Independent watchdog (IWDG)
The LSI can be calibrated so as to compute the IWDG timeout with an acceptable accuracy.
For more details refer to
16.4

IWDG registers

Refer to
16.4.1

Key register (IWDG_KR)

Address offset: 0x00
Reset value: 0x0000 0000 (reset by Standby mode)
31 30 29 28
15 14 13 12
w w w
Bits 31:16 Reserved, read as 0.
Bits 15:0 KEY[15:0]: Key value (write only, read 0000h)
These bits must be written by software at regular intervals with the key value AAAAh, otherwise the
watchdog generates a reset when the counter reaches 0.
Writing the key value 5555h to enables access to the IWDG_PR and IWDG_RLR registers (see
Section
Writing the key value CCCCh starts the watchdog (except if the hardware watchdog option is
selected)
16.4.2

Prescaler register (IWDG_PR)

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
356/690
LSI calibration on page
Section 1.1 on page 32
27 26 25
11 10 9
w w w w
16.3.2)
27 26 25
11 10 9
Reserved
74.
for a list of abbreviations used in register descriptions.
24 23 22
Reserved
8 7 6
KEY[15:0]
w w w
24 23 22
Reserved
8 7 6
21 20 19 18
5 4 3 2
w w w w
21 20 19 18
5 4 3 2
rw
RM0008
17 16
1 0
w w
17 16
1 0
PR[2:0]
rw rw
