Power control/status register (PWR_CSR)

Address offset: 0x04
Reset value: 0x0000 0000 (not reset by wakeup from Standby mode)
Additional APB cycles are needed to read this register versus a standard APB read.
31 30 29
15 14 13
Reserved
Res.
Bits 31:9 Reserved, always read as 0.
Bit 8 EWUP: Enable WKUP pin
This bit is set and cleared by software.
0: WKUP pin is used for general purpose I/O. An event on the WKUP pin does not wakeup the
device from Standby mode.
1: WKUP pin is used for wakeup from Standby mode and forced in input pull down configuration
(rising edge on WKUP pin wakes-up the system from Standby mode).
Note: This bit is reset by a system Reset.
Bits 7:3 Reserved, always read as 0.
Bit 2 PVDO: PVD output
This bit is set and cleared by hardware. It is valid only if PVD is enabled by the PVDE bit.
0: V /V
DD
1: V /V
DD
Note: The PVD is stopped by Standby mode. For this reason, this bit is equal to 0 after Standby or
reset until the PVDE bit is set.
Bit 1 SBF: Standby flag
This bit is set by hardware and cleared only by a POR/PDR (power on reset/power down reset) or by
setting the CSBF bit in the
0: Device has not been in Standby mode
1: Device has been in Standby mode
Bit 0 WUF: Wakeup Flag
This bit is set by hardware and cleared only by a POR/PDR (power on reset/power down reset) or
by setting the CWUF bit in the
0: No wakeup event occurred
1: A wakeup event was received from the WKUP pin or from the RTC alarm
Note: An additional wakeup event is detected if the WKUP pin is enabled (by setting the EWUP bit)
when the WKUP pin level is already high.
