Real-time clock (RTC)
15.4.6

RTC alarm register high (RTC_ALRH / RTC_ALRL)

When the programmable counter reaches the 32-bit value stored in the RTC_ALR register,
an alarm is triggered and the RTC_alarmIT interrupt request is generated. This register is
write-protected by the RTOFF bit in the RTC_CR register, and a write operation is allowed if
the RTOFF value is '1'.
RTC alarm register high (RTC_ALRH)
Address offset: 0x20
Write only (see
Reset value: 0xFFFF
15 14 13
w w w
Bits 15:0 RTC_ALR[31:16]: RTC Alarm High
The high part of the alarm time is written by software in this register. To write to this register it is
necessary to enter configuration mode (see
page 345).
RTC alarm register low (RTC_ALRL)
Address offset: 0x24
Write only (see
Reset value: 0xFFFF
15 14 13
w w w
Bits 15:0 RTC_ALR[15:0]: RTC Alarm Low
The low part of the alarm time is written by software in this register. To write to this register it is
necessary to enter configuration mode (see
page 345).
352/690
Section 15.3.4 on page
12 11 10 9
w w w w
Section 15.3.4 on page
12 11 10 9
w w w w
345)
8 7 6
RTC_ALR[31:16]
w w w
Section 15.3.4: Configuring RTC registers on
345)
8 7 6
RTC_ALR[15:0]
w w w
Section 15.3.4: Configuring RTC registers on
5 4 3 2
w w w w
5 4 3 2
w w w w
RM0008
1 0
w w
1 0
w w
