Application Guide | iC7 Series Motion
6.
Configure the readouts in the control panel. See Understanding Readout Screens.
Configuring the Motor, Motor Control, and Motor Thermal Protection
5.3
The required configuration steps depend on the motor type selected in parameter 4.2.1.1 Motor Type.
The parameters specified in motor configuration cannot be adjusted when the motor is running.
1.
Configure basic motor data. Go to Parameter group 4 and specify the following:
Index
4.2.1.1
4.2.2.1
4.2.2.2
4.2.2.3
4.2.2.4
4.2.2.5
Note:
Changing the product label data causes a reset of the advanced motor data to default values, and the loss
of AMA results.
2.
Perform Automatic Motor Adaptation (AMA).
The advanced motor data, which are needed for optimal motor control performance and which are described in step 3, can
be entered manually or measured and calculated based on AMA. The data measurement must be conducted in standstill
with the following parameter:
Index
4.2.1.3
Note:
AMA requires an active start signal for execution. After AMA is performed, the setting of AMA Mode
automatically switches to Off, and a notification must be confirmed. A new start signal is required for starting
the motor. This is to avoid an unintended start caused by the active start signal. Consult the iC7 Series Frequency
Converters Installation Safety Guide for safety information on unintended start.
3.
Configure the advanced motor data if AMA is not performed. Setting these parameters are recommended for optimal motor
control performance.
© 2023.11
Parameter name
Motor Type
Nominal Power
Nominal Current
Nominal Speed
Nominal Frequency
Nominal Voltage
Parameter name
AMA Mode
NOTICE
Parameter setting
Induction motor or Permanent mag-
net motor
As on motor product label.
As on motor product label.
As on motor product label.
As on motor product label.
As on motor product label.
Parameter setting
Motor data
Parameter
number
407
405
400
402
403
401
Parameter
number
420
