33.8.14

USART prescaler register (USART_PRESC)

This register can only be written when the USART is disabled (UE = 0).
Address offset: 0x2C
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 PRESCALER[3:0]: Clock prescaler
The USART input clock can be divided by a prescaler factor:
Note: When PRESCALER is programmed with a value different of the allowed ones,
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
0000: input clock not divided
0001: input clock divided by 2
0010: input clock divided by 4
0011: input clock divided by 6
0100: input clock divided by 8
0101: input clock divided by 10
0110: input clock divided by 12
0111: input clock divided by 16
1000: input clock divided by 32
1001: input clock divided by 64
1010: input clock divided by 128
1011: input clock divided by 256
Remaining combinations: Reserved
programmed prescaler value is 1011 i.e. input clock divided by 256.
