RM0008
HADDR[25:0] contain the external memory address. Since HADDR is a byte address
whereas the memory is addressed in words, the address actually issued to the memory
varies according to the memory data width, as shown in the following table.
Table 67.
Memory width
8-bit
16-bit
32-bit
Wrap support for NOR Flash/PSRAM
Each NOR Flash/PSRAM memory bank can be configured to support wrap accesses.
On the memory side, two cases must be considered depending on the access mode:
asynchronous or synchronous.
●
Asynchronous mode: in this case, wrap accesses are fully supported as long as the
address is supplied for every single access.
●
Synchronous mode: in this case, the FSMC issues the address only once, and then
the burst transfer is sequenced by the FSMC clock CLK.
Some NOR memories support linear burst with wrap-around accesses, in which a fixed
number of words is read from consecutive addresses modulo N (N is typically 8, 16 or
32 and can be programmed through the NOR Flash configuration register). In this case,
it is possible to set the memory wrap mode identical to the AHB master wrap mode.
Otherwise, in the case when the memory wrap mode and the AHB master wrap mode
cannot be set identically, wrapping should be disabled (through the appropriate bit in the
FSMC configuration register) and the wrap transaction split into two consecutive linear
transactions.
18.4.2
NAND/PC Card address mapping
In this case, three banks are available, each of them divided into memory spaces as
indicated in
Table 68.
Start address
0x9C00 0000
0x9800 0000
0x9000 0000
0x8800 0000
0x8000 0000
0x7800 0000
0x7000 0000
External memory address
Data address issued to the memory
HADDR[25:0]
HADDR[25:1] >> 1
HADDR[25:2] >>2
Table
68.
Memory mapping and timing registers
End address
0x9FFF FFFF
0x9BFF FFFF
Bank 4 - PC card
0x93FF FFFF
0x8BFF FFFF
Bank 3 - NAND Flash
0x83FF FFFF
0x7BFF FFFF
Bank 2- NAND Flash
0x73FF FFFF
Flexible static memory controller (FSMC)
FSMC Bank
Memory space
Attribute
Common
Attribute
Common
Attribute
Common
Maximum memory capacity (bits)
64 Mbytes x 8 = 512 Mbit
64 Mbytes/2 x 16 = 512 Mbit
64 Mbytes/4 x 32 = 512 Mbit
Timing register
I/O
FSMC_PIO4 (0xB0)
FSMC_PATT4 (0xAC)
FSMC_PMEM4 (0xA8)
FSMC_PATT3 (0x8C)
FSMC_PMEM3 (0x88)
FSMC_PATT2 (0x6C)
FSMC_PMEM2 (0x68)
369/690
