7.4.1.4 show ip mcast mroute
This command displays a summary or all the details of the multicast table.
Syntax
show ip mcast mroute {detail | summary}
detail - displays the multicast routing table details.
summary - displays the multicast routing table summary.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
If the "detail" parameter is specified, the following fields are displayed:
Source IP: This field displays the IP address of the multicast data source.
Group IP: This field displays the IP address of the destination of the multicast packet.
Expiry Time (secs): This field displays the time of expiry of this entry in seconds.
Up Time (secs): This field displays the time elapsed since the entry was created in seconds.
RPF Neighbor: This field displays the IP address of the RPF neighbor.
Flags: This field displays the flags associated with this entry.
If the "summary" parameter is specified, the following fields are displayed:
Source IP: This field displays the IP address of the multicast data source.
Group IP: This field displays the IP address of the destination of the multicast packet.
Protocol: This field displays the multicast routing protocol by which this entry was created.
Incoming Interface: This field displays the interface on which the packet for this source/group
arrives.
Outgoing Interface List: This field displays the list of outgoing interfaces on which this packet is
forwarded.
This command displays the multicast configuration settings such as flags, timer settings, incoming and
outgoing interfaces, RPF neighboring routers, and expiration times of all the entries in the multicast
mroute table containing the given <groupipaddr>.
