the SE application software is indicated in Readme.txt Check that the displayed version coincides with the version indicated in Readme. in the DR-ID 1300 MC APL software DVD. txt in the MC APL software DVD. Check the version in three subjects of “aplWlan Readme.txt <Display example>...
  • Page 545 (5) Check that the installation is completed, and click [Install SE LAN Install SE Software>>window Software]. #1 Check: OK #2 Click: [Install SE LAN Software] Install SE1 Software>>window 1200_700122E.ai (6) Click [OK] when the confirmation window opens. 1200_700120E.ai IN2-68 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 546 SE and check the SE application software version. If the update is not performed, update the SE MCU software version once again. (8) For the other panel units, perform steps (2) to (7) as required. IN2-69 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 547 The error occurs while the SE is being initialized. <Error indication> System Status is not IDLE. Please retry after returning System Status “IDLE” Error!! (4) Click [OK] when the confirmation window opens. IN2-70 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 548 #1 Select: Panel number #2 Click: [...] #3 Select: Following panel unit serial ID folder into the DVD drive IMAGE READING MODE High-Speed Mode Standard Mode CORRECTH CORRECTS #4 Click: [OK] IN2-71 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 549 “CORRECTS” folder. For the procedure for changing the folder selection, refer to “RU IMAGE FLAG window_IMAGE READING MODE” of “MU1.11_EDIT CONFIGURATION”. {MU2:1.11_EDIT CONFIGURATION} IN2-72 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 550 Make sure that “COMPLETE_DATASAVE” is displayed in the SE Correct Data Status >> window. “STILL_DATASAVE” is displayed during transfers. (3) For the other two panel units, perform step (2). (4) Click [BACK]. IN2-73 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 551 SE Correct Data Save Status >> window 1200_700187E.ai u INSTRUCTION u Mode3 is not used for DR-ID 1300 and thus “NG” is displayed, but you can ignore this judgment. (3) For other two panel units, perform steps (1) and (2). 1200_700186E.ai...
  • Page 552 INSTRUCTION If the IP address of the MP or the SE is lost by mistake during the operation procedures, restore the IP address. {IN:Appendix 2._Restoring the IP Address of the MP/SE} IN2-75 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 553: 11. Image Calibration

    *: Set the exposure time to 200 msec or less. {IN:Appendix 5._Defect Calibration and Lag Calibration} REFERENCE Messages of “Calibrating” and “Urgent use is possible” alternately appear on the DX Console status indication area. #1 Check: Status indication 1200_700172E.ai IN2-76 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 554: Offset Calibration

    When the offset correction data is generated and stored in the HDD, [OK] appears in the result display area. (5) After operations are completed, click [BACK] to return to the Calibration window. IN2-77 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 555: Gain Calibration

    Perform the full calibration for the target panel unit. - For CENTER panel unit Perform the full calibration and marker calibration. REFERENCE The focal size of the X-ray high voltage generator may be either large or small. 600_700178E.ai IN2-78 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 556 200 msec. REFERENCE Exposure condition examples for exposing an IP to a dose of 10 mR are shown below. (1305SE) SID: 215 cm Voltage: 75 kV Amperage: 100 mA Time: 90 msec IN2-79 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 557: Checking The Calibration Results

    - Gain calibration: PanelCorrectSensitivity.txt In the case of 150,8000, the restoration of the machine-specific data failed. Restore the machine-specific data again. u INSTRUCTION u Perform the procedures from “11.1_Offset Calibration” to “11.3_Checking the Calibration Results” at an installation site where two or more SEs are connected. {IN2:11.1_Offset Calibration} IN2-80 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 558: 12. Marker Calibration

    Select an operative method from Stand / Table / Free. The Marker Calibration >> window opens. #1 Click: [ Marker Calibration >> ] Marker Calibration >> window <Display example> Calibration window 1300_700001E.ai 1300_700030E.ai (6) Click [Calib Position] and select “Top_Center”. IN2-81 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 559 (C) Installation positions for the calibration phantom (D) Align two calibration phantoms on the specific installation position for each boundary. REFERENCE The calibration phantom is the metal stick that is included with the MP. 1300_700057.ai IN2-82 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 560 - Tube voltage of 80 kV, Amperage: 100 mA, Time: 20 msec, SID: 120 cm - Tube voltage of 80 kV, Amperage: 100 mA, Time: 20 msec, SID: 120 cm Marker Calibration >> window u NOTE u Do not move the irradiation field. 1300_700032E.ai 1300_700033.ai IN2-83 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 561 - LogAll (IMO.log / Calib.log) (3) Check that the calibration data have been generated. REFERENCE The data are stored in the following location. Check the time stamp of the file generated. - C:\Program Files\FujiFilm\MC\opt\config\machine\correct\PANEL2\ LPMarkerData.txt IN2-84 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 562 - Tube voltage of 80 kV, Amperage: 50 mA, Time: 13 msec, SID: 180 cm 1st shot 2nd shot 1300_700036E.ai u NOTE u If a misalignment is found, perform the full calibration and marker calibration for the CENTER panel unit again. IN2-85 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 563: 13. Checking For Image Problems

    1.5 mR are shown below. Distance: 180 cm {MT:4.1_Analyzing Moiré} Voltage: 55 kV Amperage and time: 1.6 mAs (When the amperage and the time can be specified, minimize the amperage.) IN2-86 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 564 - Routine files (a total of four images each for TOP, CENTER, BOTTOM and Synthesis) Obtain complete set of the Routine files having extensions other than “inf” that includes personal information. IN2-87 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 565: 14. Checking The Error Log

    14. Checking the Error Log (1) Start up the RU PC-TOOL. (2) Click [ERROR DB]. → The ERROR-DB window opens. (3) Check the error log. (4) Click [CLEAR] to clear the error log. (5) Exit the RU PC-TOOL. IN2-88 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 566: 15. Clearing The Edit History

    (5) Click the [TABLE] tab, and reset the counts. #1 Click : [TABLE] tab #2 Click : [RESET] #3 Click : [SET] EDIT HISTORY window <Display example> 600_700139.ai 600_700141.ai (6) Exit the RU PC-TOOL. IN2-89 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 567: 16. Backing Up The Data

    IN2-90 16. Backing Up the Data (1) Start up the RU PC-TOOL. (2) Back up “LOG ALL” and “CORRECT ALL DATA”. (3) Exit the RU PC-TOOL. IN2-90 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 568 (2) Click [MP Board State Check] and check the following board status. Make sure that the board is free from errors on the Board State display. - MP board status {MU2:[5.1]_MP Board State >>} - SE board status {MU2:[5.2]_SE Board State >>} IN2-91 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 569 IN2-92 18. Visual Inspection and Cleaning of the Machine Visually check the units for damage. If contaminated, wipe off with a dry cloth. IN2-92 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 570 IN2-93 BLANK PAGE IN2-93 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 571 IN2-94 BLANK PAGE IN2-94 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 572 IN2-95 BLANK PAGE IN2-95 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 573 AppxIN 3-1, AppxIN 5-2, 5-4, 5-6 12.28.2017 Revision for MC V16.2 (FM9490) AppxIN 8-1 DR-ID 1300 / DR-ID 1300PU 03.31.2020 Revision for MC V17.2 (FM9623) AppxIN 8-2 to 8-4, AppxIN 9-1 to 9-4 Service Manual Installation (AppxIN) 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 574: Appendix 1. Requirements Regarding Locally Obtained Parts

    Locally Obtained Parts and Their Requirements l Network cable and Network HUB {Product Specifications:6._Electrical Specifications_n I/F Cable} l PU power cable {Product Specifications:6._Electrical Specifications_n PU Power Cable} AppxIN1-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 575 AppxIN1-2 BLANK PAGE AppxIN1-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 576 AppxIN1-3 BLANK PAGE AppxIN1-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 577: Appendix 2. Restoring The Ip Address Of The Mp/Se

    <IP address of the SE (default value)> (2) Remove the MP top cover. IP address #1 Loosen: T3x6 (x2) 1305SE (TOP) 192.168.0.90 1305SE (CENTER) 192.168.0.91 Top cover 1305SE (BOTTOM) 192.168.0.92 1200_700026E.ai AppxIN2-1 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 578 Connect the jig cable after disconnecting the cable connector of the remote switch if the remote switch (optional item) is connected. #1 Connect: Jig cable <supplied accessory> Rear cover 1200_700028E.ai MPC2 1300_700028.ai AppxIN2-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 579: Appendix 2.2 Restoring The Ip Address Of The Se

    IP address, causing DR-ID 1305SE to malfunction. (1) Turn OFF the power of the MP. (2) Disconnect the SE cable from the SE. (3) Remove the SE rear cover. {MC:3.1.1_SE Rear Cover} AppxIN2-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 580 (8) Disconnect the jig cable you connect in the procedure (4) and connect the connector cable (RMV16). (9) Put on the SE rear cover. {MC:3.1.1_SE Rear Cover} (10) Set the COUNTRY CODE in “WIRELESS SETTING” window of EDIT CONFIGURATION. {MU2:1.11_EDIT CONFIGURATION} AppxIN2-4 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 581: Appendix 3. Replacement Procedure Of The Local Network

    - MP1 - SE1 WIRED - SE1 WIRELESS To make the changed set value effective, the set value needs to be enabled (setting executed) respectively for the SE, MP and MC. 1200_700163E.ai AppxIN3-1 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 582 #2 Input: MC/MP network address #3 Click: [SET] #3 Click: [SET] Local Network PreSetting>>window Local Network PreSetting >> window SE1-5>>window MC ETH1/MP>>window 1200_700164E.ai 1200_700166E.ai (4) Click [BACK] to return to the NETWORK SETTING window. AppxIN3-2 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 583 (4) Click [OK]. (7) Disconnect the SE cable from the SE. (8) If an unspecified SE exists, repeat procedures (1) to (7). (9) Connect the SE cable to the specified SE. AppxIN3-3 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 584 (9) Left-click the MC Manager from the task tray and excute "EXIT". Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from "Start menu" → "Start-up". AppxIN3-4 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 585 MC Manager from "Start menu" → "Start-up". (3) Start up the MUTL. (4) Click [NETWORK SETTING], [SE Network Setting >>] and the target SE button. Check that the IP address of the SE has been changed. AppxIN3-5 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 586: Appendix 3.2 Mc Eth0 Ip Setting

    (4) Left-click the MC Manager from the task tray and excute "EXIT". Check that the MC Manager icon has disappeared from the task tray, and then start the MC Manager from "Start menu" → "Start-up". (5) Exit the RU PC-TOOL. AppxIN3-6 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 587 AppxIN3-7 BLANK PAGE AppxIN3-7 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 588 AppxIN3-8 BLANK PAGE AppxIN3-8 018-234-02E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 589: Appendix 4. Precaution Before Using The Dr-Id 1300

    (such as body thickness and radiation quality). The CR long panel image has unevenness due to IPs overlapping each other. The DR-ID 1300 also generates visible unevenness in the image but the pattern of Top panel unevenness is different.
  • Page 590 A coarsely-grained band-like area appears near the stitching area with low dose due to panels overlapping each other. The image quality in this part is coarsely grained more than the upper and lower parts. Position of unevenness at stitching part 1300_700042E.ai AppxIN4-2 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 591 ● White band and black band (first example) at stitching Especially for a thick object, band-like artifacts may appear. part Black band 1300_700045E.ai White band Position of unevenness at stitching part Position of unevenness at stitching part 1300_700046E.ai AppxIN4-3 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 592 Position of unevenness at stitching part Object X-ray scattering forward as shown in 1300_700048E.ai the figure is blocked by the top panel and does not reach the center panel. Center 1300_700047E.ai AppxIN4-4 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 593 2 cm and 6 cm inwardly from the mark indicating the overlapping part of the panels on the exposure stand, respectively. Around 2 cm Around 6 cm (thin object) (thick object) 1300_700051E.ai AppxIN4-5 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 594 Position of unevenness at stitching part 1300_700053E.ai Position of unevenness at stitching Actual lead scale 鉛スケール実 物 part 1300_700055E.ai AppxIN4-6 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 595 S value can be calculated from the image captured at any place on the panel unit. BENEO long panel image Image boundary Image boundary A thin part of the object is blackened. 1300_700054E.ai AppxIN4-7 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 596 AppxIN4-8 BLANK PAGE AppxIN4-8 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 597: Appendix 5. Defect Calibration And Lag Calibration

    *: Set the exposure time to 200 msec or less. REFERENCE Messages of “Calibrating” and “Urgent use is possible” alternately appear on the DX Console status indication area. #1 Check: Status indication 1200_700172E.ai AppxIN5-1 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 598: Appendix 5.1 Dr Maintenance Software

    The focal size of the X-ray high voltage generator may be either large or small. REFERENCE Whether the calibration is successfully completed appears after completion. An error code is displayed in some cases. Refer to the Troubleshooting manual and take appropriate countermeasures. AppxIN5-2 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 599 As a result, because the number of the defects becomes an erroneous value and the defect size is increased more than expected, a calibration error may occur. AppxIN5-3 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 600: Appendix 5.1.2 Lag Calibration

    200 msec. REFERENCE Whether the calibration is successfully completed appears after completion. An error code is displayed in some cases. Refer to the Troubleshooting manual and take appropriate countermeasures. AppxIN5-4 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 601 When the log correction data is automatically generated and stored in the HDD, “Succeeded” appears after completion. u NOTE u If “NG” appeared, check the following. - Exposure condition - Exposure field is the entire SE. AppxIN5-5 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 602: Appendix 5.1.3 Checking The Calibration Results

    The description of the defect calibration is an example of the IMAGE READING MODE in DR Maintenance Software that is “High-speed Mode”. If two lines appeared for “Standard Mode”, there is no problem. AppxIN5-6 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 603: Appendix 5.2 Ru Pc-Tool

    If you click [Start] during automatic offset update (for 30 seconds every approx. 10 minutes), “Error 12700 currently unavailable” appears. Click [Start] again after an interval of approx. 30 seconds, in this case. AppxIN5-7 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 604 If you click [Create a Defect Data] when less than five exposures have been made, “Error!!” appears in the result display area. Continue to make exposures until five exposures are made, and click [Create a Defect Data], in this case. AppxIN5-8 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 605: Appendix 5.2.2 Lag Calibration

    Images of seven frames are read with a predetermined interval for one exposure. Clicking [Display Progress Status], you can know the number of image reads. The count is displayed in the format of “n/7” in the result display area after n-times of reads. AppxIN5-9 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 606 (9) Click [OK]. When the lag correction data is generated and stored in the HDD, [OK] appears in the result display area. (10) Select “Shut Down” in the menu of the DX Console. AppxIN5-10 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 607: Appendix 5.2.3 Checking The Calibration Results

    Restore the machine-specific data or perform the defect calibration again. REFERENCE The description of the defect calibration is an example of the IMAGE READING MODE in EDIT CONFIGURATION that is “High-speed Mode”. AppxIN5-11 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 608 AppxIN5-12 BLANK PAGE AppxIN5-12 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 609: Appendix 6. Lattice

    BOTTOM are positioned within ±5 mm from the longitudinal center of the long panel. -15° -15° 5 mm 5 mm SID= 180 cm Lattice table Lattice scale 1300_030006E.ai CENTER BOTTOM 1300_030007E.ai AppxIN6-1 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 610 - Some lattices overlap each other and disappear of the lattice and no blurring in the vertical direction. - The lattice is imaged correctly 1300_030004.ai - A part of lattice is vertically blurred 1300_030003.ai 1300_030005.ai AppxIN6-2 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 611 AppxIN6-3 BLANK PAGE AppxIN6-3 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 612 AppxIN6-4 BLANK PAGE AppxIN6-4 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 613: Appendix 7. Installing The Ru Pc-Tool (Mc V3.X Or Earlier)

    (2) Turn ON the CL power. 1200_700143E.ai (3) Insert the install disk into the DVD drive of the CL. Upon inserting the install disk into the DVD drive, the “Set Up PC-TOOL” window automatically starts. AppxIN7-1 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 614 (8) Click [Finish]. Upon clicking [Finish], the Command Prompt window opens. When the Command Prompt window appears, press any key on the keyboard. The Command Prompt window appears three times. 600_700054.ai AppxIN7-2 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 615 The MC application is installed and the dialog to confirm the installation opens. #1 Click: [OK] 600_700259.ai (3) Click [OK]. #1 Click: [OK] 1200_700106.ai The “Installation options” window opens. 600_700277.ai (4) Click [OK]. The “Welcome to the WinPcap 4.1.3 Setup Wizard” window opens. AppxIN7-3 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 616 The “Completing the WinPcap 4.1.3 Setup Wizard” window opens. and then click [EXECUTE]. (8) Click [Finish]. The “Are you sure you want to uninstall MC application?” dialog appears. 3. Click [OK]. #1 Click: [Finish] 1200_700108.ai AppxIN7-4 018-234-03E DR-ID 1300 / DR-ID 1300PU Service Manual...

  • Page 617: Appendix 8. Installing The Internet Explorer 11

    (3) Insert the install disk into the DVD drive of the CSL-PC. INSTRUCTION Use the following installation media. Internet Explorer 11 installation media: 114Y2312721A00 (4) When the following window opens, press any key on the keyboard. 1200_7C0017.ai The installation processing starts. 1200_7C0014.ai AppxIN8-1 018-234-05E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 618 If a Windows service “Windows Update(wuauserv)” required for applying a security patch is not started up, the 1058 error will occur, failing in installation. Move to “Control panel” - “Management tool” - “Service” to check if the “Windows Update” has started AppxIN8-2 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 619 1200_7C0019.ai - Troubleshooting for when the installing of IE11 has failed Check the following Windows Update error code list, and do a workaround. https://support.microsoft.com/ja-jp/kb/2872074 - Windows Update error code list https://support.microsoft.com/ja-jp/kb/938205 AppxIN8-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 620 If an error is generated by the installing (Step 03) of a compulsory update program after the installing of IE11. 1200_7C0021.ai Check the following Windows Update error code list, and do a workaround. - Windows Update error code list https://support.microsoft.com/ja-jp/kb/938205 AppxIN8-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 621 Current part number (New FPGA memory equipped part) RMV65A service part for 857Y120057 857Y200090 DR-ID 1200 RMV66A service part for 857Y120105 857Y200091 DR-ID 1200 RMV65A service part for 857Y120005 857Y200089 DR-ID 1300 AppxIN9-1 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 622 If the SE’s IP address is not the default, select “IP Address” from “Setting”. 1300_70J002.ai In the “IP Address Setting” window, enter the SE’s IP address and click [Close]. 1300_70J003.ai When the jig software is connected to the SE, the next window automatically appears. AppxIN9-2 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 623 1300_70J005.ai After about seven minutes, the installation is completed with the information below appearing. 1300_70J006.ai (7) Click the “X” on the upper right of the screen, and exit the jig software. AppxIN9-3 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 624 AppxIN9-4 BLANK PAGE AppxIN9-4 018-234-06E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 625 Control Sheet Issue date Revision number Reason Pages affected 03.31.2016 New release (FM9369) All pages 06.30.2017 Revision for MC V15 (FM9473) All pages DR-ID 1300 / DR-ID 1300PU Service Manual Performance Check (PC) 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 626 DR-ID 1300 Performance Check List n Settings l Housing network settings The purpose of this performance check list is used at the time of DR-ID 1300 installation to record the steps performed, measured values, and settings, which MC IP address: ____________________________________ are based on the instructions set forth in the Service Manual.
  • Page 627  OK  NG Resistance value measured between L and FG: ______Ω (specified value: ∞)  OK  NG {IN1:11._Image Calibration} Resistance value measured between L and N: ______Ω {IN2:11._Image Calibration} (specified value: 100 kΩ or higher)  OK  NG 4.6 Marker Calibration  OK  NG {IN1:12._Marker Calibration} {IN2:12._Marker Calibration} PC-2 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...
  • Page 628  OK  NG 8. Test equipment used for the check Test equipment: ____________ Model: ____________ S/N: ____________ Test equipment: ____________ Model: ____________ S/N: ____________ Test equipment: ____________ Model: ____________ S/N: ____________ PC-3 018-234-04E DR-ID 1300 / DR-ID 1300PU Service Manual...

This manual is also suitable for:

Dr-id 1300pu

Table of Contents

Save PDF
