Altera cyclone V Technical Reference page 2783

cv_5v4
2016.10.28
doepdma4
DMA OUT Address.
Module Instance
usb0
usb1
Offset:
0xB94
Access:
RW
31 30
15 14
doepdma4 Fields
Bit
31:0
doepdma4
doepdmab4
DMA Buffer Address.
Module Instance
usb0
usb1
USB 2.0 OTG Controller
Send Feedback
0xFFB00000
0xFFB40000
29 28 27 26
13 12 11 10
Name
Holds the start address of the external memory for
storing or fetching endpoint data. for control
endpoints, this field stores control OUT data packets
as well as SETUP transaction data packets. When
more than three SETUP packets are received back-to-
back, the SETUP data packet in the memory is
overwritten. This register is incremented on every
AHB transaction. The application can give only a
DWORD-aligned address. When Scatter/Gather
DMA mode is not enabled, the application programs
the start address value in this field. When Scatter/
Gather DMA mode is enabled, this field indicates the
base pointer for the descriptor list.
0xFFB00000
0xFFB40000
Base Address
Bit Fields
25 24 23 22
doepdma4
RW 0x0
9 8 7 6
doepdma4
RW 0x0
Description
Base Address
doepdma4
Register Address
0xFFB00B94
0xFFB40B94
21 20 19 18
5 4 3 2
Access
Register Address
0xFFB00B9C
0xFFB40B9C
18-693
17 16
1 0
Reset
RW 0x0
Altera Corporation
