Controller area network (bxCAN)
CAN master status register (CAN_MSR)
Address offset: 0x04
Reset value: 0x0000 0C02
31 30 29
15 14 13
Reserved
Res.
Bits 31:12 Reserved, forced by hardware to 0.
Bit 11 RX: CAN Rx Signal
Monitors the actual value of the CAN_RX Pin.
Bit 10 SAMP: Last Sample Point
The value of RX on the last sample point (current received bit value).
Bit 9 RXM: Receive Mode
The CAN hardware is currently receiver.
Bit 8 TXM: Transmit Mode
The CAN hardware is currently transmitter.
Bits 7:5 Reserved, forced by hardware to 0.
Bit 4 SLAKI: Sleep Acknowledge Interrupt
When SLKIE=1, this bit is set by hardware to signal that the bxCAN has entered Sleep Mode. When
set, this bit generates a status change interrupt if the SLKIE bit in the CAN_IER register is set.
This bit is cleared by software or by hardware, when SLAK is cleared.
Note: When SLKIE=0, no polling on SLAKI is possible. In this case the SLAK bit can be polled.
Bit 3 WKUI: Wakeup Interrupt
This bit is set by hardware to signal that a SOF bit has been detected while the CAN hardware was
in Sleep mode. Setting this bit generates a status change interrupt if the WKUIE bit in the CAN_IER
register is set.
This bit is cleared by software.
520/690
28 27 26 25
12 11 10 9
RX SAMP RXM
r r r
24 23 22 21
Reserved
Res.
8 7 6 5
TXM Reserved
r Res.
20 19 18 17
4 3 2 1
SLAKI WKUI ERRI SLAK
rc_w1 rc_w1 rc_w1
RM0008
16
rw
0
INAK
r r
