Interrupts and events
8.3.5

Software interrupt event register (EXTI_SWIER)

Address offset: 0x10
Reset value: 0x0000 0000
31 30 29
15 14 13
SWIER SWIER SWIER SWIER
15 14 13
rw rw rw
Bits 31:19 Reserved, must be kept at reset value (0).
Bits 18:0 SWIERx: Software Interrupt on line x
Writing a 1 to this bit when it is at 0 sets the corresponding pending bit in EXTI_PR. If the interrupt is
enabled on this line on the EXTI_IMR and EXTI_EMR, an interrupt request is generated.
This bit is cleared by clearing the corresponding bit of EXTI_PR (by writing a 1 into the bit).
8.3.6

Pending register (EXTI_PR)

Address offset: 0x14
Reset value: 0xxxxx xxxx
31 30 29
15 14 13
PR15 PR14 PR13 PR12
rc_w1 rc_w1 rc_w1 rc_w1
Bits 31:19 Reserved, must be kept at reset value (0).
Bits 18:0 PRx: Pending bit
0: No trigger request occurred
1: selected trigger request occurred
This bit is set when the selected edge event arrives on the external interrupt line. This bit is cleared
by writing a 1 into the bit or by changing the sensitivity of the edge detector.
132/690
28 27 26 25
Reserved
Res.
12 11 10 9
SWIER SWIER SWIER
12 11 10 9
rw rw rw rw
28 27 26 25
Reserved
Res.
12 11 10 9
PR11 PR10 PR9
rc_w1 rc_w1 rc_w1
24 23 22 21
8 7 6
SWIER SWIER SWIER SWIER
8 7 6
rw rw rw rw
24 23 22 21
8 7 6
PR8 PR7 PR6 PR5
rc_w1 rc_w1 rc_w1 rc_w1
20 19 18
SWIER
18
rw
5 4 3 2
SWIER SWIER SWIER
5 4 3 2
rw rw rw
20 19 18
PR18
rc_w1
5 4 3 2
PR4 PR3 PR2
rc_w1 rc_w1 rc_w1
RM0008
17 16
SWIER SWIER
17 16
rw rw
1 0
SWIER SWIER
1 0
rw rw
17 16
PR17 PR16
rc_w1 rc_w1
1 0
PR1 PR0
rc_w1 rc_w1
