CR-IR 357 Service Manual
Installation (IN)
014-204-01E
11.10.2005 FM4750
Control Sheet
Issue date
Revision number
08.15.2005
00
New release (FM4683)
11.10.2005
01
Corrections (FM4750)
CR-IR 357 Service Manual
Reason
Pages affected
All pages
All pages

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR-IR 357 and is the answer not in the manual?

Questions and answers

Related Manuals for FujiFilm CR-IR 357

Summary of Contents for FujiFilm CR-IR 357

  • Page 1 Control Sheet Issue date Revision number Reason Pages affected 08.15.2005 New release (FM4683) All pages 11.10.2005 Corrections (FM4750) All pages CR-IR 357 Service Manual Installation (IN) CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 2: Specifications Of Machine

    Dimensions and Weight Double-wheel caster (variable-direction/no-brake) x4  Fixing Means  Dimensions - Adjustable foot x4 W590 x D380 x H810 (mm) - Anti-topple retainer: 1 set  Weight 105 kg approx. IN-1 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 3 Be sure to observe the following cautions at a user’s site where long cassettes are used. - Fix the machine to the floor by the anti-topple retainer. - Install the machine where the ceiling height is 1750 mm or higher. IN-2 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 4 Shown below is the installation space where the machine is installed at a user’s site where long cassettes are used.  Top view  Top view and side view  Hole locations of the anti-topple retainer  Hole locations of the anti-topple retainer IN-3 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 5  Installation space required for the supporter only  Installation space required when the cassette rack is attached to the supporter The cassette rack mounting position and installation space are left-right symmetrical. IN-4 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 6: Installation Work Flowchart

    6. Final Placement 11. Powering OFF the CR Console/RU Securing the Machine Securing the Cable 12. Cleaning the CR Console/RU 7. CR Console Installation Procedures 13. Lead Precaution Label {FCR XG-1/CR CL Service Manual} IN-5 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 7: Preparation For Installation

    IEC60601-1-1. Everyone who connects additional equipment configures a medical system, and is therefore responsible that the system complies with the requirements of IEC60601-1-1. If in doubt consult with the your local technical service representative." IN-6 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 8 - Secure a necessary space for unloading, before unloading the machine together with the carrier pallet from the load-carrying platform of the truck. IN-7 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 9 Cut the tapes, and remove the PP bands with stoppers and the bag containing the accessories.  NOTE  Lift the corrugated fiberboard box straight up not to damage the machine with the edges of the box, for removal. IN-8 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 10 When cutting the plastic cover, cut below the bottom of the machine. Do not damage In removing the bolts, use of a 17-mm spanner is recommended to improve workability. the machine with a sharp instrument. IN-9 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 11 REFERENCE In loosening the nut of the adjustable foot, use of a 13-mm spanner is recommended to improve workability. IN-10 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 12 Be sure to raise the adjustable feet to the uppermost position. If the machine is moved with the adjustable feet lowered, they might get caught on the ground, causing the machine to topple down. IN-11 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 13 Do not remove all of the four bolts which retain the machine retainers on the front of improve workability. the machine. If removed, the machine is movable, and might drop from the carrier pallet. IN-12 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 14 IN-13 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 15 - Place the slope with the side with holes toward the carrier pallet. IN-14 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 16 IN-15 Put the PP band on the stopper. Tighten the PP band, and fix the slope to the carrier pallet. IN-15 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 17 - Do not hold in the vicinity of the cassette inserting entrance or the vicinity of the feet. operation panel. IN-16 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 18: Temporary Placement

     NOTE  Do not use the hand lifter to transfer the machine into the installation place. The machine might topple and get damaged. Secure the machine with the adjustable feet in place. IN-17 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 19: Checking The Items Supplied

    IR 355 FLOOR FIX KIT #(E) Anti-topple retainer kit For retaining the machine IR 355 STAND #(E) Supporter IR 355 CASSETTE RACK #(E) Cassette rack Supporter cassette rack Supporter cassette rack (for long cassette) IN-18 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 20: Installation Procedures

    - If the machine is to be installed in the patient environment, see "APPENDIX 1. ADDITIONAL PROTECTIVE GROUNDING." {IN: Appendix 1_ADDITIONAL PROTECTIVE GROUNDING} Connect the power cable to the machine. Remove the protective member. Place the breaker switch in the ON position. IN-19 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 21 ∞ Measure the resistance value between the E terminal of the power cable and the bottom of the machine frame, and make sure that there is continuity. Install the power cable cover. IN-20 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 22: Connecting The Interface Cable

    For the I/F cable, only the straight cable of UTP type should be used. Connect the I/F cable to the I/F cable connector of the machine. Connect the I/F cable to the switching hub. IN-21 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 23: Final Placement

    {IN: Appendix 2_Securing the Machine with the Anti-Topple Retainer}  Using the supporter When using the supporter (optional), see "Appendix 3. Assembling and Securing the Supporter." {IN: Appendix 3_Assembling and Securing the Supporter} IN-22 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 24: Securing The Cable

    1_ADDITIONAL PROTECTIVE GROUNDING} {FCR XG-1/CR CL Service Manual} CAUTION Do not tie or bundle the power cable in such a manner that it is overloaded. Plug the power cable into the outlet. IN-23 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 25 RU starts to boot up, once turn OFF the RU power and repeat Starting the Machine Maintenance Utility from the procedure 1. Turn ON the power of the CR Console. Turn ON the circuit breaker of the RU. IN-24 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 26 → The address setting window appears. → In 1 to 2 seconds after the [Confirm] button is pressed, an alarm beeps. The specified address becomes effective, and the menu selection window restores. IN-25 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 27 IN-26 Setting the FTP Server IP Address Press the [Select] button. Press the button twice, and select “FTP Server IP Address”. → The address setting window appears. IN-26 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 28 “OK”. Then press the [Confirm] button. → In 1 to 2 seconds after the [Confirm] button is pressed, an alarm beeps. The specified address becomes effective, and the menu selection window restores. IN-27 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 29  NOTES  - “OK” is displayed in the GOOD indication when “Default Gateway” is specified. - Take the troubleshooting procedures when the NO GOOD indication appears. {Troubleshooting} → The “Network Check” window appears. IN-28 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 30 {IN: Appendix 8._Corrective Procedure to be Performed after Improper RU PC- TOOL Installation.} Click on [Finish] when the installation is completed. → You are then returned to the "Set Up PC-TOOL" window. IN-29 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 31 Enter Install "RU NAME" and "RU IP ADDR".  NOTE  If the "Reader Unit IP Address" setting was changed from the RU operation panel before RU software installation, enter the changed address. IN-30 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 32 Select "LANGUAGE". If a LINAC CASSETTE is to be used at the user’s site, select “USE”. If the LINAC CASSETTE is not to be used, select “NOT USE”, and click on [SET]. IN-31 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 33 Console's registered, up to four CR Console's are switchable as master CL's. For more detail about the function that may be set on the "EDIT CL NAME" screen, see "4.14 EDIT CL NAME" of the Maintenance Utility volume. {MU:4.14_EDIT CL NAME} IN-32 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 34 Do not close the installation screen until the flash ROM write process is completed. If you inadvertently close the installation screen, return to step 7 and perform the installation procedure again. The flash ROM write process takes about 8 minutes. Click on [OK]. IN-33 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 35 OFF the RU power does not affect the RU's functionality.  NOTE  In the case of "NO GOOD" indication, return to step 1 and perform install procedures all Turn ON the power of the RU. over again. IN-34 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 36 RU's operation panel, see "1.3.3 Operation Panel Display Screen Contents" in the "Machine Description" volume. {MD:1.3.3_Operation Panel Display Screen Contents} Perform "Secondary Erasure" on the spontaneous radiation and image accumulated on the IP to be used. {Instruction Manual} IN-35 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 37  If there is uneven density difference in the same direction on two films → The machine may be the cause of such nonuniformity. {Troubleshooting}  If positions of uneven density difference are different → The X-ray tube may be the cause of such nonuniformity. IN-36 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 38 film size. The actual size on the IP should be calculated using the distance measured on the film and the reduction factor for the film. Compute the actual size on the IP according to the following equation. IN-37 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 39 Second Third Fourth Fifth Average measurement measurement measurement measurement measurement value 1.04 Enter the exposure conditions and the average radiation dose determined in step 3 in the "FCR S Value Control Table." IN-38 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 40 If the "S value for 1 mR of radiation," which was determined in step 8, is not between the upper and lower control limit values, make sensitivity correction as directed in "15.3 Sensitivity Correction" and then confirm the S value again. {MC:15.3_Sensitivity Correction} IN-39 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 41 Clean the monitor and covers of the CR Console with a dry cloth. Shut down the system of the RU. Clean the covers of the RU with a moistened cloth. Turn OFF the power of the RU. Peel the seal off the operation panel. IN-40 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 42 IN-41 13. Lead Precaution Label Apply the lead precaution label suitable for the local language. IN-41 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 43 IN-42 BLANK PAGE IN-42 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 44 IN-43 BLANK PAGE IN-43 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 45: Appendix 1. Additional Protective Grounding

    Generally, a portion of the medically-used room is the patient environment. Non-Medically Used Room Areas outside the medically-used room are considered the non-medically used room. Appx_IN-1 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 46: Appendix 2. Securing The Machine With The Anti-Topple Retainer

    Spacer (1 mm) 347N2108 Spacer (2 mm) 347N2109 317S1064 Hex head socket bolt (8x15) 304S1000820 Spring washer (SW8) 309S0220008 Plain washer (W8) 309S0110008 Hex socket head button bolt (8x20) 304S5000820 Anchor nut (Na8) 305S0080 Appx_IN-2 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 47 The front bracket has nuts welded on the inner side. The rear bracket has no nut welded on the inner side. <Reference value> Appx_IN-3 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 48 When drilling a hole, use of a vacuum cleaner is recommended. If the hole is drilled while sucking the chips by the vacuum cleaner, the depth of the hole can be easily checked. Appx_IN-4 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 49 Be sure to use the button bolt as a bolt to retain the anti-topple retainer. If a common bolt is used, the bolt head and the adjustable foot might come into contact when the machine is moved, causing deformation on the adjustable foot. Appx_IN-5 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 50 Check to make sure that there is no aperture between the two nuts of the adjustable foot. If there is an aperture between the nuts, the machine retaining bracket cannot be fixed properly. Appx_IN-6 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 51 The front bracket has nuts welded on the inner side. The rear bracket has no nut welded on the inner side. Appx_IN-7 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 52 - If the machine can move until the bracket on the rear of the machine comes against the bracket retained on the floor, the procedure 12 need not be taken. Proceed to the procedure 13. Appx_IN-8 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 53 - If the spacer of 1mm thickness cannot be inserted into an aperture between the bracket retained on the floor and the bracket mounted on the machine, the procedure 14 need not be taken. Proceed to the procedure 15. Appx_IN-9 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 54  NOTE  on the floor. When the spacer is removed, always take the procedure 13 to check the aperture. Appx_IN-10 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 55 Appx_IN-11 Put on the bolt on the front of the machine, retain the bracket, and put on the bolt cover. Appx_IN-11 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 56: Appendix 3 Assembling And Securing The Supporter

    For arm Screw (T5x12) For base For cassette rack For cassette rack (for long cassette) Screw (T6x15) For supporter body W sems screw (B4x12) For arm W sems screw (B5x8) For arm Appx_IN-12 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 57 Appx_IN-13 Assembling the Supporter Mount the connecting struts on one of the stanchions. Attach the adjustable feet to the right- and left-hand stanchions. Appx_IN-13 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 58 Appx_IN-14 Mount the struts assembled in the step 2 on the other stanchion. Screw the struts.  NOTE  Be sure to mount the struts with the two screws temporarily tightened. Appx_IN-14 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 59 Appx_IN-15 Mount the shelf. Screw down the shelf.  NOTE  Be sure to mount the shelf with the two screws loosely installed. Appx_IN-15 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 60 Appx_IN-16 Mount the brackets. Mount the shock absorbers. Appx_IN-16 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 61: Mounting The Arm

    Appx_IN-17 Attachment of the Options Screw the arm. Mounting the Arm Mount the arm.  NOTE  Be sure to mount the struts with the two screws temporarily tightened. Appx_IN-17 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 62 Attach the bracket and screw it.  NOTE  When the arm (optional) has been mounted, be sure to retain the supporter according to “Appendix 3-5 Securing the Supporter”. {IN:Appendix 3-5_Securing the Supporter} Appx_IN-18 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 63: Mounting The Base

    Appx_IN-19 Mounting the Base Mount the base to the supporter. REFERENCE The base can be placed either on the right or the left at symmetrical positions. Attach the bracket to the base. Appx_IN-19 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 64 The cassette rack can be placed either on the right or the left at symmetrical positions.  Mounting the Cassette Rack (for Use with a Long Cassette)  Mounting the Cassette Rack Appx_IN-20 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 65 Check to make sure that there is no aperture between the two nuts of the adjustable {IN:Appendix 3-5_Securing the Supporter} foot. If there is an aperture between the nuts, the machine retaining bracket cannot be fixed properly. Appx_IN-21 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 66 The front bracket (for use on the front face) and the rear bracket (for use on the rear face) of the anti-topple retainer have different shapes. The rear bracket has pins on its back surface. Appx_IN-22 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 67 When pushing the machine into the supporter or pulling the machine out of the supporter, exercise care so that your fingers and other parts of your body are not caught between the supporter and machine. Appx_IN-23 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 68 Appx_IN-24 Place the bracket (for the front face) and secure with hex head bolts. Appx_IN-24 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 69  When the supporter is to be fixed to the floor: {IN:Appendix 3-5.1_Fixing the Supporter to the Floor}  When the supporter is to be fixed to the wall: {IN:Appendix 3-5.2_Fixing the Supporter to the Wall} Appx_IN-25 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 70 Put the assembled supporter on a position where it is to be fixed. While holding the supporter not to shift, mark with a pen or the like the positions to be bored where the anchor nuts are to be embedded. <Reference value> Appx_IN-26 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 71 When drilling a hole, use of a vacuum cleaner is recommended. If the hole is drilled while sucking the chips by the vacuum cleaner, the depth of the hole can be easily checked. Appx_IN-27 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 72 Always use button bolts to fix the supporter. If a normal bolt is used, the head of the bolt comes into contact with the adjustable foot when the machine is moved, and the adjustable foot might get deformed. Appx_IN-28 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 73 Mark the positions to be screwed with a pen or the like. REFERENCE Mark two holes among five holes on each of the upper and lower struts. Appx_IN-29 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 74 {IN:Appendix 3-5.3_Securing the Machine (when the Supporter has been Fixed)} REFERENCE Make a preparatory hole of approx. 1 mm on the wall before screwing. This makes the screws easy to be tightened. Appx_IN-30 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 75 Check to make sure that there is no aperture between the two nuts of the adjustable foot. If there is an aperture between the nuts, the machine retaining bracket cannot be fixed properly. Appx_IN-31 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 76 The front bracket (for use on the front face) and the rear bracket (for use on the rear face) of the anti-topple retainer have different shapes. The rear bracket has pins on its back surface. Appx_IN-32 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 77 - When fastening the nut of the adjustable foot, exercise care not to cause an aperture between the two nuts. The bracket might not be able to be properly retained. Appx_IN-33 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 78 Appx_IN-34 Install the hex head bolts. Appx_IN-34 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 79 Apply the seals to the screw holes on the supporter. REFERENCE The number of seals to be applied depends on whether an optional part has been mounted. The locations where the seals might be applied are shown below. Appx_IN-35 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 80: Appendix 4. Setting The Master Cl

    Console's registered, up to four CR Console's are switchable as master CL's. For more detail about the function that may be set on the "EDIT CL NAME" screen, see "4.14 EDIT CL NAME" of the Maintenance Utility volume. {MU:4.14_EDIT CL NAME} Appx_IN-36 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 81 Start up the Machine Maintenance Utility of the RU. Select [Run...] from the Start menu of Windows. When the dialog opens, type ["C:\ Program Files\FujiFilm\FCR\TOOL\RuPcTool\RuPcTool.exe"] and click on the [OK] Turn ON the RU power while pressing the first and third buttons from the left on button.
  • Page 82 Register the master CL (CL2) created at procedure 5 into the master CL. and enter the "IP ADDRESS" and "CL NAME" of the master CL to be added. Close the RU PC-TOOL window. Appx_IN-38 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 83 REFERENCE The name should not necessarily be the same as the host name. Click on → Registering the network information is now completed. Click on → The "New Node" dialog box appears. Appx_IN-39 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 84 III. If several RU's are connected, select the second and subsequent host name(s) in "Equipment #2" and so on. Click on → Registering the machine information is now completed. The "Setup Configuration Item" window appears back on screen. Appx_IN-40 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 85 Turn OFF the power of the RU. Turn ON the power of the RU. Press the [Utility] button on the operation panel. → The “Utility” window appears. Press the [Select] button. → The “Select master Console” window appears. Appx_IN-41 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 86 Perform reading, and make sure that the image is transferred to the master CL. Press the [Select] button. REFERENCE The power of the RU automatically turns OFF about 1 minute after the master CL is set. Appx_IN-42 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 87: Appendix 5. Changing The Ru's Ip Address

    Reinstall the RU software as directed under "Appendix 6. Reinstalling the RU Software."  INSTRUCTION  After the RU's IP address is changed, be sure to reinstall the RU software. {IN: Appendix 6._Reinstalling the RU Software} Appx_IN-43 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 88: Appendix 6. Reinstalling The Ru Software

    From "LIST OF EXISTING RU," select an RU. Reinstalling the RU Software Reinstall the RU software. For the RU software reinstallation procedure, see "Appendix 7. Installing the RU Software." {IN: Appendix 7._Installing the RU Software} Appx_IN-44 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 89: Appendix 7. Installing The Ru Software

    Install the RU PC-TOOL as directed under "8.5 Installing the RU PC-TOOL." {IN:8.5_Installing the RU PC-TOOL} Installing the RU Software Install the RU software as directed under "8.6 Installing RU Software." {IN:8.6_Installing RU Software} Appx_IN-45 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...

  • Page 90: Appendix 8. Corrective Procedure To Be Performed After Improper Ru Pc- Tool Installation

    RU PC-TOOL. For details on the procedure, see "Appendix 8-2 Corrective Procedure 2." {IN: Appendix 8-2_Corrective Procedure 2} Click on [Finish]. Install the RU PC-TOOL as directed under "Appendix 7-2 Installing the RU PC- TOOL." {IN: Appendix 7-2_Installing the RU PC-TOOL} Appx_IN-46 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 91 Click on [UNINSTALL]. When the uninstallation process is completed, click [Finish]. Click on [NEXT]. Install the RU PC-TOOL as directed under "Appendix 7-2 Installing the RU PC- TOOL." {IN: Appendix 7-2_Installing the RU PC-TOOL} Appx_IN-47 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
  • Page 92 Appx_IN-48 BLANK PAGE Appx_IN-48 CR-IR 357 Service Manual 014-204-01E 11.10.2005 FM4750...
