5.28 Multi Chassis Link Aggregation Commands

5.28.1 Show Commands

5.28.1.1 show mlag
This command displays detailed information about the Multi-chassis Link Aggregation (MLAG)
configured on the switch.
Syntax
show mlag <mlag-number>
Default Setting
None
Command Mode
Privileged Exec
Display Message
Admin Mode: Displays the administrative mode for MLAG functionality on the switch.
Domain Id: Represents the domain identify number of MLAG peer devices.
MLAG Status: Represents the operation status of MLAG.
Configuration Consistency Status: Represents the configuration consistency status of MLAG peer
devices.
MLAG Role: Represents the role of MLAG peer device.
MLAG System-Mac: Represents the operation system MAC address of MLAG peer devices.
MLAG Local Syatem-Mac: Represents the statically defined system MAC address of MLAG peer
devices.
Number of MLAG Configured: Represents the number of MLAG port-channel member.
Peer Gateway Mode: To enable Layer 3 forwarding for packets destined to the gateway MAC
address of the MLAG.
Delay Restore Time: To delay the MLAG from coming up on the restored MLAG peer device after a
reload when the peer adjacency is already established. The range is from 5 to 600 seconds.
Keepalive Timeout: To specify the timeout (in seconds) between re-transmissions to the MLAG
peer device. The range is from 3 to 20.
Interface: Shows the interface on which MLAG information is being displayed.
Status: Represents the link status of MLAG peer link port or port-channel member.
ID: Represents the identify number of MLAG port-channel member.
Consistency: Represents the configuration consistency status of MLAG port-channel member.
Active Vlan: Represents the VLAN which MLAG peer link port or port-channel member belong to.
