Application Guide | iC7 Series Motion
P 4.1.16 Motor Thermal Load (ETR)
Description: Shows the estimated thermal load of the motor calculated by the ETR function.
Default Value: NA
Unit: %
P 4.1.17 Motor Current Output
Description: Select an output for the motor current signal. The scale of the signal is 0–100% of the nominal current.
Default Value:
Unit: -
P 4.1.18 Motor Voltage Output
Description: Select an output for the motor voltage signal. The scale of the signal is 0–100% of the nominal voltage.
Default Value:
Unit: -
P 4.1.19 Absolute Motor Torque Output
Description: Select an output for the motor torque signal. The scale of the signal is 0–100% of the absolute value of the nominal torque.
Default Value:
Unit: -
P 4.1.20 Extended Motor Torque Output
Description: Select an output for the motor torque signal. The scale of the signal is -200...200% of the nominal torque.
Default Value:
Unit: -
P 4.1.21 Absolute Motor Speed Output
Description: Select an output for the motor speed signal. The scale of the signal is 0–100% of the absolute value of the nominal speed.
Default Value:
Unit: -
P 4.1.22 Extended Motor Speed Output
Description: Select an output for the motor speed signal. The scale of the signal is -200...200% of the nominal speed.
© 2023.11
Parameter Type: Range (0 — 100)
Data Type: REAL
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Parameter Number: 2951
Access Type: Read Only
Parameter Number: 2302
Access Type: Read/Write
Parameter Number: 2303
Access Type: Read/Write
Parameter Number: 2306
Access Type: Read/Write
Parameter Number: 2310
Access Type: Read/Write
Parameter Number: 2301
Access Type: Read/Write
