This command displays the multicast configuration settings such as flags, timer settings, incoming and
outgoing interfaces, RPF neighboring routers, and expiration times of all the entries in the multicast
mroute table containing the given <sourceipaddr>.
Syntax
show ip mcast mroute source <sourceipaddr> {summary | detail}
< sourceipaddr > - the IP Address of the multicast data source.
summary - display the multicast routing table summary
detail - Display the multicast routing table details.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
If the < groupipaddr > parameter is specified the follow fields are displayed:
Source IP: This field displays the IP address of the multicast data source.
Group IP: This field displays the IP address of the destination of the multicast packet.
Expiry Time (secs): This field displays the time of expiry of this entry in seconds.
Up Time (secs): This field displays the time elapsed since the entry was created in seconds.
RPF Neighbor: This field displays the IP address of the RPF neighbor.
Flags: This field displays the flags associated with this entry.
If the summary parameter is specified the follow fields are displayed:
Source IP: This field displays the IP address of the multicast data source.
Group IP: This field displays the IP address of the destination of the multicast packet.
Protocol: This field displays the multicast routing protocol by which this entry was created.
Incoming Interface: This field displays the interface on which the packet for this source arrives.
Outgoing Interface List: This field displays the list of outgoing interfaces on which this packet is
forwarded.
