Bits 15:0 CCR4[15:0]: Capture/Compare Value.
1/ if CC4 channel is configured as output (CC4S bits):
CCR4 is the value to be loaded in the actual capture/compare 4 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR4 register (bit
OC4PE). Else the preload value is copied in the active capture/compare 4 register when an update
event occurs.
The active capture/compare register contains the value to be compared to the counter TIMx_CNT and
signalled on OC4 output.
2/ if CC4 channel is configured as input (CC4S bits in TIMx_CCMR4 register):
CCR4 is the counter value transferred by the last input capture 4 event (IC4).
13.4.17

DMA control register (TIMx_DCR)

Address offset: 0x48
Reset value: 0x0000
15 14 13
Reserved
Bits 15:13 Reserved, always read as 0
Bits 12:8 DBL[4:0]: DMA Burst Length.
This 5-bits vector defines the length of DMA transfers (the timer recognizes a burst transfer when a
read or a write access is done to the TIMx_DMAR address), i.e. the number of bytes to be transferred.
00000: 1 byte,
00001: 2 bytes,
00010: 3 bytes,
...
10001: 18 bytes.
Bits 7:5 Reserved, always read as 0
Bits 4:0 DBA[4:0]: DMA Base Address.
This 5-bit vector defines the base-address for DMA transfers (when read/write access are done
through the TIMx_DMAR address). DBA is defined as an offset starting from the address of the
TIMx_CR1 register.
Example:
00000: TIMx_CR1,
00001: TIMx_CR2,
00010: TIMx_SMCR,
...
12 11 10 9
DBL[4:0]
rw rw rw rw
8 7 6 5
Reserved
rw
General-purpose timer (TIMx)
4 3 2 1
DBA[4:0]
rw rw rw rw
0
rw
