1.5 SNMP-Based Management

You can manage the Switch with an SNMP-compatible console program. The Switch supports SNMP
version 1.0, version 2.0, and version 3.0. The SNMP agent decodes the incoming SNMP messages and
responds to requests with MIB objects stored in the database. The SNMP agent updates the MIB objects
to generate statistics The Switch supports a comprehensive set of MIB extensions:
•
RFC1493 Bridge
•
RFC 2819 RMON-MIB
•
RFC 2233 Interface MIB
•
RFC 2618 (Radius-Auth-Client-MIB)
•
RFC 2620 (Radius-Acc-Client-MIB)
•
RFC 1724 (RIPv2-MIB)
•
RFC 1850 (OSPF-MIB)
•
RFC 1850 (OSPF-TRAP-MIB)
•
RFC 2787 (VRRP-MIB)
•
RFC 3289 - DIFFSERV-DSCP-TC
•
RFC 3289 - DIFFSERV-MIB
•
QoS-DIFFSERV-EXTENSIONS-MIB
•
QoS-DIFFSERV-PRIVATE-MIB
•
RFC 2674 802.1p
•
RFC 2932 (IPMROUTE-MIB)
•
Quanta Enterprise MIB
•
ROUTING-MIB
•
MGMD-MIB
•
RFC 2934 PIM-MIB
•
DVMRP-STD-MIB
•
IANA-RTPROTO-MIB
•
MULTICAST-MIB
•
ROUTING6-MIB
•
IEEE8021-PAE-MIB
•
INVENTORY-MIB
•
MGMT-SECURITY-MIB
•
QoS-MIB
•
QoS-ACL-MIB
•
QoS-COS-MIB
•
QoS-AUTOVOIP-MIB
