2.5.4 Quick Start up IP Address

To view the network parameters the operator can access the device by the following three methods.
•
Simple Network Management Protocol - SNMP
•
Telnet/SSH
Table 2-4. Quick Start up IP Address
Command
show ip interface
ip address
show serviceport
serviceport ip
Details
Displays the Network Configurations
Interface Status – Indicates whether the interface is up or
down.
IP Address - IP Address of the interface
Subnet Mask - IP Subnet Mask for the interface.
MAC Address - The MAC Address used for this in-band
connectivity
Network Configurations Protocol Current - Indicates which
network protocol is being used. Default is None.
(Config)#interface vlan 1
(if-vlan 1)#ip address <ipaddr> <netmask>
(if-vlan 1)#exit
(Config)#ip default-gateway <gateway>
IP Address range from 0.0.0.0 to 255.255.255.255
Subnet Mask range from 0.0.0.0 to 255.255.255.255
Gateway Address range from 0.0.0.0 to 255.255.255.255
Displays all of the login session information
Display the serviceport's network configurations
Interface Status – Indicates whether the interface is up or
down.
IP Address - IP Address of the interface. Default IP is 0.0.0.0
Subnet Mask - IP Subnet Mask for the interface. Default is
0.0.0.0
Default Gateway - The default Gateway for this interface.
Default value is 0.0.0.0
Burned in MAC Address - The Burned in MAC Address used for
out-of-band connectivity
Configured IPv4 Protocol - Indicates which network protocol is
being used. Default is DHCP.
(Config)#serviceport protocol none
(Config)#serviceport ip <ipaddr> <netmask> <gateway>
(Config)#
QuantaMesh | Installation and Quick Startup
Layer 2/3/4 Managed Switch
24
