Application Guide | iC7 Series Motion
Table 37: Selection Descriptions
Selection Name
Trip
Automatically derate
P 2.3.1.6 Inverter Thermal Overload Response
This parameter selects a response to the reaction of the drive for Inverter Thermal Overload protection. Inverter thermal overload is
detected when the drive operates for a long period at a specified output current level. Specific current levels and trip times depend on
the power unit type and rating. Following are the descriptions for the selections available for the parameter:
Table 38: Selection Descriptions
Selection Name
Trip
Automatically derate
Overvoltage Protection (Menu Index 2.3.2)
6.3.4.3
P 2.3.2.1 Overvoltage Control
Description: Enables the DC-link overvoltage controller. It is recommended to disable the overvoltage controller if brake is enabled, or
the unit is supplied with a regulated DC.
Default Value: 1 [Enabled]
Unit: -
The following are the selections for the parameter.
Selection Number
0
1
P 2.3.2.2 Overvoltage Control Kp
Description: Set the scaling of the overvoltage control proportional gain.
Default Value: 100
Unit: %
P 2.3.2.3 Overvoltage Control Ti
Description: Set the scaling of the overvoltage control integral time.
114
| © 2023.11
Selection Description
The drive issues a fault and stops modulation.
The drive derates the rectifier current (DC-link current) to mitigate the cause of rectifier thermal
overload. When the drive exits from the overload operation window, derating is stopped.
Selection Description
The drive issues a fault and stops modulation.
The drive derates the rectifier current (DC-link current) to mitigate the cause of rectifier thermal
overload. When the drive exits from the overload operation window, derating is stopped.
Parameter Type: Selection
Data Type: BOOL
Selection Name
Disabled
Enabled
Parameter Type: Range (0 — 10000)
Data Type: REAL
Parameter Number: 1802
Access Type: Read/Write
Selection Description
Disables the function.
Enables the function.
Parameter Number: 1803
Access Type: Read/Write
