STM32F101xx, STM32F102xx, STM32F103xx, STM32F105xx

and STM32F107xx advanced ARM-based 32-bit MCUs

Introduction

This reference manual targets application developers. It provides complete information on

how to use the STM32F101xx, STM32F102xx, STM32F103xx and

STM32F105xx/STM32F107xx microcontroller memory and peripherals. The STM32F101xx,

STM32F102xx, STM32F103xx and STM32F105xx/STM32F107xx will be referred to as

STM32F10xxx throughout the document, unless otherwise specified.

The STM32F10xxx is a family of microcontrollers with different memory sizes, packages and

peripherals.

For ordering information, mechanical and electrical device characteristics please refer to the

low-, medium- and high-density STM32F101xx and STM32F103xx datasheets, to the low-

and medium-density STM32F102xx datasheets and to the STM32F105xx/STM32F107xx

connectivity line datasheet.

For information on programming, erasing and protection of the internal Flash memory

please refer to the STM32F10xxx Flash programming manual.

For information on the ARM Cortex™-M3 core, please refer to the Cortex™-M3 Technical

Reference Manual.

Related documents

Available from www.arm.com:

■

Cortex™-M3 Technical Reference Manual, available from:

http://infocenter.arm.com/help/topic/com.arm.doc.ddi0337e/DDI0337E_cortex_m3_r1p1_trm.pdf

Available from www.st.com:

■

STM32F101xx STM32F103xx datasheets

■

STM32F10xxx Flash programming manual

March 2009

Reference manual

Rev 1

RM0034

1/959

www.st.com
