5.21.1.4 show access-lists interface
This command displays IP ACLs, IPv6 ACLs, and MAC access control lists information for a designated
interface and direction. Use the control-plane keyword to display the ACLs applied on the CPU port.
Syntax
show access-lists {{ interface <slot/port> | port-channel <portchannel-id> } {in | out} | control-plane}
<slot/port> - is the interface number.
<portchannel-id> - is the port-channel ID. The port-channel ID is range from 1 to 64.
control-plane – is the management (CPU) port.
in | out - The direction value is either in or out
Default Setting
None
Command Mode
Privileged Exec
Display Message
ACL Type: This displays ACL type is IP, IPv6 or MAC.
ACL ID: Access List name for a MAC or IPv6 access list or the numeric identifier for an IP access
list.
Sequence Number: An optional sequence number may be specified to indicate the order of this
access list relative to other access lists already assigned to this interface and direction. A lower
number indicates higher precedence order. If a sequence number is already in use for this interface
and direction, the specified access list replaces the currently attached access list using that
sequence number. If the sequence number is not specified by the user, a sequence number that is
one greater than the highest sequence number currently in use for this interface and direction is
used. Valid range is (1 to 4294967295).
5.21.1.5 show access-lists vlan
This command displays Access List information for a particular VLAN ID.
Syntax
show access-lists {{ interface <slot/port> | port-channel <portchannel-id> } {in | out} | control-plane}
<slot/port> - is the interface number.
<portchannel-id> - is the port-channel ID. The port-channel ID is range from 1 to 64.
