RM0008
12.4.4

DMA/Interrupt enable register (TIMx_DIER)

Address offset: 0x0C
Reset value: 0x0000
15 14 13
COMD CC4D
Res. TDE
E
Res. rw rw
Bit 15 Reserved, always read as 0.
Bit 14 TDE: Trigger DMA request enable.
0: Trigger DMA request disabled.
1: Trigger DMA request enabled.
Bit 13 COMDE: COM DMA request enable.
0: COM DMA request disabled.
1: COM DMA request enabled.
Bit 12 CC4DE: Capture/Compare 4 DMA request enable.
0: CC4 DMA request disabled.
1: CC4 DMA request enabled.
Bit 11 CC3DE: Capture/Compare 3 DMA request enable.
0: CC3 DMA request disabled.
1: CC3 DMA request enabled.
Bit 10 CC2DE: Capture/Compare 2 DMA request enable.
0: CC2 DMA request disabled.
1: CC2 DMA request enabled.
Bit 9 CC1DE: Capture/Compare 1 DMA request enable.
0: CC1 DMA request disabled.
1: CC1 DMA request enabled.
Bit 8 UDE: Update DMA request enable.
0: Update DMA request disabled.
1: Update DMA request enabled.
Bit 7 BIE: Break interrupt enable.
0: Break interrupt disabled.
1: Break interrupt enabled.
Bit 6 TIE: Trigger interrupt enable.
0: Trigger interrupt disabled.
1: Trigger interrupt enabled.
Bit 5 COMIE: COM interrupt enable.
0: COM interrupt disabled.
1: COM interrupt enabled.
Bit 4 CC4IE: Capture/Compare 4 interrupt enable.
0: CC4 interrupt disabled.
1: CC4 interrupt enabled.
12 11 10 9
CC3D CC2D CC1D
E E E E
rw rw rw rw
Advanced-control timers (TIM1&TIM8)
8 7 6 5
COMI
UDE BIE TIE
E
rw rw rw rw
4 3 2
CC4IE CC3IE CC2IE CC1IE
rw rw rw rw
1 0
UIE
rw
253/690
