Controller area network (bxCAN)
CAN filter mode register (CAN_FM1R)
Address offset: 0x204
Reset value: 0x0000 0000
This register can be written only when the filter initialization mode is set (FINIT=1) in the
CAN_FMR register.
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. FBM13 FBM12 FBM11 FBM10
rw
Note: Please refer to
page 1462
Bits 31:14 Reserved, must be kept at reset value.
Bits 13:0 FBMx
Note: Bits 27:14 are available in connectivity line devices only and are reserved otherwise.
CAN filter scale register (CAN_FS1R)
Address offset: 0x20C
Reset value: 0x0000 0000
This register can be written only when the filter initialization mode is set (FINIT=1) in the
CAN_FMR register.
31 30 29
Res Res Res
15 14 13
Res Res FSC13 FSC12
rw
Bits 31:14 Reserved, must be kept at reset value.
Bits 13:0 FSCx
These bits define the scale configuration of Filters 13-0.
0: Dual 16-bit scale configuration
1: Single 32-bit scale configuration
Note: Bits 27:14 are available in connectivity line devices only and are reserved otherwise.
Note: Please refer to
page 1462.
