Operating Guide
Voltage Measurement Option OC7V0
iC7 Series
drives.danfoss.com |

Advertisement

Table of Contents
loading

Summary of Contents for Danfoss iC7 Series

  • Page 1 Operating Guide Voltage Measurement Option OC7V0 iC7 Series drives.danfoss.com |...
  • Page 3: Table Of Contents

    Installing the Voltage Measurement Option OC7V0 Fiber Cable Requirements Terminal and Connector Specifications Installation Example Diagrams Application Examples Grid Converter Control Line Filter Energization and Transformer Magnetization Closed-loop AC Voltage Control External Grid Synchronization Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 4 Operating Guide | Voltage Measurement Option OC7V0 Specifications Technical Data Dimensions Related Standards | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 5: Introduction

    Installation guides, which cover the mechanical and electrical installation of drives, power converters, or functional extension options. Design guides, which provide technical information to understand the capabilities of the iC7 series drives or power converters for integration into motor control and monitoring systems.
  • Page 6: Safety

    ISO action symbol for referring to the instructions Safety Awareness Before starting installation, read: The safety guidelines and precautions related to installing the iC7 series Voltage Measurement Option OC7V0 in this operating guide The iC7 series System Modules Safety Guide Supplemental information and other iC7 series guides can be downloaded from https://www.danfoss.com/en/service-and-support/...
  • Page 7: Installation Safety

    Disconnect all sources and loads which are connected to the line which is to be connected to the Voltage Measurement Option. Use a calibrated measuring device to make sure that there is no voltage, before performing any work on the cables. Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 8: Overview

    Figure 1: Voltage Measurement Option OC7V0 Used in a Grid Converter Application Compatibility The iC7 series Voltage Measurement Option OC7V0 is compatible with the iC7 series system modules and the modular control unit. | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 9: Configuration

    101 is reserved for default control unit components. Table 2: Physical Option Slot and Its Software Address in Systems with Modular Control Unit Software address Slot Figure 2: Option Slot Locations in Systems with Modular Control Unit Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 10: Installation

    Do not install, remove, or replace option boards on the drive when the power is on. Doing this can cause damage to the boards. Switch off the AC drive before installing, removing, or replacing option boards on the drive. | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 11: Installing The Voltage Measurement Option Oc7V0

    The DIN rail is included in the delivery of the Voltage Measurement Option OC7V0. Mount the voltage measurement option on the DIN rail so that the terminals are in the bottom. Lower the voltage measurement option on the DIN rail from above. Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 12: Fiber Cable Requirements

    Cable Bending radius (25 mm, 1.0 in) Terminal and Connector Specifications The Voltage Measurement Option OC7V0 has 2 voltage measurement groups with 2 channels each. The channels share a common reference pin. | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 13 X52, X53 (TE CONNECTIVITY type 282843-3) Screw connectors on PCB, not pluggable X64 (TE CONNECTIVITY type 282841-2 or PHOENIX CONTACT type1888687) X84 (Firecomms Ltd type FB2M5LVR(-P)) Plug-in type for the fiber optic cable Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 14 24 V DC supply voltage from option extender only Reference for pin 1 X84 optic fiber connection no pins Maximum optic fiber length 20 m (65 ft) Figure 8: Terminal Locations on Option Extender OC7F2 | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 15: Installation Example Diagrams

    Maximum optic fiber length 20 m (65 ft) X83 optic fiber connection 1 no pins Maximum optic fiber length 20 m (65 ft) Installation Example Diagrams Figure 9: Delta Voltage Measurement Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 16: Application Examples

    The grid converter can charge the filter capacitors, magnetize the transformers, and synchronize the voltage measured from the grid side of the main circuit breaker. Thus the inrush currents and voltage transients occurring after the breaker closure are effectively avoided by using the Voltage Measurement Option OC7V0. | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 17: Closed-Loop Ac Voltage Control

    If there are transformers between the 2 circuit nodes, configure the phase difference of the converter voltage at the external grid measurement point. Figure 14: External Grid Synchronization Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 18 Voltage supply for the module 24 V wired externally from the option extender Altitude Maximum altitude 3000 m (10800 ft) Maximum altitude, up to 480 V supply networks, no corner grounding 4000 m (13100 ft) | Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332...
  • Page 19 IEC/EN 61000-6-4 Electromagnetic compatibility (EMC) – Part 6-4: Generic standards – Emission standard for industrial environments CISPR 11 Industrial, scientific and medical equipment - Radio-frequency disturbance characteristics - Limits and methods of measurement Danfoss A/S © 2024.01 AQ476649821259en-000101 / 136R0332 |...
  • Page 20 Danfoss reserves the right to alter its products without notice. This also applies to products ordered but not delivered provided that such alterations can be made without changes to form, fit or function of the product. All trademarks in this material are property of Danfoss A/S or Danfoss group companies.
