Table 258. Device-mode control and status registers (continued)
Acronym
OTG_DIEPEMPMSK
OTG_DIEPCTL0
OTG_DIEPCTLx
OTG_DIEPINTx
OTG_DIEPTSIZ0
OTG_DTXFSTSx
OTG_DIEPTSIZx
OTG_DOEPCTL0
OTG_DOEPCTLx
OTG_DOEPINTx
OTG_DOEPTSIZ0
OTG_DOEPTSIZx
Offset
address
OTG device IN endpoint FIFO empty interrupt mask register
0x834
(OTG_DIEPEMPMSK) on page 1571
OTG device control IN endpoint 0 control register (OTG_DIEPCTL0) on
0x900
page 1571
0x920
0x940
OTG device endpoint-x control register (OTG_DIEPCTLx) (x = 1..5 ,
where x = Endpoint_number) on page 1573
...
0x9A0
0x908
0x928
OTG device endpoint-x interrupt register (OTG_DIEPINTx) (x = 0..5 ,
where x = Endpoint_number) on page 1579
....
0x9A8
OTG device IN endpoint 0 transfer size register (OTG_DIEPTSIZ0) on
0x910
page 1581
0x918
OTG device IN endpoint transmit FIFO status register
0x938
(OTG_DTXFSTSx) (x = 0..5 , where x = Endpoint_number) on
....
page 1584
0x9B8
0x930
0x950
OTG device IN endpoint-x transfer size register (OTG_DIEPTSIZx)
(x = 1..5 , where x= Endpoint_number) on page 1583
...
0x9B0
OTG device control OUT endpoint 0 control register
0xB00
(OTG_DOEPCTL0) on page 1575
0xB20
0xB40
OTG device endpoint-x control register (OTG_DOEPCTLx) (x = 1..5 ,
where x = Endpoint_number) on page 1577
...
0xBA0
0xB08
0xB28
OTG device endpoint-x interrupt register (OTG_DOEPINTx) (x = 0..5 ,
where x = Endpoint_number) on page 1580
...
0xBA8
OTG device OUT endpoint 0 transfer size register (OTG_DOEPTSIZ0)
0xB10
on page 1582
0xB30
0xB50
OTG device OUT endpoint-x transfer size register (OTG_DOEPTSIZx)
(x = 1..5 , where x = Endpoint_number) on page 1584
...
0xBB0
