Basic timer (TIM6&7)
14.4.6

Counter (TIMx_CNT)

Address offset: 0x24
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CNT[15:0]: Counter Value.
14.4.7

Prescaler (TIMx_PSC)

Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler Value.
The counter clock frequency CK_CNT is equal to f
PSC contains the value to be loaded into the active prescaler register at each update event.
14.4.8

Auto-reload register (TIMx_ARR)

Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 ARR[15:0]: Prescaler Value.
ARR is the value to be loaded into the actual auto-reload register.
Refer to Section 14.3.1: Time-base unit on page 331
behavior.
The counter is blocked while the auto-reload value is null.
340/690
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
8 7 6 5
CNT[15:0]
rw rw rw rw
8 7 6 5
PSC[15:0]
rw rw rw rw
/ (PSC[15:0] + 1).
CK_PSC
8 7 6 5
ARR[15:0]
rw rw rw rw
for more details about ARR update and
4 3 2 1
rw rw rw rw
4 3 2 1
rw rw rw rw
4 3 2 1
rw rw rw rw
RM0008
0
rw
0
rw
0
rw
