Altera cyclone V Technical Reference page 2308

18-218
hctsiz5
Bit
0
xfercomplmsk
hctsiz5
Buffer DMA Mode
Module Instance
usb0
usb1
Offset:
0x5B0
Access:
RW
31 30
dopng pid
RW 0x0 RW 0x0
15 14
hctsiz5 Fields
Bit
31
dopng
Altera Corporation
Name
Transfer complete.
0x0
0x1
29 28 27 26
13 12 11 10
Name
This bit is used only for OUT transfers.Setting this
field to 1 directs the host to do PING protocol. Do not
Set this bit for IN transfers. If this bit is set for IN
transfers it disables the channel.
0x0
0x1
Description
Value
Mask
No mask
Base Address
0xFFB00000
0xFFB40000
Bit Fields
25 24 23 22
pktcnt
RW 0x0
9 8 7 6
xfersize
RW 0x0
Description
Value Description
No ping protocol
Ping protocol
Description
Register Address
0xFFB005B0
0xFFB405B0
21 20 19 18
5 4 3
cv_5v4
2016.10.28
Access Reset
RW 0x0
17 16
xfersize
RW 0x0
2 1 0
Access Reset
RW 0x0
USB 2.0 OTG Controller
