RM0432
enable bit (EIE bit in the LPUART_CR3 register), which, if set, enables an interrupt after the
current byte if any of these errors occur.
51.4.13 RS232 Hardware flow control and RS485 Driver Enable
It is possible to control the serial data flow between 2 devices by using the nCTS input and
the nRTS output. The
RS232 RTS and CTS flow control can be enabled independently by writing the RTSE and
CTSE bits respectively to 1 (in the LPUART_CR3 register).
RS232 RTS flow control
If the RTS flow control is enabled (RTSE=1), then nRTS is asserted (tied low) as long as the
LPUART receiver is ready to receive a new data. When the receive register is full, nRTS is
deasserted, indicating that the transmission is expected to stop at the end of the current
frame. Figure 526
RX
nRTS
Note: When FIFO mode is enabled, nRTS is deasserted only when RXFIFO is full.
Low-power universal asynchronous receiver transmitter (LPUART)
Figure 511 shows how to connect 2 devices in this mode:
Figure 525. Hardware flow control between 2 LPUARTs
LPUART 1
TX
TX circuit
CTS
RX
RX circuit
RTS
shows an example of communication with RTS flow control enabled.
Figure 526. RS232 RTS flow control
Start
Data 1
bit
RM0432 Rev 6
RX
RTS
TX
CTS
Stop Start
Idle
bit bit
RXNE
Data 1 read
Data 2 can now be transmitted
LPUART 2
RX circuit
TX circuit
MSv31892V2
Stop
Data 2
bit
RXNE
MSv31168V1
