5.21.1.3 show ip access-lists
This command displays an Access Control List (ACL) and all of the rules that are defined for the ACL.
Syntax
show ip access-lists [<1-199> | <name>]
<1-199> - is the number used to identify the ACL.
<name> - is the name of the ACL.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
Current number of ACLs: The number of user-configured rules defined for this ACL.
Maximum number of ACLs: The maximum number of ACL rules.
ACL ID: The identifier of this ACL.
Rule: This displays the number identifier for each rule that is defined for the ACL.
Action: This displays the action associated with each rule. The possible values are Permit or Deny.
Match ALL: Match all packets or not.
IPv4 Protocol: This displays the protocol to filter for this rule.
Source IP Address: This displays the source IP address for this rule.
Source IP Mask: This field displays the source IP Mask for this rule.
Source L4 Port Keyword: This field displays the source port for this rule.
Destination IP Address: This displays the destination IP address for this rule.
Destination IP Mask: This field displays the destination IP Mask for this rule.
Destination L4 Port Keyword: This field displays the destination port for this rule.
IP DSCP: This field displays the IP DSCP value for this rule.
IP Precedence: This field displays the IP Precedence value for this rule.
IP TOS: This field displays the IP TOS value for this rule.
Log: This field displays when you enable logging for this rule.
Assign Queue: This field displays the queue identifier to which packets matching this rule are
assigned.
Mirror Interface: This field displays the slot/port to which packets matching this rule are copied.
