Digital-to-analog converter (DAC)
11.5.4

DAC channel1 12-bit Left aligned Data Holding Register

(DAC_DHR12L1)

Address offset: 0x0C
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
rw rw rw
Bits 31:16 Reserved.
Bit 15:4 DACC1DHR[11:0]: DAC channel1 12-bit Left aligned data
These bits are written by software which specify 12-bit data for DAC channel1.
Bits 3:0 Reserved.
11.5.5

DAC channel1 8-bit Right aligned Data Holding Register

(DAC_DHR8R1)

Address offset: 0x10
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
Bits 31:8 Reserved.
Bits 7:0 DACC1DHR[7:0]: DAC channel1 8-bit Right aligned data
These bits are written by software which specify 8-bit data for DAC channel1.
