RM0008
23.6.7

Status register 2 (I2C_SR2)

Address offset: 0x18
Reset value:0x0000
15 14 13 12
r r r
Bits 15:8 PEC[7:0] Packet Error Checking Register
This register contains the internal PEC when ENPEC=1.
Bit 7 DUALF: Dual Flag (Slave mode)
0: Received address matched with OAR1
1: Received address matched with OAR2
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 6 SMBHOST: SMBus Host Header (Slave mode)
0: No SMBus Host address
1: SMBus Host address received when SMBTYPE=1 and ENARP=1.
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 5 SMBDEFAULT: SMBus Device Default Address (Slave mode)
0: No SMBus Device Default address
1: SMBus Device Default address received when ENARP=1
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 4 GENCALL: General Call Address (Slave mode)
0: No General Call
1: General Call Address received when ENGC=1
– Cleared by hardware after a Stop condition or repeated Start condition, or when PE=0.
Bit 3 Reserved, forced by hardware to 0.
11 10 9
PEC[7:0]
r r r r
Inter-integrated circuit (I
8 7 6 5
SMB
SMB
DUALF DEF
HOST
AULT
r r r r
2
C) interface
4 3 2 1
GEN
Res. TRA BUSY
CALL
r r r
0
MSL
r
