Status register (TIMx_SR)

Address offset: 0x10

Reset value: 0x0000

Bits 15:1 Reserved, always read as 0.

Bit 0 UIF: Update interrupt flag.

This bit is set by hardware on an update event. It is cleared by software.

0: No update occurred.

1: Update interrupt pending. This bit is set by hardware when the registers are updated:

– At overflow or underflow regarding the repetition counter value and if UDIS = 0 in the TIMx_CR1

– When CNT is reinitialized by software using the UG bit in the TIMx_EGR register, if URS = 0 and

UDIS = 0 in the TIMx_CR1 register.

Address offset: 0x14

Reset value: 0x0000

Bits 15:1 Reserved, always read as 0.

Bit 0 UG: Update generation.

This bit can be set by software, it is automatically cleared by hardware.

0: No action.

1: Re-initializes the timer counter and generates an update of the registers. Note that the prescaler

counter is cleared too (but the prescaler ratio is not affected).

Basic timer (TIM6&7)
