RM0444
Bit 6 DMAR: DMA enable receiver
Bits 5:4 Reserved, must be kept at reset value.
Bit 3 HDSEL: Half-duplex selection
Bits 2:1 Reserved, must be kept at reset value.
Bit 0 EIE: Error interrupt enable
34.7.5

LPUART baud rate register (LPUART_BRR)

This register can only be written when the LPUART is disabled (UE
automatically updated by hardware in auto baud rate detection mode.
Address offset: 0x0C
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 BRR[19:0]: LPUART baud rate
Note: It is forbidden to write values lower than 0x300 in the LPUART_BRR register.
Provided that LPUART_BRR must be ≧ 0x300 and LPUART_BRR is 20 bits, a care should
be taken when generating high baud rates using high fck values. fck must be in the range [3
x baud rate..4096 x baud rate].
Low-power universal asynchronous receiver transmitter (LPUART)
This bit is set/reset by software
1: DMA mode is enabled for reception
0: DMA mode is disabled for reception
Selection of Single-wire Half-duplex mode
0: Half duplex mode is not selected
1: Half duplex mode is selected
This bit can only be written when the LPUART is disabled (UE = 0).
Error Interrupt Enable Bit is required to enable interrupt generation in case of a framing
error, overrun error or noise flag (FE = 1 or ORE = 1 or NE = 1 in the LPUART_ISR
register).
0: Interrupt is inhibited
1: An interrupt is generated when FE = 1 or ORE = 1 or NE = 1 in the LPUART_ISR
register.
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
24 23 22
Res. Res. Res.
8 7 6
BRR[15:0]
rw rw rw
RM0444 Rev 5
0). It may be
=
21 20 19 18
Res. Res. BRR[19:16]
rw rw
5 4 3 2
rw rw rw rw
17 16
rw rw
1 0
rw rw
1125/1390
