General-purpose timer (TIMx)
Bit 2 CC2G: Capture/compare 2 generation.
refer to CC1G description
Bit 1 CC1G: Capture/compare 1 generation.
This bit is set by software in order to generate an event, it is automatically cleared by hardware.
0: No action.
1: A capture/compare event is generated on channel 1:
If channel CC1 is configured as output:
CC1IF flag is set, Corresponding interrupt or DMA request is sent if enabled.
If channel CC1 is configured as input:
The current value of the counter is captured in TIMx_CCR1 register. The CC1IF flag is set, the
corresponding interrupt or DMA request is sent if enabled. The CC1OF flag is set if the CC1IF flag
was already high.
Bit 0 UG: Update generation.
This bit can be set by software, it is automatically cleared by hardware.
0: No action.
1: Re-initialize the counter and generates an update of the registers. Note that the prescaler counter
is cleared too (anyway the prescaler ratio is not affected). The counter is cleared if the center-aligned
mode is selected or if DIR=0 (upcounting), else it takes the auto-reload value (TIMx_ARR) if DIR=1
(downcounting).
13.4.7
Capture/compare mode register 1 (TIMx_CCMR1)
Address offset: 0x18
Reset value: 0x0000
The channels can be used in input (capture mode) or in output (compare mode). The
direction of a channel is defined by configuring the corresponding CCxS bits. All the other
bits of this register have a different function in input and in output mode. For a given bit,
OCxx describes its function when the channel is configured in output, ICxx describes its
function when the channel is configured in input. So you must take care that the same bit
can have a different meaning for the input stage and for the output stage.
15
14
13
OC2
OC2M[2:0]
CE
IC2F[3:0]
rw
rw
rw
Output compare mode
Bit 15 OC2CE: Output Compare 2 Clear Enable
Bits 14:12 OC2M[2:0]: Output Compare 2 Mode.
Bit 11 OC2PE: Output Compare 2 Preload enable.
Bit 10 OC2FE: Output Compare 2 Fast enable.
318/690
12
11
10
9
OC2
OC2
PE
FE
CC2S[1:0]
IC2PSC[1:0]
rw
rw
rw
rw
8
7
6
5
OC1
OC1M[2:0]
CE
IC1F[3:0]
rw
rw
rw
rw
4
3
2
1
OC1
OC1
PE
FE
CC1S[1:0]
IC1PSC[1:0]
rw
rw
rw
rw
RM0008
0
rw
