Page 1 Design Guide iC7 Series Air-cooled System Modules Active Front-End, Grid Converter, and Inverter Modules drives.danfoss.com |...
Page 3: Table Of Contents
Design Guide | iC7 Series Air-cooled System Modules Contents Introduction Purpose of this Design Guide Additional Resources Planning and Design Support Materials 1.3.1 Overview of Available Planning and Design Support Materials 1.3.2 Locating Support Information Version History Abbreviations Recommended Disposal...
Page 4 Design Guide | iC7 Series Air-cooled System Modules Mechanical Installation Considerations Storing the System Module Requirements for the Cabinet Installation Direction Cooling Requirements 5.4.1 General Cooling Requirements 5.4.2 The Quantity of Cooling Air 5.4.3 Cooling of System Modules 5.4.4 Cooling of System Modules with Integration Units 5.4.5...
Page 5 Design Guide | iC7 Series Air-cooled System Modules LCL Filter The Pre-charging Unit Control Unit Modular Control Unit Control Board Definitions of the Indicator Lights on the Control Board Control Board Connections Star Coupler Board Definitions of the Indicator Lights on the Star Coupler Board...
Page 6 Design Guide | iC7 Series Air-cooled System Modules Downloading the Software without the Mains Supply Installing MyDrive® Insight Specifications 10.1 Tightening Torques 10.2 Dimensions 10.2.1 Dimensions of the Inverter Module, IM10 10.2.2 Dimensions of the Inverter Module, IM11 10.2.3 Dimensions of the Inverter Module, IR10 10.2.4...
Page 7 Design Guide | iC7 Series Air-cooled System Modules 10.2.31 Dimensions of the Pre-charging Unit, UL 10.3 Wiring Diagrams 10.3.1 Wiring Diagram, AFE Modules 10.3.2 Wiring Diagram, AFE Modules with Parallel Power Units 10.3.3 Wiring Diagram, Inverter Modules 10.3.4 Wiring Diagram, Inverter Modules with Parallel Power Units 10.3.5...
Page 8 Design Guide | iC7 Series Air-cooled System Modules 10.7 Derating the Output Current 10.8 Power Losses 10.8.1 Power Losses of AFE Modules without Options, 380–440 V 10.8.2 Power Losses of AFE Modules without Options, 441–500 V 10.8.3 Power Losses of LCL Filter at Drive Nominal Parameters, 380–500 V 10.8.4...
Page 9: Introduction
Danfoss provides access to a consolidated product environment that supports throughout the product lifecycle. All iC7 series design guides, installation guides, safety guides, operating guides, and application guides are available for download at https://www.danfoss.com. It is also possible to order printed guides.
Page 10: Locating Support Information
Design Guide | iC7 Series Air-cooled System Modules Locating Support Information 1.3.2 Additional information is available on the company website. Go to https://www.danfoss.com. Select Products. Select Drives. Select the product series, for example Low-voltage drives or System modules. Select the product series (for example, iC7).
Page 11: Recommended Disposal
Contact your local Danfoss office for further information on environmental aspects and recycling instructions for professional recyclers. End-of-life treatment must follow international and local regulations. All products are designed and manufactured in accordance with Danfoss company guidelines on prohibited and restricted substances. A list of these substances is available at https://www.danfoss.com.
Page 12: Safety
Design Guide | iC7 Series Air-cooled System Modules Safety Safety When designing AC drives, some residual dangers cannot be avoided. One example is the discharge time, which must be observed to avoid potential death or serious injury. The discharge time is shown on the danger label on the drive.
Page 13: Target Group And Necessary Qualifications
Non-qualified electricians are not allowed to perform any electrical installation or troubleshooting activities. Only Danfoss authorized, qualified personnel are allowed to repair this equipment. Specialized training is required to perform the activities related to repair.
Page 14: Danfoss Ic7 Series
Design Guide | iC7 Series Air-cooled System Modules Danfoss iC7 Series Overview of iC7 Series The Danfoss iC7 series comprises 3 products that combine hardware and software. Table 3: The iC7 Series Product Product category Product type Application software iC7-Automation...
Page 15: Overview Of The Ic7 Series Air-Cooled System Modules
Design Guide | iC7 Series Air-cooled System Modules Overview of the iC7 Series Air-cooled System Modules System Modules The air-cooled system modules come in 2 main mechanical variants: with or without an integration unit. The system modules are a size-optimized solution, and the system modules with integration units are intended for easy installation into cabinets, and provide integrated filters.
Page 16: Checking The Delivery
If the delivery does not match your order, contact the vendor immediately. Description of the Frame Designation A frame designation is used to refer to different types of iC7 series system modules. The frame designation describes the function, mechanical variant, and size of the system module.
Page 17: Lifting The Product
Design Guide | iC7 Series Air-cooled System Modules Table 5: Weights of the System Modules (continued) Frame Short Short Standard Standard Standard Standard IP00 [kg IP00 with integratio integratio integratio integratio integratio integratio integratio (lb)] an IP54 n unit [kg...
Page 18 Design Guide | iC7 Series Air-cooled System Modules Figure 2: Lifting the Inverter Module, IM/IR10 Lift the upper part of the LCL Filter for the AFE module vertically or horizontally. 45–75° Figure 3: Lifting the Upper Part of the LCL Filter, AFE When lifting the integration unit, make sure that the maximum lifting angle is correct (60°...
Page 19: Common Dc Bus Drive System
Design Guide | iC7 Series Air-cooled System Modules 45–75° Figure 4: Lifting the Integration Unit Common DC Bus Drive System A common DC bus drive system consists of one or more front-end modules (AFE, GC, or NFE) that convert the mains AC voltage into DC voltage and current, providing power to the common DC bus.
Page 20: Description Of The Model Code
Design Guide | iC7 Series Air-cooled System Modules AFE, GC, or NFE Inverter module DC bus Brake chopper Mains DC/DC converter Energy storage Description of the Model Code The model code defines the specifications of the product included in the delivery. It is shown on the product label and the package label.
Page 21: Options
Design Guide | iC7 Series Air-cooled System Modules Options Table 7: Options for the System Modules Option group Plus code Description Extension, integration unit +AEXX None +AE01 Short integration unit without filter +AEC1 Short integration unit with CM filter +AE10...
Page 22 Design Guide | iC7 Series Air-cooled System Modules Table 7: Options for the System Modules (continued) Option group Plus code Description Control unit cable length +BKXX None +BK03 0.3 m (1 ft), fiber +BK05 0.5 m (1 ft), fiber +BK15 1.5 m (5 ft), fiber...
Page 23: Labels On The System Module
Design Guide | iC7 Series Air-cooled System Modules Labels on the System Module 4.10 To provide information about the product and the system modules, several labels are placed on the modules. Product label Includes the model code and other information about the product. See 4.12 Product Label...
Page 24: Product Label
Design Guide | iC7 Series Air-cooled System Modules Control for 5 X AR 1 1 DC 1 2 3 4 X Z 137H0741 S tar for 5 X AR 1 1 DC 1 2 3 4 X Z 137G2222 Figure 7: Labels on the Control Unit and Star Coupler Board...
Page 25 Danfoss A/S DK-6430 Nordborg www.danfoss.com MADE IN FINLAND Danfoss Ltd.22 Wycombe End,HP9 1NB, GB Figure 9: Product Label for iC7 Series Air-cooled System Modules Model code of the product Product number Power, input, and output ratings Protection rating Temperature rating for ambient air...
Page 26: Mechanical Installation Considerations
Design Guide | iC7 Series Air-cooled System Modules Mechanical Installation Considerations Storing the System Module If it is necessary to store the product before installing it, follow these instructions. Keep the equipment sealed in its packaging until installation. Make sure that the ambient conditions correspond to these: Temperature: -40...+70 °C (-40...+158°F)
Page 27: Cooling Requirements
Design Guide | iC7 Series Air-cooled System Modules Figure 10: Forbidden Installation Direction of the Inverter Module The system modules with integration units must be installed in a vertical position. Cooling Requirements General Cooling Requirements 5.4.1 The power units produce heat in operation. The fan circulates air and decreases the temperature of the drive. Make sure that there is sufficiently free space around the product.
Page 28: Cooling Of System Modules With Integration Units
Design Guide | iC7 Series Air-cooled System Modules Figure 11: Cooling of System Modules without Integration Units Cooling of System Modules with Integration Units 5.4.4 Figure 12: Inlet Airflow from the Front or from Below | Danfoss Drives Oy © 2024.03...
Page 29: Steering The Airflow
Design Guide | iC7 Series Air-cooled System Modules In the system modules with integration units, there are 2 methods to arrange inlet and outlet airflow. The inlet airflow can enter from the front or from below of the product. To allow cooling air to enter from the front, remove the air inlet covers of the integration unit.
Page 30 Design Guide | iC7 Series Air-cooled System Modules Figure 14: Air Guides of the IM10/IM11 (left) or IR10/IR11 (right) Modules in the Cabinet Air guide | Danfoss Drives Oy © 2024.03 AJ389643111587en-000101 / 172F6361A...
Page 31: Electrical Installation Considerations
Design Guide | iC7 Series Air-cooled System Modules Electrical Installation Considerations Cable Requirements Follow these requirements for the mains and motor cables used in the drive system. Select and install mains cables and motor cables according to the local safety regulations, the input voltage, and the load current of the drive.
Page 32: Grounding Principles
Design Guide | iC7 Series Air-cooled System Modules Conductor sizing is based on NEC table 310.15(B)(16) with a correction factor for an ambient temperature of 40 °C (104 °F). For parallel multicore cable installations: multicore cables listed in the recommendation list must be installed on raceways or they must not be stacked or bundled longer than 600 mm (24 in) without maintaining spacing.
Page 33 Design Guide | iC7 Series Air-cooled System Modules Table 9: Minimum Distances from Motor Cables to Other Cables Distance to other cables Length of the shielded motor cable [m (ft)] [m (ft)] 0.3 (1.0) ≤ 50 (164) 1.0 (3.3) ≤ 150 (492) Before starting, make sure that none of the components of the AC drive is live.
Page 34: Recommended Installation Of Motor Cables
Design Guide | iC7 Series Air-cooled System Modules (DC-DC) (BCU) Figure 18: Cabling Principle Grounding bar of the control cable Control cable Grounding conductor Mains cables Motor cables Strain relief The grounding clamp, 360° grounding Recommended Installation of Motor Cables If the power units are connected in parallel without output filters or only with a common-mode filter, the recommended common coupling point of motor cables is at the motor terminals.
Page 35: Cable Requirements For The Lcl Filter Fan Supply
Design Guide | iC7 Series Air-cooled System Modules Figure 19: Recommended Installation Inverter module Common coupling point at the motor terminals Figure 20: Alternative Installation Method Inverter module Cable Requirements for the LCL Filter Fan Supply NOTICE The LCL Filter fan supply is protected with internal fuses. Use external fuses if the local safety regulations or installation conditions require fuse protection.
Page 36: Connecting The Lcl Filter Fan Supply
Design Guide | iC7 Series Air-cooled System Modules Table 11: Connector X121 Item Value Connector Wago, 831-3103/037-000 Maximum wire insulation diameter 7 mm (0.3 in) Wire stripping length 14 mm (0.6 in) Conductor size maximum 10 mm /AWG8 Fine-stranded conductor...
Page 37: Installation In An Impedance-Grounded (It) System
Design Guide | iC7 Series Air-cooled System Modules 2 3 4 Figure 21: Fan Supply Connector of the LCL Filter Fan supply (X121) 465–740 V DC (+) Empty 0 V DC (-) X121 Figure 22: Diagram of the LCL Filter Fan Supply...
Page 38 Design Guide | iC7 Series Air-cooled System Modules In a non-dedicated IT system, it is recommended to leave the ground capacitors connected in each AFE to limit conducted high frequency disturbances between devices across the system. A non-dedicated IT system is defined here as a network where several separate DC links are fed from the same AC supply.
Page 39: Changing The Emc Protection Level In An It System
Design Guide | iC7 Series Air-cooled System Modules Figure 24: Diagram of the LCL Filter AC fuses LCL Filter AFE module DC fuses The grounding wire Changing the EMC Protection Level in an IT System In an IT system, to change the EMC protection level of the AC drive from C3 to C4, disconnect the LCL Filter ground capacitor.
Page 40 Design Guide | iC7 Series Air-cooled System Modules Figure 25: EMC Protection Level 3 Move the cable lug of the grounding wire with the screw onto the insulator and tighten the screw (maximum 0.5 Nm, 4.4 in-lb). | Danfoss Drives Oy © 2024.03...
Page 41: Fuses Of The Drive System
Design Guide | iC7 Series Air-cooled System Modules Figure 26: EMC Protection Level 4 After the change, write "The EMC level was changed" and the date on the "product modified" label. If the label is not yet attached, attach it on the drive near the product label.
Page 42 Design Guide | iC7 Series Air-cooled System Modules Adequate fuse protection for the drive configuration must be provided on the line side and on the DC side. The power cables and busbars must be dimensioned with sufficient thermal and mechanical strength to handle short circuits in the system. See the fuse ratings 10.5.1 List of Fuse Size...
Page 43 Design Guide | iC7 Series Air-cooled System Modules Control Control unit, AFE unit, INU Star coupler Star coupler board, AFE board, INU DC connection fuses Pre-charging power power circuit units units (1–6 PUs) (1–6 PUs) Filter fuses Mains device AC grid...
Page 44: Terminals Of The System Modules
Design Guide | iC7 Series Air-cooled System Modules Terminals of the System Modules 6.12 IM10/IM11 IR10/IR11 AR10/AR11+LCL Figure 30: Locations of the Terminals on the System Modules Auxiliary Power Connection of the Power Unit 6.13 The service 24 V DC supply terminal X80 for the power unit is used for service purposes together with the output terminal X67. When there is a 24 V DC power, it is possible to update the firmware, do commissioning checks, or check node communication.
Page 45: Auxbus Communication
Design Guide | iC7 Series Air-cooled System Modules – – Figure 31: Auxiliary Connections of the Power Unit AuxBus terminal Service 24 V DC supply terminal Control terminal 24 V DC output terminal AuxBus Communication 6.14 Usage of AuxBus 6.14.1 AuxBus enables communication for the filters.
Page 46: Auxbus Cable Requirements
Figure 33: AuxBus Topology for AFE Modules and LCL Filters AuxBus Cable Requirements 6.14.2 It is recommended to use the AuxBus cables that are provided by Danfoss. AuxBus is delivered with 3 m (10 ft) of cable. If other cables are used, see the table Table | Danfoss Drives Oy ©...
Page 47: Auxbus Grounding Principles
Design Guide | iC7 Series Air-cooled System Modules NOTICE RISK OF ELECTRICAL INTERFERENCE AuxBus consists of point-to-point connection, but the signals are connected in series. Cables that are longer than 10 m (33 ft) can create interference and communication problems.
Page 48: Auxbus Terminals Of The Lcl Filter And The Integration Unit
Design Guide | iC7 Series Air-cooled System Modules AuxBus Terminals of the LCL Filter and the Integration Unit 6.14.4 Figure 35: AuxBus Terminals of the LCL Filter AuxBus in (X86) | Danfoss Drives Oy © 2024.03 AJ389643111587en-000101 / 172F6361A...
Page 49 Design Guide | iC7 Series Air-cooled System Modules Figure 36: AuxBus Terminals of the Integration Unit AuxBus out (X85) AuxBus in (X86) Danfoss Drives Oy © 2024.03 AJ389643111587en-000101 / 172F6361A |...
Page 50: Options And Accessories For The Air-Cooled System Modules
Design Guide | iC7 Series Air-cooled System Modules Options and Accessories for the Air-cooled System Modules dU/dt Filter With the dU/dt Filter, the nominal switching frequency is 3 kHz DPWM. The maximum switching frequency is 6 kHz DPWM. The dU/dt Filter can be used without derating up to 70 Hz. For output frequencies higher than 70 Hz, current must be derated according to the curve presented in the illustration below.
Page 51: Lcl Filter
Design Guide | iC7 Series Air-cooled System Modules In an IT system, filter losses in a single phase ground fault depend on the setup. All capacitances to ground should be minimized to minimize the fault current. The fault current increases the losses, and continuous operation during the ground fault cannot be guaranteed, especially if the filter is already in the limits without the fault.
Page 52 Design Guide | iC7 Series Air-cooled System Modules Table 14: Selection of the Correct Pre-charging Unit System modules Pre-charging unit IM10 + IM10 / IR10 + IR10 Pre-charging unit 10 (IEC or UL) IM11 + IM11 / IR11 + IR11...
Page 53: Control Unit
Design Guide | iC7 Series Air-cooled System Modules Control Unit Modular Control Unit The maximum input power of the internal 24 V DC power supply is 60 W. NOTICE EXTERNAL 24 V DC POWER SUPPLY OPTIONAL The power units of the air-cooled system modules provide a 24 V DC power supply for the control unit. But it is also possible to provide an external 24 V DC +15%/-10% power supply for the control unit.
Page 54: Control Board
Design Guide | iC7 Series Air-cooled System Modules Star coupler board Functional extensions, for example: I/O and Relay Option OC7C1 ¢ Encoder/Resolver Option OC7M0 ¢ Temperature measurement option ¢ Voltage measurement option ¢ See more information on the option boards in the relevant installation guides and operating guides.
Page 55: Definitions Of The Indicator Lights On The Control Board
Design Guide | iC7 Series Air-cooled System Modules Status indicators (FAULT, WARN, READY) Fieldbus indicators (ST, X1, X2) and Ethernet port indicators (X0) Control panel connector (X9) Fiber optic link to power unit (X80) 24 V DC supply (X62) microSD card...
Page 56 Design Guide | iC7 Series Air-cooled System Modules Table 19: Control Board Connections (continued) Terminal Function Connector type Control panel terminal iX Industrial RTC battery RTC battery BR1632 (battery type) Figure 41: Control Board Terminal Block and Terminal Numbering Table 20: STO Terminal Signals (X33) for the Inverter Module...
Page 57: Star Coupler Board
Design Guide | iC7 Series Air-cooled System Modules Table 21: 24 V DC Supply Signals (X62) Terminal Function Description +24 V input Internal +24 V DC, 60 W control supply Power supply ground +24 V external input External +24 V DC control supply, maximum 10 A.
Page 58 Design Guide | iC7 Series Air-cooled System Modules Figure 42: The Star Coupler Board with 16 Ports Board configuration status indicator +24 V power status indicator Power unit connection status indicators Fiber connection to the power unit (X301–X316) +24 V power supply (X65)
Page 59: Definitions Of The Indicator Lights On The Star Coupler Board
Design Guide | iC7 Series Air-cooled System Modules Figure 44: Example Control Connection with a Star Coupler Board: 3 Power Units in Parallel Control board Star coupler board Maximum 3 power units Definitions of the Indicator Lights on the Star Coupler Board...
Page 60: Star Coupler Board Connections
Design Guide | iC7 Series Air-cooled System Modules Star Coupler Board Connections Table 23: Star Coupler Board Connections Terminal Function Connector type Ethernet port RJ45 24 V DC supply 2 x spring force connector 2.5 mm Fiber optic link to control board LC-duplex X301–X316...
Page 61 Design Guide | iC7 Series Air-cooled System Modules Table 25: I/O and Relay Option Signals (continued) Terminal Function Connector type X102 Relay 2 1 x 3 spring force connector 0.25–2.5 mm X103 Relay 3 1 x 2 spring force connector 0.25–2.5 mm...
Page 62 Design Guide | iC7 Series Air-cooled System Modules Table 26: I/O Terminal Signals (X13) (continued) Terminal Function Description AI 1 Configurable analog input. Voltage mode: AI 2 • 0 ± 10 V • single-ended • R ~ 10 kΩ • accuracy ± 0.5% of full scale Current mode: •...
Page 63: I/O And Relay Option Interface
Design Guide | iC7 Series Air-cooled System Modules Table 29: Relay 2 Signals (X102) Terminal Function Description Configurable relay output. Switching capacity: • 24 V DC/8 A • 250 V AC/8 A • 125 V DC/0.4 A Minimum switching load: 5 V/10 mA...
Page 64: Analog Outputs
Design Guide | iC7 Series Air-cooled System Modules Analog Outputs 8.9.2 The I/O and Relay Option has 1 analog output that can be configured with the software to voltage output or current output. The table shows the specification for the analog output.
Page 65: Digital Outputs
Design Guide | iC7 Series Air-cooled System Modules Table 33: Digital Inputs Logic Levels and Other Requirements Parameter Value Recommended Operation Voltage 0...24 V +20%/-10% Overvoltage Limit 33 V Logic Level 0 = V ≤ 5 V 1 = V ≥...
Page 66: Analog Reference Voltage Output
Design Guide | iC7 Series Air-cooled System Modules Table 35: Relay Output Values (continued) Parameter Value Operate Time Max. 9 ms Release Time Max. 5 ms DC Breaking Capacity Figure [VDC] Figure 47: Maximum DC Load Breaking Capacity DC voltage...
Page 67: Thermistor Input
Design Guide | iC7 Series Air-cooled System Modules Table 37: 24 V DC Voltage Output (continued) Parameter Value Short Circuit Current 250 mA Electrical fast transient (EFT) 2 kV Thermistor Input 8.9.8 The I/O and Relay Option contains 1 thermistor input. Thermistor input has basic isolation for system voltages ≤ 600 V and reinforced isolation for system voltages ≤...
Page 68: Attaching The Control Unit Mounting Plates
Design Guide | iC7 Series Air-cooled System Modules Figure 48: Assembling the Mounting Plate Attaching the Control Unit Mounting Plates 8.11 Use these instructions to attach 2 or several mounting plates to each other, and to install mounting plates to the cabinet. All the parts can be found in the accessories bag.
Page 69: Installing The Control Unit
Design Guide | iC7 Series Air-cooled System Modules Attach the mounting plates onto the cabinet with screws by the 4 mounting holes in the corners of the mounting plates. The screws are not included in the delivery. Use an M4/M5 screw.
Page 70: Connecting The Fieldbus Cable And The Fiber Cables
Design Guide | iC7 Series Air-cooled System Modules Figure 50: Installing a Board to the Modular Control Unit Mounting Plate Option connector Option terminal cover Option board Fixing point at the top Fixing point at the middle Fixing point at the bottom Use the screw to attach the board to the fixing point at the top.
Page 71: Installing The Control Cables Into The Control Terminals
Design Guide | iC7 Series Air-cooled System Modules Figure 51: Connecting the Fieldbus Cable and the Fiber Cables PLC (not included in the delivery) Fieldbus cable Control board Star coupler board Fiber cables Power units Installing the Control Cables into the Control Terminals 8.15...
Page 72: Connecting The Control Panel
Design Guide | iC7 Series Air-cooled System Modules The lower part of the cable clamp fixes the cable to the plate and provides strain relief. The upper part provides ~360° grounding for the cable shield. Figure 53: Stripping the Cable and Using the Grounding Plates Stripping length, 10 mm (0.4 in)
Page 73: Maintenance
Preventive Maintenance Recommendations Generally, all technical equipment, including Danfoss AC drives need a minimum level of preventive maintenance. To ensure trouble-free operation and long life of the drive, regular maintenance is recommended. It is also recommended as a good service practice to record a maintenance log with counter values, date, and time describing the maintenance and service actions.
Page 74 Design Guide | iC7 Series Air-cooled System Modules Table 39: Maintenance Schedule for Air-cooled Drives (continued) Component Inspection Service Preventive maintenance actions interval schedule Corrosive environ- 1 year – Conductive dust and aggressive gases, such as sulphide, chloride, and salt mist, can ments damage the electrical and mechanical components.
Page 75: Using The Product Modified Label
Design Guide | iC7 Series Air-cooled System Modules Table 39: Maintenance Schedule for Air-cooled Drives (continued) Component Inspection Service Preventive maintenance actions interval schedule Insulator gaskets 1 year 10–15 Inspect the insulators for signs of degradation due to high temperature and ag- years ing.
Page 76: Removing The Fan Assembly
Design Guide | iC7 Series Air-cooled System Modules CAUTION RISK OF FIRE OR EXPLOSION Do not recharge, disassemble, or dispose of in fire. Locate the RTC battery holder on the control board of the control unit. Pull from the handle next to the text RTC BAT.
Page 77 Design Guide | iC7 Series Air-cooled System Modules Figure 58: Releasing and Opening the Fan Cover Disconnect the fan supply cables from the fan power supply. X610 X611 X612 X613 Figure 59: Fan Supply Terminals X610 Supply to main cooling fan...
Page 78: Downloading The Software Without The Mains Supply
Design Guide | iC7 Series Air-cooled System Modules Figure 60: Removing the Fan Assembly Downloading the Software without the Mains Supply Use these instructions to update the drive with new software without mains. Before downloading the software, read all safety precautions in this guide and other guides available for this product.
Page 79: Specifications
Design Guide | iC7 Series Air-cooled System Modules Specifications Tightening Torques 10.1 Table 40: Tightening Torques Bolt Tightening torque [Nm (in-lb)] Maximum inward thread length [mm (in)] (177) (0.39) (354) (0.87) (620) (0.87) Grounding bolt (M8) 13.5 – (119) Dimensions 10.2...
Page 80: Dimensions Of The Inverter Module, Im11
Design Guide | iC7 Series Air-cooled System Modules Front Back The front fixing beam can be rotated so that the screws can be attached from the front or from the top. Dimensions of the Inverter Module, IM11 10.2.2 Ø12 (18.4) (3.5)
Page 81: Dimensions Of The Inverter Module, Ir10
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Inverter Module, IR10 10.2.3 (7.72) (21.73) (6.73) (1.97) (1.10) (6.77) (19.68) (3.35) (10.59) 2 x M8 Ø13 (0.51) 12 x M10 37 (1.46) 37 (1.46) 115.5 (4.54) 70.5 (1.0) 160.5 (6.31)
Page 82: Dimensions Of The Inverter Module, Ir10 With Short Integration Unit
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Inverter Module, IR10 with Short Integration Unit 10.2.4 (7.72) (21.77) (1.97) (1.10) 2 x M8 (19.68) (6.77) (3.35) (10.59) Ø13 (0.51) 12 x M10 37 (1.46) 37 (1.46) (15.94) (9.25)
Page 83: Dimensions Of The Inverter Module, Ir11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Inverter Module, IR11 10.2.5 (21.73) (8.31) (3.54) (1.10) (19.68) (6.77) (3.35) (10.59) 2 x M8 Ø13 (0.51) 12 x M10 37 (1.46) 37 (1.46) 115.5 (4.54) 70.5 (1.0) 160.5 (6.31) (9.25)
Page 84: Dimensions Of The Inverter Module, Ir11 With Short Integration Unit
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Inverter Module, IR11 with Short Integration Unit 10.2.6 (21.77) (8.31) (6.77) (3.54) (1.10) (19.68) (3.35) (10.59) 2 x M8 Ø13 (0.51) 12 x M10 37 (1.46) 37 (1.46) (15.94) (9.25)
Page 85: Dimensions Of The Afe Module, Ar10
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the AFE Module, AR10 10.2.7 (7.71) (6.73) (21.73) (6.77) (3.35) (10.59) (1.96) (1.10) (19.68) 2 x M8 Ø13 (0.51) 115.5 (4.54) (9.25) 25.5 (1.0) 160.5 (6.31) 48 (1.88) (7.20) 2 x Ø9 205.5...
Page 86: Dimensions Of The Afe Module With The Short Integration Unit, Ar10
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the AFE Module with the Short Integration Unit, AR10 10.2.8 (7.72) (21.77) (6.73) (1.97) (1.10) (21.65) (6.77) (3.35) (10.6) (0.51) (9.25) 2 x (15 x 17) (0.07 x (0.59 x 0.66)) 4 x 45 = 180 27.5...
Page 87: Dimensions Of The Afe Module, Ar11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the AFE Module, AR11 10.2.9 (21.73) (8.31) (3.54) (1.10) (6.77) (19.68) 2 x M8 (3.35) (10.59) Ø13 (0.51) 115.5 (4.54) (9.25) 25.5 (1.0) 160.5 (6.31) 48 (1.88) 183 (7.20) 205.5 (8.09) 70.5 (2.77)
Page 88: Dimensions Of The Afe Module With The Short Integration Unit, Ar11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the AFE Module with the Short Integration Unit, AR11 10.2.10 (7.72) (21.77) (1.97) (1.10) (6.77) (3.35) (10.6) (19.68) Ø13 (0.51) (9.25) 2 x (15 x 17) (0.07 x (0.59 x 0.66)) 4 x 45 = 180 27.5...
Page 89: Dimensions Of The Lcl Filter And The Afe Module Ar10
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the LCL Filter and the AFE Module AR10 10.2.11 (18.58) (21.85) 90 (3.54) Ø13 (1.06) (1.97) (7.36) (0.51) (6.77) (19.68) 5 x M8 6 x M12 46 (1.81) 92 (3.62) 46 (1.81)
Page 90: Dimensions Of The Lcl Filter And The Afe Module With The Short Integration Unit Ar10
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the LCL Filter and the AFE Module with the Short Integration Unit AR10 10.2.12 (18.58) (21.85) 90 (3.54) Ø13 (1.06) (7.36) (1.97) (19.68) (0.51) 5 x M8 (6.77) 6 x M12 46 (1.81)
Page 91: Dimensions Of The Lcl Filter And The Afe Module With The Standard Integration Unit Ar11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the LCL Filter and the AFE Module with the Standard Integration Unit AR11 10.2.13 (18.58) (21.85) 90 (3.54) Ø13 (1.06) (5.78) (3.54) (0.51) (19.68) (6.77) 5 x M8 6 x M12 46 (1.81)
Page 92: Dimensions Of The Lcl Filter And The Afe Module With The Short Integration Unit Ar11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the LCL Filter and the AFE Module with the Short Integration Unit AR11 10.2.14 (18.58) (21.85) 90 (3.54) Ø13 (1.06) (5.78) (3.54) (19.68) (0.51) 5 x M8 (6.77) 6 x M12 46 (1.81)
Page 93: Dimensions Of The Lcl Filter, Size 10 And 11
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the LCL Filter, Size 10 and 11 10.2.15 2 x Ø9 (0.35) 5 x Ø5.5 (0.22) (11.81) Ø13 Ø13 Ø25 (10.20) (0.51) (0.51) (0.98) (2.84) 3 x M8 (36.26) 1576 (62.05)
Page 94: Dimensions Of The Short Integration Unit For Afe Module
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Short Integration Unit for AFE Module 10.2.16 (21.69) (5.51) (0.35) 2 x (9 x 37) (6.38) (0.55) (9.25) (1.45) (21.14) 5 x Ø6 90˚ Ø9 4 X 45= 180 (7.09)
Page 95: Dimensions Of The Standard Integration Unit For Afe Module
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Standard Integration Unit for AFE Module 10.2.17 (21.77) (5.51) (0.35) 2 x (9 x 13) (27.83) 581.5 (23.38) (22.89) (1.77) (9.25) 115.5 (4.54) 70.5 (1.0) 160.5 (6.31) 48 (1.88) 183 (7.20)
Page 96: Dimensions Of The Short Integration Unit For Inverter Module
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Short Integration Unit for Inverter Module 10.2.18 (21.69) (5.51) (0.35) 2 x (9 x 13) 12 x M10 (19.96) 37 (1.46) 37 (1.46) (15.51) (15.04) (6.88) (1.69) (1.93) (9.25) (15.94)
Page 97: Dimensions Of The Standard Integration Unit For Inverter Module
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Standard Integration Unit for Inverter Module 10.2.19 (21.85) (5.51) (0.35) 2 x (9 x 13) 12 x M10 37 (1.46) 37 (1.46) (23.38) (1.93) (1.85) (16.06) (9.25) (1.93) (0.07) 115.5 (4.54)
Page 98 Design Guide | iC7 Series Air-cooled System Modules (21.77) (5.51) (0.35) 2 x (9 x 13) 12 x M10 37 (1.46) 37 (1.46) (23.38) (1.93) (1.85) (9.25) (16.06) (1.93) 115.5 (4.54) 75.5 (2.97) 160.5 (6.31) A - A 48 (1.88) 183 (7.20)
Page 99: Dimensions For Dc Fuses, Im10
Design Guide | iC7 Series Air-cooled System Modules Dimensions for DC Fuses, IM10 10.2.20 (4.80) (6.26) (4.76) (4.80) (3.35) (10.59) (1.81) (1.81) Figure 81: Dimensions for DC Fuses in mm (in), IM10 Dimensions without DC fuses Dimensions with DC fuses Danfoss Drives Oy ©...
Page 100: Dimensions For Dc Fuses, Im11
Design Guide | iC7 Series Air-cooled System Modules Dimensions for DC Fuses, IM11 10.2.21 (6.34) (4.76) (6.26) (6.34) (3.35) (10.59) (1.81) (1.81) Figure 82: Dimensions for DC Fuses in mm (in), IM11 Dimensions without DC fuses Dimensions with DC fuses | Danfoss Drives Oy ©...
Page 101: Dimensions For Dc Fuses, Ir10
Design Guide | iC7 Series Air-cooled System Modules Dimensions for DC Fuses, IR10 10.2.22 (32.44) (3.35) (10.59) (6.77) (34.25) Figure 83: Dimensions for DC Fuses in mm (in), IR10 Dimensions with DC fuses Dimensions without DC fuses Danfoss Drives Oy © 2024.03...
Page 102: Dimensions For Dc Fuses, Ir11
Design Guide | iC7 Series Air-cooled System Modules Dimensions for DC Fuses, IR11 10.2.23 (32.44) (3.35) (10.59) (6.77) (34.25) Figure 84: Dimensions for DC Fuses in mm (in), IR11 Dimensions with DC fuses Dimensions without DC fuses | Danfoss Drives Oy © 2024.03...
Page 103: Dimensions Of The Control Unit
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Control Unit 10.2.24 83.4 79.3 (3.28) (3.12) (9.21) (11.69) Figure 85: Dimensions of the Control Unit in mm (in), Example Configuration Danfoss Drives Oy © 2024.03 AJ389643111587en-000101 / 172F6361A |...
Page 104: Dimensions Of The Control Unit Mounting Plate
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Control Unit Mounting Plate 10.2.25 39.5 (1.55) 16.75 27.5 (0.66) (1.08) Ø5 (0.2) (0.79) (0.14) 212.25 (8.36) (9.21) Figure 86: Dimensions of the Modular Control Unit Mounting Plate in mm (in), 2 Places | Danfoss Drives Oy ©...
Page 105: Dimensions Of The Option Connector
Design Guide | iC7 Series Air-cooled System Modules 1.25 (0.05) 79.5 (3.13) 67.5 16.5 (2.66) (0.65) (0.24) Ø5 (0.2) (0.43) (0.79) (0.79) (0.79) (0.14) 212.5 (9.21) (8.37) (2.48) (0.87) Ø5 (0.2) (2.48) 41.5 (1.63) 75.5 (0.24) 32.5 (0.43) (2.97) (1.28) 67.5...
Page 106: Dimensions Of The Control Board
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Control Board 10.2.27 19.8 (0.78) (0.38) (2.72) Ø4.8 (0.18) (0.31) (0.19) (7.44) (7.72) Ø4 (0.16) (0.04) Figure 89: Dimensions of the Control Board in mm (in) | Danfoss Drives Oy © 2024.03...
Page 107: Dimensions Of The I/O And Relay Option
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the I/O and Relay Option 10.2.28 19.8 (0.78) 69.3 (2.73) (0.38) Ø4.8 (0.31) (0.18) (0.19) (7.44) (7.72) Ø4 (0.16) (0.04) Figure 90: Dimensions of the I/O and Relay Option in mm (in) Danfoss Drives Oy ©...
Page 108: Dimensions Of An Option Board
Design Guide | iC7 Series Air-cooled System Modules Dimensions of an Option Board 10.2.29 20.15 (0.79) (0.38) Ø4.8 (0.19) (0.18) 126.4 133.5 (4.98) 150.3 (5.25) (5.92) Ø4 (0.04) (0.16) 61.8 (2.43) Figure 91: Dimensions of an Option Board in mm (in) | Danfoss Drives Oy ©...
Page 109: Dimensions Of The Pre-Charging Unit, Iec
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Pre-charging Unit, IEC 10.2.30 (11.5) (9.41) (9.45) Ø6 (1.18) (2.36) (0.24) (2.36) (0.59) (4.64) (9.45) (10.35) (0.71) (9.05) Figure 92: Dimensions of the Pre-charging Unit in mm (in), IEC Danfoss Drives Oy ©...
Page 110: Dimensions Of The Pre-Charging Unit, Ul
Design Guide | iC7 Series Air-cooled System Modules Dimensions of the Pre-charging Unit, UL 10.2.31 (11.5) (9.41) (9.45) Ø6 (1.18) (2.36) (2.36) (0.24) (0.59) (4.41) (10.35) (9.45) (4.53) (6.14) Figure 93: Dimensions of the Pre-charging Unit in mm (in), UL Wiring Diagrams 10.3...
Page 111: Wiring Diagram, Afe Modules With Parallel Power Units
Design Guide | iC7 Series Air-cooled System Modules AC fuses LCL Filter AFE module DC fuses Wiring Diagram, AFE Modules with Parallel Power Units 10.3.2 DC+ DC- DC+ DC- Figure 95: Wiring Diagram, AFE Modules with Parallel Power Units Danfoss Drives Oy © 2024.03...
Page 112: Wiring Diagram, Inverter Modules
Design Guide | iC7 Series Air-cooled System Modules Common AC bus AC fuses LCL Filters AFE modules DC fuses Common DC bus Wiring Diagram, Inverter Modules 10.3.3 U/T1 V/T2 W/T3 Figure 96: Wiring Diagram, Inverter and dU/dt Filter DC fuses...
Page 113 Design Guide | iC7 Series Air-cooled System Modules DC fuses Inverter modules dU/dt Filters Common-mode Filters Motor Danfoss Drives Oy © 2024.03 AJ389643111587en-000101 / 172F6361A |...
Page 114: Pre-Charging Wiring Diagram, Afe Modules
Design Guide | iC7 Series Air-cooled System Modules Pre-charging Wiring Diagram, AFE Modules 10.3.5 -QB1 -QA3 -FC1 -QB6 -RA1 -QA6 -TB6 -CA6 -CA2 -RA2 -XD6 -RA6.1 -RA6.2 -XD6 -TB3 -FC2 Figure 98: Pre-charging Wiring Diagram, AFE Modules Double-insulated cable Pre-charging circuit Double-insulated cable | Danfoss Drives Oy ©...
Page 115: Pre-Charging Control Wiring Diagrams
Design Guide | iC7 Series Air-cooled System Modules Pre-charging Control Wiring Diagrams 10.3.6 STOP START -SF11 -SF11 -SF12 ENABLE -SF12 MANUAL AUTO DGND DGND +10V Figure 99: Pre-charging Control Wiring Diagram AFE remote control start/stop Mains 0-enable Pre-charging man-auto Main input device status...
Page 116: The Pre-Charging Function
Design Guide | iC7 Series Air-cooled System Modules 115... 230 VAC -SF11 -QA6 -QA3 Figure 100: Pre-charging Control Wiring Diagram Short-circuit protected Pre-charging contactor control Main input device control Basic I/O of the control unit of the AFE module The Pre-charging Function 10.3.7...
Page 117: Wiring Diagrams Of The +24 V Supply For The Control Unit
Design Guide | iC7 Series Air-cooled System Modules Enable pre-charging and set it to MANUAL mode. Pre-charging starts by activating Digital Input 1. The AFE or grid converter module starts and the pre-charging contactor closes. When charging is done, the main input device closes and the pre-charging contactor opens.
Page 118: Cable Sizes
Design Guide | iC7 Series Air-cooled System Modules +24V +24V input +24V input +24V input +24V ext input +24V ext input +24V ext input +24V +24V output +24V output +24V output Normal external supply Reference design, daisy-chained +24 V power...
Page 119: Mains Cable Sizes For Afe Modules, 380-500
Design Guide | iC7 Series Air-cooled System Modules Mains Cable Sizes for AFE Modules, 380–500 V 10.4.2 Table 41: Mains Cable Size Recommendations for AFE Modules, 380–500 V Frame Model code Mains cable Cu [mm Mains cable Al [mm iC7-60SA3A05-317AE00...
Page 120: Motor Cable Size Recommendations For Inverter Modules With Integration Units, 380-500 V
Design Guide | iC7 Series Air-cooled System Modules Table 42: Motor Cable Size Recommendations for Inverter Modules, 380–500 V (continued) Model code Frame Motor cable Cu Motor cable Al Maximum Number of Maximum terminal grounding number of cable size terminals...
Page 121: Mains Cable Sizes For Afe Modules, Ul 480 V
Design Guide | iC7 Series Air-cooled System Modules Table 43: Motor Cable Size Recommendations for Inverter Modules with Integration Units, 380–500 V (continued) Model code Frame Motor cable Cu Motor cable Al Maximum Number of Maximum terminal grounding number of...
Page 122: Motor Cable Sizes Recommendation For Inverter Modules, Ul
Design Guide | iC7 Series Air-cooled System Modules Motor Cable Sizes Recommendation for Inverter Modules, UL 480 V 10.4.6 Table 45: Motor Cable Sizes Recommendation for Inverter Modules, UL 480 V Model code Frame Motor cable Cu Motor cable Terminal...
Page 123: Fuses
Design Guide | iC7 Series Air-cooled System Modules Table 46: Motor Cable Size Recommendations for Inverter Modules with Integration Units, UL 480 V (continued) Model code Frame Motor cable Cu Motor cable Terminal Number of Maximum termination, maximum grounding number of...
Page 124: Dc Fuses For Afe, 465-740 V Dc
Design Guide | iC7 Series Air-cooled System Modules Table 47: AC Fuses for AFE, 380–500 V AC (continued) Frame Rated Number Fuse Mersen part Fuse U Fuse I Minimu Model code current of fuses size number cp,mr iC7-60SA3x05-580AE00 AM11/ PC33UD69V550TF...
Page 125: Dc Fuses For Inverter Modules, 465-740 V Dc
Design Guide | iC7 Series Air-cooled System Modules Table 48: DC Fuses for AFE, 465–740 V DC (continued) Frame Rated Number Fuse size Mersen part number Fuse U Fuse I Model code current of fuses iC7-60SA3x05-580AE00 AM11/AR11 PC73UD90V13CTF 1250 iC7-60SA3x05-650AE00...
Page 126: Current Ratings
Design Guide | iC7 Series Air-cooled System Modules Table 49: DC Fuses for Inverter Modules, 465–740 V DC (continued) Model code Frame Rated Number Fuse size Mersen part number Fuse U Fuse I current of fuses iC7-60SAIN05-1000E00 2 x IM10/2 x...
Page 127: Current Ratings For Regenerative Afe Module, 400 V Ac (465-650 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Table 50: Abbreviations Used in the Rating Tables Abbreviation Description Nominal current. If the process does not require any overloadability or the process does not include any load variation or margin for overloadability, the dimensioning can be done according to this current.
Page 128: Current Ratings For Regenerative Afe Module, Ul 480 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Table 51: Current Ratings for Regenerative AFE Module, 400 V AC (465–650 V DC) (continued) Model code Frame AC ratings DC ratings [kVA] [kW] [kW] N-DC iC7-60SA3A05-2800 1940 2859 2800 2231 3268...
Page 129: Current Ratings For Regenerative Afe Module, 500 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Table 52: Current Ratings for Regenerative AFE Module, UL 480 V AC (650–740 V DC) (continued) Model code Frame AC ratings DC ratings [kVA] [kW] [kW] N-DC iC7-60SA3A05-3650 2736 3359 3290 2726...
Page 130: Current Ratings For Low-Harmonic Afe Module, 400 V Ac (465-650 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Table 53: Current Ratings for Regenerative AFE Module, 500 V AC (650–740 V DC) (continued) Model code Frame AC ratings DC ratings [kVA] [kW] [kW] N-DC iC7-60SA3A05-4500 3473 4094 4010 3152 4681...
Page 131: Current Ratings For Low-Harmonic Afe Module, Ul 480 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Current Ratings for Low-harmonic AFE Module, UL 480 V AC (650–740 V DC) 10.6.6 Table 55: Current Ratings for Low-harmonic AFE Module, UL 480 V AC (650–740 V DC) Model code Frame...
Page 132: Current Ratings For Inverter Module, 400 V Ac (465-650 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Table 56: Current Ratings for Low-harmonic AFE Module, 500 V AC (650–740 V DC) (continued) Model code Frame AC ratings DC ratings [kVA] [kW] [kW] N-DC iC7-60SA3H05-580A AM11/ AR11 iC7-60SA3H05-650A iC7-60SA3H05-730A iC7-60SA3H05-816A...
Page 133 Design Guide | iC7 Series Air-cooled System Modules Table 57: Current Ratings for Inverter Module, 400 V AC (465–650 V DC) (continued) Model code Frame AC current Typical motor power, 400 V AC current [kW] [kW] peak N-DC iC7-60SAIN05-658A IM11/...
Page 134: Current Ratings For Inverter Module, Ul 460 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Current Ratings for Inverter Module, UL 460 V AC (650–740 V DC) 10.6.9 Table 58: Current Ratings for Inverter Module, UL 460 V AC (650–740 V DC) Model code Frame AC current...
Page 135: Current Ratings For Inverter Module, 500 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Current Ratings for Inverter Module, 500 V AC (650–740 V DC) 10.6.10 Table 59: Current Ratings for Inverter Module, 500 V AC (650–740 V DC) Model code Frame AC current Typical motor power,...
Page 136: Current Ratings For Grid Converter Module, 400 V Ac (465-650 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Current Ratings for Grid Converter Module, 400 V AC (465–650 V DC) 10.6.11 Table 60: Current Ratings for Grid Converter Module, 400 V AC (465–650 V DC) Model code Frame AC ratings...
Page 137: Current Ratings For Grid Converter Module, 500 V Ac (650-740 V Dc)
Design Guide | iC7 Series Air-cooled System Modules Current Ratings for Grid Converter Module, 500 V AC (650–740 V DC) 10.6.12 Table 61: Current Ratings for Grid Converter Module, 500 V AC (650–740 V DC) Model code Frame AC ratings...
Page 138: Power Losses
Design Guide | iC7 Series Air-cooled System Modules For INU modules, derating is required when the switching frequency is higher than 3 kHz. The default switching frequency for AFE/ GC modules is 4 kHz. [°C] Figure 103: Output Current Derating vs. Ambient Temperature...
Page 139: Power Losses Of Afe Modules Without Options, 441-500 V
Design Guide | iC7 Series Air-cooled System Modules 380–440 V AC (465–740 V DC) Losses calculated with 400 V AC and 594 V DC No input filters Switching frequency 4 kHz NSPWM modulator Table 62: Power Losses of AFE Modules without Options, 380–440 V...
Page 140: Power Losses Of Lcl Filter At Drive Nominal Parameters, 380-500 V
Design Guide | iC7 Series Air-cooled System Modules Table 63: Power Losses of AFE Modules without Options, 441–500 V Frame Rated current 4 kHz Model code Total power losses [kW] Main cooling channel power losses [kW] iC7-60SA3x05-317A AM10 iC7-60SA3x05-400A iC7-60SA3x05-514A...
Page 141: Power Losses Of Inverter Modules With Du/Dt Filter, 150 M (492 Ft) Motor Cables, 380-440 V
Design Guide | iC7 Series Air-cooled System Modules Losses calculated with 400 V AC and 594 V DC No output filters Switching frequency 2 kHz with SVPWM modulator or 3 kHz with DPWM modulator Table 65: Power Losses of Inverter Modules without Options, 380–440 V...
Page 142: Power Losses Of Inverter Modules Without Options, 441-500
Design Guide | iC7 Series Air-cooled System Modules Table 66: Power Losses of Inverter Modules with dU/dt Filter, 150 m (492 ft) Motor Cables, 380–440 V Model code Frame Rated current 3 kHz DPWM Total power losses [kW] Main cooling channel power...
Page 143: Power Losses Of Inverter Modules With Du/Dt Filter, 150 M (492 Ft) Motor Cables, 441-500 V
Design Guide | iC7 Series Air-cooled System Modules Table 67: Power Losses of Inverter Modules without Options, 441–500 V Model code Frame Rated current 2 kHz SVPWM or 3 kHz DPWM Total power losses [kW] Main cooling channel power losses [kW]...
Page 144: Technical Data
Design Guide | iC7 Series Air-cooled System Modules Table 68: Power Losses of Inverter Modules with dU/dt Filter, 150 m (492 ft) Motor Cables, 441–500 V Model code Frame Rated current 3 kHz DPWM Total power losses [kW] Main cooling channel power...
Page 145 Design Guide | iC7 Series Air-cooled System Modules Table 69: Mains connection, AFE/GC modules (continued) Technical item or function Technical data Total harmonics distortion THDi (nominal situation and undis- AFE: <5% (Voltage class 5) torted network) Short-circuit current rating, with the specified fuses or cir- The maximum short circuit current I ≤...
Page 146 Design Guide | iC7 Series Air-cooled System Modules Table 71: Control electronic connection Technical item or function Technical data Input voltage U 24 V DC +15/-10%, power consumption is 15–60 W depending on configuration. Ground = negative polarity floating (potentially balanced (1 MΩ)
Page 147 Design Guide | iC7 Series Air-cooled System Modules Table 73: Ambient conditions (continued) Technical item or function Technical data Pollution degree Altitude 0–4000 m (0–13100 ft) above sea level: in case network is not corner-grounded (Voltage class 5). Above 1000 m (3300 ft): derating of the output current by 1% per each 100 m is required.
Page 148 UL 61800-5-1 CSA C22.2 No.274 Functional safety STO/SS1-t with option +BEF2 See the iC7 Series Functional Safety Operating Guide, Air-cooled and Liquid-cooled System Modules. Marine type approvals – 1) For detailed information on the approvals and certifications of the product, see the product label.
Page 149 ...
Page 150 Danfoss reserves the right to alter its products without notice. This also applies to products ordered but not delivered provided that such alterations can be made without changes to form, fit or function of the product. All trademarks in this material are property of Danfoss A/S or Danfoss group companies.

Danfoss iC7 Series Design Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Danfoss iC7 Series

Summary of Contents for Danfoss iC7 Series

This manual is also suitable for:

Table of Contents
