FujiFilm FDR ES DR-ID1270 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

(DR-ID1270)
Operation Manual
6th Edition : July 2018
897N120821E
This Operation Manual describes details on how to operate the DR-ID1270 and
cautions to be observed when operating it.
After reading this manual, store it nearby the DR-ID1270 so that you can see it
whenever necessary.
For Safe Operation
System
Configuration
(Product Overview)
Basic Operation
Daily Inspection and
Maintenance
Appendix
Maintenance and
Inspection

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FDR ES DR-ID1270 and is the answer not in the manual?

Questions and answers

Related Manuals for FujiFilm FDR ES DR-ID1270

Summary of Contents for FujiFilm FDR ES DR-ID1270

  • Page 1 For Safe Operation System Configuration (Product Overview) (DR-ID1270) Basic Operation Operation Manual 6th Edition : July 2018 Daily Inspection and Maintenance Appendix Maintenance and Inspection This Operation Manual describes details on how to operate the DR-ID1270 and cautions to be observed when operating it. After reading this manual, store it nearby the DR-ID1270 so that you can see it whenever necessary.
  • Page 2 DR-ID1270 Operation Manual 897N120821E...
  • Page 3 Intended Use (for European Union and other countries.) The Fujifilm DR-ID1270 provides digital image capture for radiographic examinations. It is intended for use in general projection radiographic applications wherever conventional screen-film systems or CR systems may be used. DR-ID1270 is a device that provides images, which diagnostic image process is not implemented, to image collecting console.
  • Page 4 Source codes for certain type of open source software used in this product are available at delivery cost. If you would like to receive such source codes, please contact FUJIFILM dealer or the service representatives at the agency from which you purchased this product. (Please be noted that any inquiries concerning the contents of source codes should be directed to original licensors of open source software.)

  • Page 5: Table Of Contents

    Contents Introduction ...........................iii Chapter 1 For Safe Operation Safety ........................1-1 Electromagnetic Compatibility (EMC) ..............1-11 1.2.1 DR-ID1270 ......................1-11 Precautions in Using the DR-ID1270 ..............1-16 1.3.1 Handling .........................1-16 1.3.2 Before Exposure ....................1-18 1.3.3 During Exposure ....................1-18 1.3.4 During Cleaning .....................1-19 1.3.5 Storage ........................1-19 1.3.6...
  • Page 6 Appendix A Specifications Specifications ......................A-1 A.1.1 Reduced Equivalent (DR-ID1270) ................A-1 A.1.2 Power Supply Conditions ..................A-1 A.1.3 Environmental Conditions ..................A-1 A.1.4 Image Performance ....................A-2 A.1.5 Load Restriction ...................... A-2 A.1.6 Radio Waves ......................A-2 External View and Weight ..................A-3 A.2.1 DR-ID1270 ......................

  • Page 7: Chapter 1 For Safe Operation

    For Safe Operation Chapter 1 1.1 Safety Before using the DR-ID1270, read this section thoroughly to ensure that you use the product properly. Electric Shock Warnings and Cautions WARNING This product is internal power supply equipment. To avoid electric shocks, users should always take the following precautions: ●...
  • Page 8 WARNING Do not disassemble or remodel the equipment. Otherwise, fire or electric shock may result. Keep away from the parts inside the product, which may cause electric shock. If you touch them accidentally, death or severe injury may result. WARNING Do not hit or drop the equipment or subject it to severe shock.
  • Page 9 If any of the following occurs, immediately turn off the power of each unit, unplug the power cable from the outlet, and then contact our official dealer or FUJIFILM Representative. ● When smoke, strange odor, or abnormal sound is present.
  • Page 10 CAUTIONS When the devices are used outdoors in wireless communication mode, contact our official dealer or FUJIFILM Representative. CAUTIONS/ATTENTION Do not place any object in a place where removal of the power cable is prevented. Ne placez aucun objet à un emplacement gênant le débranchement du câble d’alimentation.
  • Page 11 System Isolation Instructions WARNING To ensure complete system isolation, never install any unauthorized items. When it is necessary to install authorized optional items, contact our official dealer or FUJIFILM Representative. WARNING Keep the products other than those used for patients out of their reach to ensure appropriate system isolation.
  • Page 12 Disinfectant ethanol is recommended for disinfection. Carefully read the instructions and cautions supplied with the disinfectant before use. For details on the disinfectant, contact a FUJIFILM dealer or the service representatives at the agency from which you purchased the disinfectant.
  • Page 13 ● Use or store the battery pack only in the environmental conditions specified by FUJIFILM Corporation. If the battery pack is used or stored in a place where it is exposed to high temperature, the battery pack may emit smoke, ignite, explode or leak fluid.
  • Page 14 ● Do not reverse the positive (+) and negative (-) terminals. Otherwise, the battery pack may be reverse-charged during charging. As a result, abnormal chemical reactions may occur inside the battery pack, or extremely high current may flow during discharging, causing it to overheat, emit smoke, explode or ignite.
  • Page 15 No modification of this equipment is allowed. CAUTIONS Install the system in accordance with what is provided by IEC 60601-1:2005 + A1:2012 Chapter 16. Contact our official dealer or FUJIFILM Representative for installation (except the flat panel sensor) of the system. CAUTIONS Do not hit or drop the equipment.
  • Page 16 Contraindications and Prohibitions No contraindications present. Classification ● According to the type of protection against electrical shock Internally powered equipment (when only the flat panel sensor is used) Class 1 equipment (when connected to the power supply unit and power box) ●...

  • Page 17: Electromagnetic Compatibility (Emc)

    If the problem cannot be solved with the above measures, stop using this equipment and consult the manufacturer, our official dealer or FUJIFILM Representative for help. WARNING ● Do not place devices generating electromagnetic wave near this equipment.
  • Page 18 4. The use of optional items, transducers and cables other than those specified, with the exception of transducers and cables sold by FUJIFILM Corporation as replacement parts for internal components, may result in increased emissions or decreased immunity of the DR-ID1270.
  • Page 19 Table 2 Guidance and manufacturer’s declaration - electromagnetic immunity The DR-ID1270 is intended for use in the electromagnetic environment specified below. The customer or the user of the DR-ID1270 should assure that they are used in such an environment. IEC 60601-1-2 Electromagnetic environment - Immunity test Compliance level...
  • Page 20 Table 3 Guidance and manufacturer’s declaration - electromagnetic immunity The DR-ID1270 is intended for use in the electromagnetic environment specified below. The customer or the user of the DR-ID1270 should assure that they are used in such an environment. Immunity test IEC 60601-1-2 Compliance level Electromagnetic environment - guidance...
  • Page 21 Table 4 Recommended separation distances between Portable and mobile RF communications equipment and the DR-ID1270 The DR-ID1270 is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the DR-ID1270 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the DR-ID1270 as recommended below, according to the maximum output power of the communications equipment.

  • Page 22: Precautions In Using The Dr-Id1270

    1.3 Precautions in Using the DR-ID1270 This section describes the precautions in using the DR-ID1270. 1.3.1 Handling Handle the flat panel sensor carefully since they are manufactured with precision. If the flat panel sensor or the SE communication cable is hit or dropped or is subjected to severe shock, it may be malfunction.
  • Page 23 If a seal that covers a screw peels from the side surface of the flat panel sensor, contact a FUJIFILM dealer. If the seal is not attached, artifacts caused by discharge of static electricity may appear. To ensure optimal image quality, it is recommended that you do not use the flat panel sensor near devices (motor, transformer, switching supply, etc.) that generate electromagnetic noise.

  • Page 24: Before Exposure

    DR-ID1274SE and DR-ID1275SE : 120kg (264.6 lb) / ø40mm (1.6 in.) (Based on FUJIFILM measurement specifications) Use the flat panel sensor on a flat floor or platform. When an excessive force is applied to the unit when it is tilted, the sensor inside the flat panel sensor may be damaged.

  • Page 25: During Cleaning

    When the SE communication cable is connected to the fl at panel sensor to make an exposure on a bed, follow the precautions below. Otherwise a load may be applied locally to the SE communication cable connectors, causing damage to the fl at panel sensor. Make sure that the connector Do not place the connector Do not raise the flat...

  • Page 26: Precautions Related To The Load Applied To The Flat Panel Sensor

    1.3.6 Precautions Related to the Load Applied to the Flat Panel Sensor If excessive load is applied to the fl at panel sensor, use it on a fl at fl oor or platform. When making an exposure for the patient in a wheelchair or adjustable bed or on a stretcher, the fl at panel sensor may be deformed (slightly warped).

  • Page 27: Radio Waves

    1.3.7 Radio Waves Wireless specifications for the flat panel sensor and access point are as follows. Flat panel sensor Access point (optional) Wireless specification IEEE802.11n IEEE 802.11n Transmit frequency 5.2, 5.3, 5.6, 5.8, 2.4 GHz 5.2, 5.3, 5.6, 5.8, 2.4 GHz Modulation OFDM OFDM...
  • Page 28 1-22 DR-ID1270 Operation Manual 897N120821E...

  • Page 29: Chapter 2 System Configuration (Product Overview)

    System Configuration Chapter 2 (Product Overview) 2.1 DR-ID1270 2.1.1 System Confi guration DIGITAL RADIOGRAPHY DR-ID1270 Flat panel sensor unit Flat panel sensor unit Flat panel Flat panel sensor sensor Power supply unit* Power box* DR-ID 1200MC (software)* Image processing unit Access point Battery charger DR-ID 300CL*...

  • Page 30: Features Of The Dr-Id1270

    10 By using a notebook computer as the image processing unit, and also by using the optional FUJIFILM access point together with the image processing unit, the combination can be used as a mobile system for rounds, since the need of carrying cables is eliminated. In addition, exposures can also be made outdoors depending on the frequency band of radio wave.

  • Page 31: Unit Names And The Functions

    2.2 Unit Names and the Functions Unit names and the functions of the DR-ID1270 are described below. * Exposure plane is shown in this figure. Applied part Battery pack level indicator Status lamp <Front> <Back> Flat panel sensor Name Description Flat panel sensor The DR-ID1271SE and DR-ID1272SE incorporate a GOS indirect panel.
  • Page 32 ■ SE cable Name Description SE cable A cable that connects the flat panel sensor and the power supply unit. This cable is used for adding the second and subsequent flat panel sensors,changing over the connection between the flat panel sensors, and other usages.

  • Page 33: Locations Of Labels And Signs

    2.3 Locations of Labels and Signs Locations of labels and signs affixed to the DR-ID1270, and the relevant safety signs are shown below. 2.3.1 Locations of Labels Flat panel sensor (DR-ID1271SE) Flat panel sensor (DR-ID1272SE) Serial Number Label Serial Number Label DR-ID1272SE DR-ID1271SE Radio Law Certification Label...
  • Page 34 DR-ID 1200MP Rating Label contactez notre revendeur agréé DR-ID1270MP Caution Label 2 ou notre représentant FUJIFILM. Bracket for MP Identification Label Power supply unit (DR-ID 1200MP/DR-ID1270MP) DR-ID 1200MP Identification Label DR-ID 1200MP Rating Label DR-ID 1200MP/DR-ID1270MP...
  • Page 35 Identification Label Pour en savoir plus sur les types de câbles connectables, contactez notre revendeur agréé Power box (DR-ID 1200PB/DR-ID1270PB) ou notre représentant FUJIFILM. DR-ID 1200PB Identification Label DR-ID 1200PB Rating Label DR-ID 1200PB/DR-ID1270PB DR-ID1270PB Identification Label DR-ID1270PB Rating Label...

  • Page 36: Safety And Other Symbols

    At the same time, your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information about waste, please contact our official dealer or FUJIFILM Representative. Year of manufacture Caution for local load / Do not drop the flat panel sensor to the user/patient...

  • Page 37: Symboles De Sécurité Et Autres

    Votre coopération pour la mise au rebut correcte de ce produit contribuera en outre à une utilisation efficace des ressources naturelles. Pour en savoir plus sur les déchets, contactez notre revendeur agréé ou notre représentant FUJIFILM. Année de fabrication Attention relative à une charge placée de façon localisée / Ne faites pas tomber le détecteur à...

  • Page 38: Installation Conditions

    2.4 Installation Conditions 2.4.1 Definition of Patient Environment For the products that can be installed in patient environment, see “2.1.1 System Configuration” (page 2-1). CAUTIONS In the X-ray room, do not install the power supply unit, access point, image processing unit and battery charger (optional) in areas where the user could easily trip over them.

  • Page 39: Installation Precautions

    2.4.2 Installation Precautions ■ Using in an open space Install the fl at panel sensor, the access point and the image processing unit at a distance of less than 10m (32.8 ft) from each other. If any distance is over 10m (32.8 ft), a wireless communication error may occur.

  • Page 40: Wireless Specifications

    Wireless range : max. 10m (32.8 ft) from the Access point as tested. Actual range may vary. Data transfer rate : 35Mbps (DR-ID1270 : between the Flat Panel Sensor and Console PC) (This value is FUJIFILM measuring result of wireless module, and actual data rate may vary.) Transfer Power : 17 dBm or less Modulation : OFDM (Provided by IEEE802.11n)
  • Page 41 Quality of Service (QoS) DR-ID1271SE/DR-ID1272SE/ DR-ID1273SE/DR-ID1274SE/ Item Standard Unit Remarks DR-ID1275SE Form of electric Spectrum diffusion wave Center frequency HT20 5180 - 5825 MHz 36ch,40ch,44ch,48ch 2412 - 2472 HT40 5190 - 5795 38ch,46ch 2422 - 2462 Channel interval IEEE802.11n 20(HT20) / 40(HT40) Transmission rate IEEE802.11n HT20：MCS0-15...
  • Page 42 2-14 DR-ID1270 Operation Manual 897N120821E...

  • Page 43: Chapter 3 Basic Operation

    3.1.2 Number of the Connectable Flat Panel Sensors To enable the fl at panel sensor, its ID needs to be registered in advance by our offi cial dealer or FUJIFILM Representative. Up to a hundred fl at panel sensors can be registered.

  • Page 44: Inserting/Removing The Flat Panel Sensor Into/From The Radiographic Examination Stand

    3.1.4 Inserting/Removing the Flat Panel Sensor into/from the Radiographic Examination Stand Follow the procedure below to insert/remove the fl at panel sensor into/from the radiographic examination stand. For details, see the Operation Manual for the radiographic examination stand CAUTIONS For the positioning at the time of inserting/removing the fl at panel sensor, see the Operation Manual for the radiographic examination stand.
  • Page 45 [1] Upright type Set the flat panel sensor to the upper part of the tray. CAUTIONS When inserting the flat panel sensor into the radiographic examination stand, direct the exposure plane toward the X-ray tube. Pull out the tray. Push the tray back into place after setting Tray the flat panel sensor.

  • Page 46: Changing The Direction Of The Flat Panel Sensor Connector

    The direction of the connector of the flat panel sensor can be changed, depending on how it is inserted into the radiographic examination stand. To change the direction, contact our official dealer or FUJIFILM Representative. When shipped After changing the direction...

  • Page 47: Charging The Battery Pack For The Flat Panel Sensor

    Charge the battery pack (optional) using the battery charger (optional). CAUTIONS Do not charge the battery pack other than those designated by FUJIFILM Corporation. If the battery pack is charged under the charging conditions (voltage, current and charging method) different from those specified by FUJIFILM Corporation, the battery pack may emit smoke, ignite, explode or leak fluid.

  • Page 48: Installing/Removing The Battery Pack For The Flat Panel Sensor

    3.1.7 Installing/Removing the Battery Pack for the Flat Panel Sensor Follow the procedure below to install/remove the battery pack for the flat panel sensor. When installing/removing the battery pack, place the flat panel sensor on a flat place. Do not remove the battery pack until a processed image appears in the window of the image processing unit after the exposure.
  • Page 49 3.1.8 Lamp Indications on the Flat Panel Sensor This section explains the indications of the battery pack level indicator. For other lamp indications, see “2.2 Unit Names and the Functions”. ■ Battery pack level indicator LED0 LED3 LED2 LED1 (When the battery pack is being charged) Fully charged LED1, 2, 3: Lit in green Available time: 60 minutes or more...

  • Page 50: Starting Up And Shutting Down The System

    3.2 Starting Up and Shutting Down the System This section explains how to start up and shut down the system. Operations are required on the power supply unit, power box, flat panel sensor and image processing unit. The procedure below is an example of using the image processing unit DR-ID 300CL. For details on the image processing unit being used, see the Operation Manual provided with the personal computer.

  • Page 51: Shutting Down The System

    CAUTIONS An error occurs if the system is started up immediately after shutdown. To restart the system including the control cabinet, make sure that the power status LED of the control cabinet is off, and then press the power switch for the image processing unit. CAUTIONS ●...
  • Page 52 Turn off the display as necessary. Make sure that calibration of the flat panel sensor is completed. When completed, the READY lamp of the flat panel sensor turns off. When the optional access point is used, remove the access point from the image processing unit. Remove the battery pack from the flat panel sensor.

  • Page 53: Sleep Mode

    3.3 Sleep mode When sleep mode is enabled, if no operation is performed for about two minutes without an exposure menu registered, the flat panel sensor will enter sleep mode and the power state is changed to the power-saving state. Once an exposure menu is registered, sleep mode is canceled automatically.
  • Page 54 3-12 DR-ID1270 Operation Manual 897N120821E...

  • Page 55: Chapter 4 Daily Inspection And Maintenance

    Daily Inspection and Chapter 4 Maintenance 4.1 Daily User Inspection and Maintenance During maintenance and inspection, strictly observe precautions contained in “Chapter 1 For Safe Operation” in this manual for you to use the DR-ID1270 under best conditions. 4.1.1 Periodical Inspection Inspection Every Three Months Once every three months, remove any dirt or dust accumulated in each part of the equipment using a vacuum cleaner or air duster, clean each part with a slightly moistened soft cloth and then wipe off...
  • Page 56 DR-ID1270 Operation Manual 897N120821E...

  • Page 57: Appendix A Specifications

    Specifications Appendix A A.1 Specifications Specifications of the DR-ID1270 are shown below. A.1.1 Reduced Equivalent (DR-ID1270) Peak reduced equivalent on the front panel of the flat panel sensor: 0.5 mmAl A.1.2 Power Supply Conditions ■ Flat panel sensor Rated voltage : 6-12V Input current : 2.73A ■...

  • Page 58: Image Performance

    300kg (661.5 lb) Local load : DR-ID1271SE, DR-ID1272SE, DR-ID1273SE, DR-ID1274SE, DR-ID1275SE : 120kg (264.6 lb) / ø40mm (1.6in.) (Based on FUJIFILM measurement specifications) CAUTIONS Do not apply an excessive force to the exposure plane. The sensor inside the flat panel sensor may be damaged, and it may not be possible to make an exposure properly.

  • Page 59: External View And Weight

    A.2 External View and Weight The external view and weight of the DR-ID1270 are shown below. Specifications, dimensions and weight are subject to change for improvement without prior notice. A.2.1 DR-ID1270 Width Depth Height Weight (mm(in.)) (mm(in.)) (mm(in.)) (kg(lb)) Flat panel sensor (DR-ID1271SE) 460(18.1) 384(15.1) 15(0.6)
  • Page 60 Unit: mm(in.) 328(13.0) 15(0.6) 120(4.7) 388(15.3) Flat panel sensor (DR-ID1275SE) Power supply unit 259(10.2) 205(8.1) Power box The effective area of the flat panel sensor is as shown in the figure below. 17.25 425.4(16.7) 17.25 (0.68) (0.68) 17.25 425.4(16.7) 17.25 (0.68) (0.68) Effective...
  • Page 61 ■ Battery charger (optional) Width Depth Height Weight (mm(in.)) (mm(in.)) (mm(in.)) (kg(lb)) Battery charger 92.5(3.6) 259(10.2) 56(2.2) 0.6(1.3) AC adapter 153(6.0) 67(2.6) 35(1.4) Approx.0.51(1.1) Unit: mm(in.) 153(6.0) 67(2.6) AC adapter 92.5 (3.6) 259(10.2) Battery charger DR-ID1270 Operation Manual 897N120821E...

  • Page 62: Characteristics

    ● DICOM calibrated (5) Image Quality Evaluation Fujifilm typically conducts reader studies that compare new DR-ID1270 detector models to chosen marketed devices. These studies, involving an assessment of image quality by board-certified radiologists, have demonstrated that the images acquired using the DR-ID1270 detectors are deemed to be of diagnostic capability.

  • Page 63: Appendix Z Precautions For Exposure

    Precautions for Exposure Appendix Z Z.1 Precautions for the Automatic X-ray Detection Function Z.1.1 Precautions for Making an Exposure 1 The fl at panel sensor cannot detect X-rays automatically unless Shot Ready (exposure ready status indicator) on the image processing unit, the READY lamp among the status lamps on the fl at panel sensor is lit green.

  • Page 64: Precautions Related To The X-Ray Exposure Time

    4 When an exposure menu is registered and the system is ready for an exposure, the flat panel sensor enters X-ray detection mode. If an exposure is not made for a period of time while an exposure menu is registered, the operating time of the flat panel sensor’s battery pack may be reduced to half.

  • Page 65: Other Precautions

    Z.2 Other Precautions Z.2.1 Precautions for Exposure of a Subject in Relatively Large Contrast 1 Exposures using a contrast medium may cause artifacts around it. 2 When exposing a subject with any metal objects implanted, artifacts may appear around them. 3 For exposures with objects of large X-ray absorption, such as lead characters and metals for measurement, artifacts may appear around them.

  • Page 66: Precautions For Urgent Use

    Z.2.5 Precautions for Urgent Use When you start a study before completion of the calibration at the time of startup, the operation will be in Urgent Use Mode. At this time, “Urgent use is possible” appears in the “Output Device Status window”...

  • Page 67: Precautions For Using The Access Point

    Z.2.11 Precautions for Using the Access Point When making an exposure with the access point, do not remove the USB cable until the image appears on the image processing unit and ShotReady lights green. Also, with the supplied Velcro tape and clamp or by other means, secure the USB cable before use to prevent it from being disconnected accidentally.
  • Page 68 DR-ID1270 Operation Manual 897N120821E...

  • Page 69: Appendix O Use Of Optional Items

    Use of Optional Items Appendix O O.1 Optional Items Name Description SE storage case* A case used for carrying and storing the flat panel sensor. For the external view and precautions, see “O.2 Using the SE Storage Case” (page O-2). Battery pack* A battery pack for the flat panel sensor.

  • Page 70: Using The Se Storage Case

    O.2 Using the SE Storage Case SE storage case for 35 SE storage case for 43 (DR-ID1271SE/DR-ID1273SE) (DR-ID1272SE/DR-ID1274SE) CAUTIONS ● Do not store the SE storage case in a location with the following conditions. ● Where the SE storage case is exposed to direct sunlight. ●...

  • Page 71: Power Supply Unit

    O.3 Power Supply Unit Power status LED Main switch Power supply unit Name Description Main switch Supplies the power to the flat panel sensor and the inside of the power supply unit. Power status LED Displays ON/OFF of the power supply unit. O.4 Power Box Power status LED Power box...

  • Page 72: Access Point

    ● Do not subject the Access Point to severe shock (by dropping it, etc.). ● When using the Access Point, place it at least 20cm (7.9in.) away from the body. ● To supply power to the Access Point, connect it to the FUJIFILM-specified personal computer supporting USB 3.0.
  • Page 73 Precautions for LAN Connection CAUTIONS ● For the LAN connection, use the dedicated LAN conversion cable. In addition, when connecting or disconnecting the LAN conversion cable, be sure to hold the connector portion. If it is connected or disconnected while holding the cable, the cable may be broken. ●...
  • Page 74 DR-ID1270 Operation Manual 897N120821E...

  • Page 75: Maintenance And Inspection

    (1 hour and 40 minutes) Operable time [Minute] The cycles of periodical maintenance and inspection and of parts replacement differ depending on the usage and the daily operation time. For details, contact our official dealer or FUJIFILM Representative. DR-ID1270 Operation Manual 897N120821E...
