Figure 389. Start Sequence In Master Mode - ST STM32G0 1 Series Reference Manual

RM0444
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
WS (O)
CK (O),
CKPOL = 0
CK (O),
CKPOL = 1
SD (O)
I2SE
dum: not significant data
In slave mode, the way the frame synchronization is detected, depends on the value of
ASTRTEN bit.
If ASTRTEN = 0, when the audio interface is enabled (I2SE = 1), then the hardware waits for
the appropriate transition on the incoming WS signal, using the CK signal.
Serial peripheral interface / integrated interchip sound (SPI/I2S)

Figure 389. Start sequence in master mode

Master I2S Philips Standard
dum Left sample
Master I2S MSB or LSB justified
dum Left sample
Master PCM short frame
dum Sample1
Master PCM long frame
dum Sample1
RM0444 Rev 5
Right sample
Right sample
Sample 2
Sample 2
MSv37520V2
