5.3.5

SNMP Server Commands

5.3.5.1 show snmp
This command displays SNMP community information and SNMP trap/inform receivers. Trap/Inform
messages are sent across a network to an SNMP Network Manager. These messages alert the
manager to events occurring within the switch or on the network. Six trap/inform receivers are
simultaneously supported.
Six communities are supported. You can add, change, or delete communities. The switch does not have
to be reset for changes to take effect.
The SNMP agent of the switch complies with SNMP versions 1, 2c, and 3 (for more about the SNMP
specification, see the SNMP RFCs). The SNMP agent sends traps through TCP/IP to an external SNMP
manager based on the SNMP configuration (the trap receiver and other SNMP community parameters).
Syntax
show snmp
Default Setting
None
Command Mode
Privileged Exec
Display Message
Community-String: The community string to which this entry grants access. A valid entry is a
case-sensitive alphanumeric string of up to 20 characters. Each row of this table must contain a
unique community name.
Community-Access: The access level for this community string.
Group Name: The community this mapping configures.
View Name: The view this community has access to.
IP Address: Access to this community is limited to this IP address.
Target Address: An IP address (or portion thereof) from which this device will accept SNMP
packets with the associated community.
Type: The type of message that will be sent, either traps or informs.
Community: The community traps will be sent to.
Version: The version of SNMP the trap will be sent as.
SNMP v1 – Uses SNMP v1 to send traps to the receiver.
SNMP v2 – Uses SNMP v2 to send traps to the receiver.
