DMA controller (DMA)
9.4
DMA registers
Refer to
Note:
In the following registers, all bits relative to channel6 and channel7 are not relevant for
DMA2 since it has only 5 channels.
9.4.1
DMA interrupt status register (DMA_ISR)
Address offset: 0x00
Reset value: 0x0000 0000
31
30
29
28
Reserved
15
14
13
12
TEIF4
HTIF4
TCIF4
GIF4
r
r
r
Bits 31:28
Reserved, always read as 0.
Bits 27, 23,
TEIFx: Channel x Transfer Error flag (x = 1 ..7)
19, 15, 11,
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
7, 3
DMA_IFCR register.
0: No transfer error (TE) on channel x
1: A transfer error (TE) occurred on channel x
Bits 26, 22,
HTIFx: Channel x Half Transfer flag (x = 1 ..7)
18, 14, 10,
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
6, 2
DMA_IFCR register.
0: No half transfer (HT) event on channel x
1: A half transfer (HT) event occurred on channel x
Bits 25, 21,
TCIFx: Channel x Transfer Complete flag (x = 1 ..7)
17, 13, 9, 5,
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
1
DMA_IFCR register.
0: No transfer complete (TC) event on channel x
1: A transfer complete (TC) event occurred on channel x
Bits 24, 20,
GIFx: Channel x Global interrupt flag (x = 1 ..7)
16, 12, 8, 4,
This bit is set by hardware. It is cleared by software writing 1 to the corresponding bit in the
0
DMA_IFCR register.
0: No TE, HT or TC event on channel x
1: A TE, HT or TC event occurred on channel x
142/690
Section 1.1 on page 32
27
26
25
TEIF7
HTIF7
TCIF7
r
r
r
11
10
9
TEIF3
HTIF3
TCIF3
r
r
r
r
for a list of abbreviations used in the register descriptions.
24
23
22
GIF7
TEIF6
HTIF6
TCIF6
r
r
r
8
7
6
GIF3
TEIF2
HTIF2
TCIF2
r
r
r
21
20
19
18
GIF6
TEIF5
HTIF5
r
r
r
r
5
4
3
2
GIF2
TEIF1
HTIF1
r
r
r
r
RM0008
17
16
TCIF5
GIF5
r
r
1
0
TCIF1
GIF1
r
r
