5.22 IPv6 ACL Command

5.22.1 Show Commands

5.22.1.1 show ipv6 access-lists
This command displays an IPv6 access list and all of the rules that are defined for the IPv6 ACL. Use the
[name] parameter to identify a specific IPv6 ACL to display.
Syntax
show ipv6 access-lists [<name>]
<name> - ACL name which uniquely identifies the IPv6 ACL to display.
Default Setting
None
Command Mode
Privileged EXEC
User EXEC
Display Message
Rule Number: The ordered rule number identifier defined within the IPv6 ACL.
Action: The action associated with each rule. The possible values are Permit or Deny.
Match All: Indicates whether this access list applies to every packet. Possible values are True or
False.
IPv6 Protocol: The protocol to filter for this rule.
Source IP Address: The source IP address for this rule.
Source L4 Port Keyword: The source port for this rule.
Destination IP Address: The destination IP address for this rule.
Destination L4 Port Keyword: The destination port for this rule.
IP DSCP: The value specified for IP DSCP.
Flow Label: The value specified for IPv6 Flow Label.
Log: Displays when you enable logging for the rule.
Assign Queue: The queue identifier to which packets matching this rule are assigned.
Mirror Interface: The slot/port to which packets matching this rule are copied.
Redirect Interface: The slot/port to which packets matching this rule are forwarded.
Time Range Name: Displays the name of the time-range if the Ipv6 ACL rule has referenced a time
range.
